Object-Oriented Databases

Obj t O i t d D t b

Object-Oriented Databases

db4o: Part 2

•

•

•

Summary: db4o Part 1 y

ƒ Managing databases with an object container

ƒ Retrieving objects

ƒ query by exampleq y y p

ƒ native queries

ƒ SODA queries

ƒ Updating and deleting simple and complex objects

ƒ configuration of update, delete and activation depth

ƒ inconsistencies between in-memory and stored objects

ƒ Transactions

ƒ commit and rollback

ƒ concurrent transactions, collision detection and avoidance

Configuration and Tuning g g

ƒ Configuration interface

ƒ global configuration set through Db4o.configure()

ƒ current global settings are cloned when object container or object server opened

ƒ further changes of global configuration not propagated to already existing object containers and object servers

existing object containers and object servers

ƒ External tools

performance tuning

ƒ performance tuning

ƒ database diagnostics

ƒ Indexes

ƒ Indexes

ƒ optimise query evaluation

Configuration Interface g

ƒ Represented by com.db4o.config.Configuration

ƒ Methods rather than properties files

ƒ Configuration setting groups Configuration setting groups

ƒ object-related methods

ƒ file-related methodsfile related methods

ƒ reflection-related methods

ƒ communication-related methods

ƒ logging-related methods

ƒ miscellaneous configuration methods

ƒ Configuring an existing object container or object server

ƒ access settings with ExtObjectContainer#configure() or

External Tools

ƒ Defragment

ƒ removes unused fields and management information

ƒ compacts database file and provides faster access

ƒ initiated from command line or from within application

ƒ Statistics

ƒ computes and outputs statics about a database file

ƒ executed from command line or programmatically

ƒ Logger

ƒ logs all objects in a database file

ƒ logs all objects of a given class

ƒ run from command line

Indexes

ƒ Trade-off between increased query performance and decreased storage, update and delete performance

ƒ Support for B-Tree indexes on single object fields Support for B Tree indexes on single object fields

ƒ enabled or disabled using configuration interface

ƒ internal field i indexed_ is set to true or false for indexed field

ƒ index created or removed automatically when object container or object server is opened

ƒ Example

// create an index

Db4o.configure().objectClass(...).objectField(...).indexed(true);

// remove an index

Db4o.configure().objectClass(...).objectField(...).indexed(false);

Tuning for Speed g p

ƒ Heuristics to improve performance of db4o

ƒ Object loading

ƒ use appropriate activation depthpp p p

ƒ use multiple object containers

ƒ disable weak references if not required (no updates performed)

ƒ Database tests

ƒ disable detection of schema changes

ƒ disable instantiation tests of persistent classes at start-up

ƒ Query evaluation

ƒ set field indexes on most used objects to improve searches

ƒ optimise native queries

Distribution and Replication p

ƒ Local mode

ƒ standalone database

ƒ database file opened and accessed directly

ƒ one user, one process or one thread at a time

ƒ Client/Server mode

ƒ multiple clients interact with one central server

ƒ server listens for and accepts connections

ƒ clients connect to server to perform database tasks

ƒ Replication

ƒ multiple server manage redundant copies of a database

ƒ changes are replicated from master to client servers

li t d d t b d t b k t i t t

ƒ replicated databases need to be kept consistent

Client/Server Modes: Networking Mode g

Virtual Machine

db4o Client

Database Operations

Database File db4o Server

db4o Client

db4o Client

Database File

db4o Client

ƒ Client opens TCP/IP connection to server p

ƒ method Db4o.openServer(filename, port)

ƒ method Db4o.openClient(host, port, user, pass)

ƒ Client sends query, insert, update and delete instructions

to server and receives data from the server

Client/Server Modes: Embedded Mode

Virtual Machine

Database File db4o Server

Embedded Client Database Operations

Database File

ƒ Not distributed across a network

ƒ client and server run in the same virtual machine

ƒ better performance for multi-threaded applications

ƒ Server is started on port 0

ƒ Client is opened using Client is opened using ObjectServer#openClient() ObjectServer#openClient()

Client/Server Modes: Out-of-Band Signalling g g

Server Machine Client Machine

MessageRecipient processMessage MessageSender

sendMessage

Database File ObjectServer

Database Operations and Commands ObjectContainer

ƒ Basic client/server mode cannot transmit command

ƒ operations are limited to methods of ObjectContainer

ƒ Out-of-band signalling g g

ƒ interface MessageSender

ƒ interface MessageRecipient

Replication p

ƒ Database managed by redundant servers

ƒ data changes on masters or publishers

ƒ changes replicated to clients of subscribers

ƒ Several forms of replication supported

ƒ snapshot replication

ƒ transactional replication

ƒ merge replication

ƒ Replication in db4o has to be coded into application and

cannot be configured on an administrative level

Replication Modes: Snapshot Replication p p p

M t

Client Client

Master

Client Client

ƒ Snapshots of the master database replicated to client p p

ƒ state-based

ƒ periodical schedule

ƒ Support in db4o

ƒ special SODA query to detect all new and updated objectsp q y p j

Replication Modes: Transactional Replication p p

M t

Client Client

Master

Client Client

ƒ Changes are synchronised after transaction g y

ƒ operation based

ƒ changes are replicated immediately

ƒ Support in db4o

ƒ single object replication with ReplicationProcess

Replication Modes: Merge Replication p g p

M t

Client Client

Master

Client Client

ƒ Changes from client are merged to central server g g

ƒ Other clients are updated to reflect changes

ƒ Can be done either transactionally or on a periodic basis

ƒ Can be done either transactionally or on a periodic basis

ƒ Typically occurs if subscribers are occasionally offline

Core Replication p

ƒ Transfers data between peer object containers

ƒ local database files

ƒ object servers in networking or embedded mode

ƒ Requires three steps

ƒ generating unique IDs and version numbers

ƒ creating a ReplicationProcess object

ƒ replicating objects

ƒ Replication mode is dependent on implementation

ƒ Replication is bidirectional by default

ƒ replication can be configured to be unidirectional using method ReplicationProcess#setDirection()

Core Replication p

// configuration

Db4o.configure().generateUUIDs(Integer.MAX VALUE);g () g ( g _ );

Db4o.configure().generateVersionNumbers(true);

// replication process

ReplicationProcess replication = db1.ext().replicationBegin(db2, new ReplicationConflictHandler() {

public Object resolveConflict(ReplicationProcess p, Object a, Object b) {

return a;

return a;

} } );

replication.setDirection(db1, db2);

// update database and replicate (transactional replication) Author alex = new Author("Alexandre de Spindler");

db1 t( l ) db1.set(alex);

replication.replicate(alex);

replication.commit();

Core Replication p

// query for changed objects Query query = db1.query();

Q y q y q y();

query.constrain(Publication.class);

replication.whereModified(query);

ObjectSet<Publication> result = query.execute();

// replicate objects (snapshot replication) for (Publication publication: result) {

replication replicate(publication);

replication.replicate(publication);

}

replication.commit();

db4o Replication System p y

ƒ Introduced in db4o version 5.1

ƒ Replication solution separated from db4o core

ƒ bridges divide between db4o and relational databasesg

ƒ uni- or bidirectional replication

ƒ replication of relational databases based on Hibernate

ƒ Supported replication providers

ƒ db4o to db4o

ƒ db4o to Hibernate, Hibernate to db4o

ƒ Hibernate to Hibernate

ƒ Concepts similar to core replication

ƒ ReplicationSession instead of ReplicationProcess

Schema Evolution

ƒ Class definitions and inheritance structure can change

ƒ additional application requirements

ƒ software refactoring

ƒ Class definitions and hierarchy are database schema

ƒ In object-oriented database schema evolution is simpler j p as in object-relational mappings as only one data model

C C C C C C

C C C C C C

T T

T

OODBMS RDBMS

OODBMS RDBMS

Refactoring Scenarios g

ƒ Changes to interface implemented by class

ƒ supported as db4o only stores data and not implementations

ƒ Removing a field g

ƒ new objects stored in new format

ƒ additional field ignored in objects stored in old format

ƒ Adding a field

ƒ new objects stored in new format

ƒ additional field set to null in objects stored in old format

ƒ Changing the type of a field

ƒ simply stored as a new field

ƒ manual migration if old and new type incompatible

Refactoring Scenarios g

ƒ Renaming a field

ƒ old field is deleted and a new inserted

ƒ data migration through configuration interface

ƒ Renaming a class

Db4o.configure().objectClass(...).objectField(...).rename(...);

g

ƒ managed through configuration interface

Db4o.configure().objectClass(...).rename(...);

ƒ Merging fields

ƒ Splitting fields manual using a helper program

g () j ( ) ( )

ƒ Splitting fields manual using a helper program

ƒ Moving fields

Inheritance Evolution

ƒ Refactoring of inheritance structure

ƒ deleting classes from inheritance hierarchy

ƒ inserting classes into inheritance hierarchy

ƒ swap classes in inheritance hierarchy

ƒ Tools for inheritance evolution are being developed

ƒ create a type-less transfer database

ƒ switch classpath manually

Callbacks

ƒ Set of methods called in response to events (triggers)

ƒ db4o events

ƒ activate and deactivate

ƒ new, update and delete

ƒ Methods called before and after event

ƒ methods starting with can called before event

ƒ methods starting with on called after event

ƒ Methods defined by interface ObjectCallbacks

ƒ interface does not have to be implemented explicitly by p p y y persistent class to use its functionality

ƒ any number of methods can be implemented by persistent class

Callbacks

package com.db4o.ext;

public interface ObjectCallbacks { public interface ObjectCallbacks {

public boolean objectCanActivate(ObjectContainer c);

public boolean objectCanDeactivate(ObjectContainer c);

public boolean objectCanDelete(ObjectContainer c);

public boolean objectCanDelete(ObjectContainer c);

public boolean objectCanNew(ObjectContainer c);

public boolean objectCanUpdate(ObjectContainer c);

public void objectOnActivate(ObjectContainer c);

p j ( j )

public void objectOnDeactivate(ObjectContainer c);

public void objectOnDelete(ObjectContainer c);

public void objectOnNew(ObjectContainer c);

public void objectOnUpdate(ObjectContainer c);

public void objectOnUpdate(ObjectContainer c);

}

Use Cases for Callbacks

ƒ Recording or preventing updates

ƒ methods canUpdate() and onUpdate()

ƒ Setting default values after refactoring g g

ƒ get values before update using method canNew()

ƒ Checking object integrity before storing objects g j g y g j

ƒ check field values using methods canNew() and canUpdate()

ƒ Setting transient fields Setting transient fields

ƒ Restoring connected state when objects activated

ƒ display graphical elements or restore network connections

ƒ display graphical elements or restore network connections

ƒ Creating special indexes

ƒ detect if a field is queried often and create index automatically

ƒ detect if a field is queried often and create index automatically

Controlling Object Instantiation g j

ƒ No convention imposed for persistent classes by db4o

ƒ Objects are instantiated using one of three techniques

ƒ using a constructorg

ƒ bypassing the constructor

ƒ using a translator

ƒ For certain classes it is important which of these methods is used to retrieve objects j

ƒ if available, bypassing the constructor is default setting

ƒ behaviour can be configured globally or per class

ƒ for debugging, db4o can be configured to throw an exception if the objects of a class cannot be stored

Using Constructors g

ƒ db4o can use a constructor to instantiate objects

ƒ if no default public constructor is present, all available constructors are tested to create instances of a class

ƒ null or default values passed to all constructor arguments

ƒ first successfully tested constructor is used throughout session if instance of a class cannot be created the object is not stored

ƒ if instance of a class cannot be created, the object is not stored

ƒ by default, execution will continue without any message or error

ƒ Settings adjusted through configuration interface

ƒ Settings adjusted through configuration interface

// global setting

Db4o.configure().callConstructors(true) // per class setting

Db4o.configure().objectClass(...).callConstructors(true) // exceptions for debugging

// p gg g

Using Constructors g

public class Person { Date birthdate;

transient Calendar today;

bli P (D t bi thd t ) { public Person(Date birthdate) {

this.birthdate = birthdate;

// get today's date and store it in a transient field this.today = Calendar.getInstance();

}

public int getAge() {

Calendar birth = Calendar getInstance();

Calendar birth = Calendar.getInstance();

birth.setTime(this.birthdate);

// NullPointerException in the next line if constructor not called!

int years = this.today.get(Calendar.YEAR) – birth.get(Calendar.YEAR);

int diff = birth.add(Calendar.YEAR, age);

return (today.before(birth)) ? age-- : age;

}

Bypassing Constructors yp g

ƒ Constructors that cannot handle null or default values must be bypassed

ƒ db4o uses platform-specific mechanisms to bypass db4o uses platform specific mechanisms to bypass constructors

ƒ Not all environments support this feature

ƒ Not all environments support this feature

ƒ Sun Java Virtual Machine (only JRE 1.4 and above)

ƒ Microsoft NET Framework (except Compact Framework)

ƒ Microsoft .NET Framework (except Compact Framework)

ƒ Default setting if supported by current environment

ƒ Breaks classes that rely on constructors being executed

ƒ Breaks classes that rely on constructors being executed

Bypassing Constructors yp g

public class Person { Calendar birthdate;

int age;

bli P (C l d bi thd t ) { public Person(Calendar birthdate) {

this.birthdate = birthdate;

// calculate age

Calendar today = Calendar.getInstance();

// NullPointerException in next line if called with null value!

int years = today.get(Calendar.YEAR) – this.birthdate.get(Calendar.YEAR);

int diff = birth add(Calendar YEAR age);

int diff = birth.add(Calendar.YEAR, age);

this.age = (today.before(birth)) ? age-- : age;

} ...

}

Translators

ƒ Some classes cannot be cleanly reinstantiated by db4o using either method

ƒ constructor needed to populate transient membersp p

ƒ constructor fails if called with null or default values

ƒ Translators control loading and storing of such objects g g j

ƒ Interface ObjectTranslator

public Object onStore(ObjectContainer c, Object appObject);

public void onActivate(

ObjectContainer c, Object appObject, Object storedObject);

public Class storedClass();

ƒ Interface ObjectConstructor extends ObjectTranslator

public Object on Instantiate(

p j (

Translators

public class Person { String name;

String name;

Calendar birthdate;

transient int age;

public Person(String name, Calendar birthdate) { public Person(String name, Calendar birthdate) {

this.name = name;

this.birthdate = birthdate;

Calendar today = Calendar.getInstance();

( )

int years = today.get(Calendar.YEAR) – this.birthdate.get(Calendar.YEAR);

int diff = birth.add(Calendar.YEAR, age);

this.age = (today.before(birth)) ? age-- : age;g ( y ( )) g g ; }

public String getName() { ... }

public Calendar getBirthdate() { } public Calendar getBirthdate() { ... } public int getAge() { ... }

...

Translators

public class PersonTranslator implements ObjectConstructor { // map Person object to storage representation

// map Person object to storage representation

public Object onStore(ObjectContainer c, Object appObject) { Person person = (Person) appObject;

return new Object[] { person.getName(), person.getBirthdate() };

}

// reconstruct Person object from storage representation

public Object onInstantiate(ObjectContainer c, Object storedObject) {

( )

Object[] raw = (Object[]) storedObject;

return new Person((String) raw[0], (Calendar) raw[1]);

}

public void onActivate(ObjectContainer c Object appObject public void onActivate(ObjectContainer c, Object appObject,

Object storedObject) { }

// return metadata about storage representation public Class storedClass() {

public Class storedClass() { return Object[].class;

} } }

Literature

ƒ db4o Tutorial

ƒ http://www.db4o.com/about/productinformation/resources/

ƒ db4o Reference Documentation

ƒ http://developer.db4o.com/Resources/view.aspx/Reference

ƒ db4o API Reference

ƒ http://developers.db4o.com/resources/api/db4o-java/

ƒ Jim Paterson, Stefan Edlich, Henrik Hörning, and Reidar Jim Paterson, Stefan Edlich, Henrik Hörning, and Reidar

Hörning: The Definitive Guide to db4o, APress 2006

N t W k Next Week

ODMG Standard

•

•

•
