Characterization and photometric membership of the open cluster
NGC 1981
F. F. S. Maia, W. J. B. Corradi and J. F. C. Santos Jr
Instituto de Ciˆencias Exatas, UFMG, Av. Antˆonio Carlos 6627, Belo Horizonte, Brazil
Accepted 2010 May 14. Received 2010 May 14; in original form 2010 April 12
A B S T R A C T
Open clusters belonging to star-forming complexes are the leftovers from the initial stellar generations. The study of these young systems provides constraints to models of star formation and evolution as well as to the properties of the Galactic disc. We aimed at investigating NGC 1981, a young open cluster in the Orion nebula region, using near-IR and BV(RI)C photometric data. We devised a method that accounts for the field contamination and allows to derive photometric membership for the cluster stars. A new cluster centre was determined by Gaussian fittings to the 2D stellar distribution on the sky, and has been used to obtain the radial stellar density profile and the structural parameters. Mass functions were computed for stars inside the cluster limiting radius and total mass estimated from them. Although more easily distinguished by its grouping of six relatively bright stars, an underlying population of faint pre-main-sequence stars is evident in the cluster area. We showed that this population is related to the cluster itself rather than to the nearby Orion nebula cluster. Additionally, a fraction of the cluster low mass stars may have been evaporated from the region in its early evolution leading to the present sparse, loose structure. The estimated parameters of NGC 1981 are core radius Rc= 0.09±0.04 pc, limiting radius Rlim= 1.21±0.11 pc, age t = 5±1 Myr, distance modulus (m− M)0= 7.9 ± 0.1(380 ± 17 pc), reddening E(B − V ) = 0.07 ± 0.03 and total mass m= 137 ± 14 M.
Key words: open clusters and associations: general – open clusters and associations: individ-ual: NGC 1981 – stars: pre-main-sequence – Galaxy: stellar content.
1 I N T R O D U C T I O N
The open clusters’ fundamental physical parameters are important pieces of information for studies on the formation and evolution of the Galactic disc (e.g. Piatti, Clari´a & Abadi 1995; Jacobson, Pila-chowski & Friel 2008; Sestito et al. 2008) and as grounding tests for star formation and evolution models (e.g. Landin et al. 1996; Siess, Dufour & Forestini 2000; D’Antona 2002). Dias et al. (2002, hereafter DAML02) have summarized the available information on open clusters in a major catalogue which continuously expands. In version 2.101 of this catalogue, 1787 open clusters are listed:
out of which 54 per cent have known distance, age and reddening; 24 per cent have also proper motion and radial velocity and only 10 per cent have metal abundance determined. Kharchenko et al. (2005) have created an open cluster catalogue with uniformly deter-mined parameters, among them cluster radius, core radius and age, by means of an automated computational algorithm (the Catalogue
E-mail: [email protected]
1http://www.astro.iag.usp.br/∼wilton
of Open Cluster Data, COCD).2 This catalogue has been used to
investigate the local (<1 kpc) population of star cluster complexes revealing new constraints on the Galaxy’s structure and kinematics (Piskunov et al. 2006).
Sky surveys like Two-Micron All-Sky Survey (2MASS) (Skrutskie et al. 2006) produced large amounts of near-infrared (IR) data and have contributed to the discovery of even more objects. Additionally, several studies have been benefited from 2MASS data base by employing near-IR photometric analyses of structural and populational properties of Milky Way star clusters (e.g. Santos, Bonatto & Bica 2005; Bonatto, Santos & Bica 2006; Pavani & Bica 2007). Because the 2MASS data base covers the whole sky, it al-lows data extraction from spatially unlimited regions. Also, near-IR wavelengths are particularly sensitive to discriminate cluster stars from the contaminating field for young stellar systems (e.g. Santos et al. 2005).
NGC 1981 (OCl 525, C 0532-044) is a young, sparse cluster lo-cated ∼1◦ north from the Orion nebula at Galactic coordinates
= 208.◦09 and b = −18.◦98. As noted by Sharpless (1952), the
Orion nebula seems to be separated from NGC 1981 only as a re-sult of a somewhat nearer obscuring cloud. NGC 1981 depicts the
northern end of Orion’s sword. According to Subramaniam et al. (1995), NGC 1981 and Collinder 70 constitute a possible binary cluster being less than 20 pc apart. The cluster belongs to Gould’s Belt, a planar distribution of O and B stars inclined∼20◦with re-spect to the Galactic plane (P¨oppel 2001, and references therein). In a detailed study of Gould’s Belt (Lesh 1968), the brightest stars in the cluster (HD 37016, HD 37017 and HD 37040) had their spectral types determined (B2.5V, B1.5V, B2.5IV, respectively) and photo-metric distances estimated (all at 494 pc).
Subsequent works emphasized kinematical properties of NGC 1981 stars, among other clusters, aiming at obtaining dynam-ical and structural characteristics of our Galaxy (e.g. Hron 1987). More recently, Kharchenko et al. (2005) performed an analysis of the cluster as a stellar system deriving reddening E(B − V) = 0.05, distance modulus (V− Mv)= 8.16 (d = 400 pc), log t(yr) =
7.50, cluster radius R = 0.◦25 (1.7 pc) and core radius Rc= 0.◦13
(0.9 pc). We should note, however, that the age estimated by Kharchenko et al. (2005) relies upon a single star, as a conse-quence of the method applied, which progressively removes stars with low membership probabilities from the Colour–magnitude di-agram (CMD) by means of an iterative process.
Most studies of the cluster are inserted in more general analyses of the Orion star formation complex. It is part of Orion OB1 asso-ciation, subgroup c, which is 2–6 Myr old and located closer to us (≈400 pc) than the younger Orion nebula by at least 10 pc (Bally 2008). However, such a division in subgroups has been questioned in favour of a continuous star-forming event (Muench et al. 2008). Since NGC 1981 bright stars are early B spectral types, a plausible evolutionary sequence would entail supernovae explosions from O-type progenitors causing the compression of the interstellar medium and formation of the present younger populations. On the kinematical side, Dias et al. (2006) derived membership proba-bilities on the basis of The Second U.S. Naval Observatory CCD Astrograph Catalog (UCAC2) proper motions aided by a statistical method for 158 stars within 15 arcmin of the cluster centre.
Elias, Alfaro & Cabrera-Ca˜no (2009) investigated hierarchical star formation in Gould’s Belt based on the spatial and kinematical distribution of star clusters, either bound star systems or transient stellar condensations with a mean lifetime of ∼10 Myr or less. NGC 1981 was classified by them as a bound cluster in view of its age (∼30 Myr) as determined by Kharchenko et al. (2005). In the present work, we argue that NGC 1981 is indeed younger, as has been shown to be the case for Platais 6 and NGC 2546, which also belong to Gould’s Belt (Elias et al. 2009).
Despite the efforts to better understand the astrophysical pro-cesses occurring in the Orion nebula and its surroundings and their connection with Gould’s Belt, NGC 1981 have not been given par-ticular attention (except for Kharchenko et al. 2005) and, as a con-sequence, its parameters can be improved. In this work, we present Johnson–Cousins BV(RI)Cphotometric observations carried out at
the Observat´orio do Pico dos Dias (Itajub´a, Brazil) along with near-IR photometric data extracted from 2MASS survey to study the open cluster structural properties and stellar content, aiming at a better determination of radius, age, distance, reddening and mass.
This work is structured as follows. Section 2 describes the obser-vational data employed. Section 3 presents the procedure to obtain the cluster centre, a fundamental step to build a reliable radial den-sity profile (RDP), discussed in Section 4. CMDs are employed in Section 5, where a statistical decontamination algorithm is applied to the cluster CMDs, and in Section 6, where a comparison of data
Figure 1.NGC 1981 and the nearby region from IRAS 60-μm band. Other objects in the area and the selected comparison field are also indicated.
with isochrones allows a determination of the cluster’s astrophys-ical parameters. In Section 7 the radial mass function (MF) of the cluster is analysed and in Section 8 the stellar density charts used to map the spatial distribution of stars and their frequency in different CMD regions are described. Further discussions and conclusions are given in Section 9.
2 D ATA 2.1 Near-IR
Vizier3was used to extract near-IR photometric data from 2MASS
in circular fields centred on equatorial coordinates (J2000) α = 05h35m09s and δ = −04◦2554, the cluster centre taken from
DAML02. The data encompass the point sources within R < 55 arcmin, corresponding roughly to four times the estimated visual radius of the cluster. For decontamination purposes, a comparison field was extracted 1◦north-west of the cluster, in a region with the same area and similar absorption as deduced from near-IR (2MASS) and mid-IR (IRAS) images. This choice was preferred over an annu-lar field extraction centred in the cluster because of the nebulosity associated with NGC 1977 towards the south. Fig. 1 shows an image of NGC 1981 and the nearby region from IRAS 60-μm band. The selected comparison field and other objects are also shown.
As photometric quality constraint, the 2MASS extracted data were restricted to unambiguous point sources brighter than specified on the 99 per cent Point Source Catalogue completeness limit (15.8, 15.1 and 14.3 mag for 10σ at J, H and Ks, respectively).
2.2 Optical
CCD BV(RI)C observations were carried out with the Boller &
Chivens 0.6-m telescope at the Observat´orio do Pico dos Dias (Lab-orat´orio Nacional de Astrof´ısica, Itajub´a, Brazil) during the night of 2000 September 21. The CCD detector employed was a 1× 1 k
Table 1. Observation log for NGC 1981.
Cluster/Region Filter Exposure (s) Seeing (arcsec) Airmass
B 1 15 50 3.4 1.2 NGC 1981/CE V 1 20 2.5 1.2 R 1 20 2.4 1.2 I 1 20 3.9 1.2 B 1 15 50 3.1 1.1 NGC 1981/CW V 1 20 2.8 1.1 R 1 20 2.7 1.1 I 1 20 3.4 1.1 B 1 15 50 2.7 1.3 NGC 1981/NE V 1 20 2.6 1.3 R 1 20 2.3 1.2 I 1 20 3.8 1.2 B 1 15 50 3.1 1.1 NGC 1981/N V 1 20 2.6 1.1 R 1 20 2.6 1.1 I 1 20 3.7 1.1 B 1 15 50 3.3 1.1 NGC 1981/NW V 1 20 2.9 1.1 R 1 20 2.8 1.1 I 1 20 4.1 1.1 B 1 15 50 3.3 1.1 NGC 1981/S V 1 20 2.6 1.1 R 1 20 2.7 1.1 I 1 20 3.7 1.1
SITe SI003AB (101) configured to yield readout noise 5.5 e−and gain 5.0 e−ADU−1. The plate scale was 1.22 arcsec pixel−1. The images were obtained using a focal reducer to cover a field of view of 21× 21 arcmin2and were taken with a mosaic setup on six
ad-jacent positions around the cluster centre in order to cover the full extension of the object. To transform instrumental magnitudes into the standard system, 15 objects from Landolt (1992) standard stars catalogue were also observed on the same night, with two standard stars being used for atmospheric extinction correction. Details of the observations are shown in Table 1, where the observed fields are listed along with their exposure times, typical seeing values and airmasses.
The data were reduced using the standardIRAFroutines for aper-ture photometry. Besides the standard reduction steps, the six ad-jacent fields have been aligned and recurrent stars were selected according to their distance to the image centre in each filter. Specif-ically, for every recurrent star, we kept only the measurement of the star closest to the image centre. This choice avoided the vignetting effect introduced on the images borders by the focal reducer. The calibration equations used to transform to the standard system were
b= B + b1+ b2Xb+ b3(B− V ) + b4(B− V )Xb (1) v= V + v1+ v2Xv+ v3(B− V ) + v4(B− V )Xv (2) r= R + r1+ r2Xr+ r3(V− R) + r4(V− R)Xr (3) i= I + i1+ i2Xi+ i3(V − I) + i4(V− I)Xi, (4)
where B, V, R and I are the standard magnitudes and b, v, r and
i are the instrumental magnitudes; Xnis the airmass on each filter.
The subscript coefficients i= 1 . . . 4, were obtained from a 2-pass interactive fitting on each filter with the extinction coefficients (sub-scripts 2 and 4) being fitted first and then used as constants on a
Table 2. Coefficients and rms deviation of the calibration fit.
i B V R I 1 5.79± 0.01 5.35± 0.01 4.53± 0.02 5.05± 0.01 2 0.28± 0.06 0.17± 0.04 0.11± 0.04 0.08± 0.05 3 −0.19 ± 0.01 −0.20 ± 0.02 −0.18 ± 0.07 −0.11 ± 0.02 4 −0.04 ± 0.04 0.15± 0.02 0.19± 0.04 0.07± 0.03 rms 0.03 0.02 0.04 0.03
second fit of the zero-point and colour terms (subscripts 1 and 3, respectively). The derived coefficients and the rms deviation of the fittings to the catalogued magnitudes of the standard stars are shown in Table 2.
The employed data set was that restricted to an error less than 0.04 mag, corresponding to the higher deviations found on the calibration fit. This value implies a magnitude limit of approximately 15 mag and leads to an average magnitude uncertainty of 0.05 mag (taking into account the calibration deviation).
The following analysis involving spatial information were de-veloped using 2MASS data due to its large extraction area, good astrometry and the poor seeing of the optical data, which was em-ployed mostly for CMD comparisons with the near-IR data.
3 N E W C E N T R E D E T E R M I N AT I O N
The sparse aspect of NGC 1981 makes it difficult to estimate its centre, which is an essential step before a reasonable RDP can be obtained. Catalogued centre values are mainly intended for identi-fication purposes and are generally imprecise. Therefore, we have estimated the centre of NGC 1981 by first selecting a region (see Fig. 2) around the coordinates given by DAML02. The search area was limited to the sky around the catalogued centre and did not
Figure 2. Sky chart of NGC 1981 showing the region used for centre de-termination (rectangle), the literature centre (cross), the calculated centre (circle) and the data extraction area for the decontamination method (dotted circle).
Figure 3. Gaussian fittings for the determination of central coordinates. Bin size on RA and Dec. is 3.0 arcmin. Error bars correspond to Poisson statistical errors.
include stars southward of δ= −4.◦55 to avoid the nebulosity and contamination from NGC 1977.
Furthermore, the selected region was divided into bins of right ascension (RA) and declination (Dec.), and star counts were made inside them. We used these star counts to build spatial profiles and fitted a Gaussian function to the stars distribution on RA and Dec., adopting the centre of the fitted Gaussian as the cluster centre coordinate. Fig. 3 shows the Gaussian fitting obtained for bin size 3.0 arcmin and the resulting coordinates of the centre.
This procedure was applied to different bin sizes ranging from 0.25 to 4.00 arcmin and the resulting centre coordinates were used to create histograms showing the most recurrent RA and Dec. values. We adopted these values as the coordinates of the cluster centre. We also found no trends between the coordinates and the bin size. Fig. 4 shows this relationship and the histograms defining the cluster centre.
The adopted coordinates of the cluster centre are α = 83◦4659 = 5h35m08s and δ = −04◦2035. The histogram bin
widths were chosen based on the standard deviation of the centre co-ordinates and account for an uncertainty of approximately 5 arcsec on α and δ. Fig. 2 shows that the calculated centre is 5.32 arcmin north and 0.27 arcmin east from the literature centre. The area used for centre determination and the data extraction region for the de-contamination method (see Section 5) are also shown.
Figure 4. Relation between determined coordinates and the bin size (top). Histograms showing the most recurrent RA and Dec. for the cluster centre (bottom).
4 R A D I A L D E N S I T Y P R O F I L E
The structural properties of star clusters can be derived by means of a projected density profile such as the RDP. The RDPs of star clusters usually follow an analytical profile and can be described by functions with different parameters related to the cluster struc-ture. These parameters include the tidal radius, core radius, core stellar density and background star density. However, young and sparse open clusters like NGC 1981 usually show little overdensity in comparison to the field making difficult the fitting of analytical functions and so the determination of their structural parameters.
In order to circumvent this problem, the density profile was built by superposing RDPs constructed by counting stars inside succes-sive radial rings of fixed width up to 55 arcmin and then dividing by the area of the rings. Ring widths ranged from 0.75 to 2.00 arcmin, with 0.25 arcmin increments. The narrower rings are ideal to probe the core structure of the cluster while the larger ones are better to probe the external regions. This prevents either region of the cluster to be undersampled.
The possible contamination from NGC 1977 stars to the clus-ter population was investigated with separate radial profiles for the northern and southern region of NGC 1981 using semicircles based on the central declination (δ = −04◦2035) determined in Sec-tion 3. Density maps were also built up to the extreme radius of 55 arcmin to allow for the discrimination of subtle stellar density differences between both regions. To obtain a good contrast on the resulting density map, an optimal radial bin of 2.5 arcmin was used to calculate the stellar density around each star. Fig. 5 shows the radial profiles of the north (top) and south (bottom) regions and the corresponding density maps (insets).
Although NGC 1977 is about 30 arcmin southwards it can be seen in Fig. 5 that the contribution from its stars clearly affects the density profile of the southern region of NGC 1981. Since it is not possible to tell the boundaries between the two clusters or readily distinguish their stars, we turned to the northern part of the density profile to investigate the structural properties of NGC 1981 by means of analytical density functions.
Figure 5. RDP of the north (top) and south (bottom) regions of NGC 1981. Stellar density maps of each region are also shown (insets). Radial ring sizes range from 0.75 to 2.00 arcmin. Colourbar on the right represents the stellar density (stars arcmin−2) on the insets.
Figure 6.Two-parameter King-profile fittings. Background level was de-termined beyond 16 arcmin (inset). The dede-termined core radius is indicated. Sky fluctuation is represented by a grey rectangle. Error bars denote 1σ Poissonian fluctuations.
Trials of King profile fittings were made on the density profile using the two-parameter modified density function introduced by King (1962):
f2(R)= σbg+ σ0
1+ (R/Rc)2
. (5)
To provide better convergence, the sky level (σbg) was estimated
as the mean of the radial bins inside the range 16–32 arcmin and further subtracted from each radial ring to derive the central density (σ0) and core radius (Rc) through the two-parameter King function.
The fitting was weighted by the statistical Poissonian errors of the star counts inside each radial ring. Fig. 6 shows the fitting of the two-parameter function and the sky determination (inset) for the northern region of the cluster with the 1σ uncertainties of the fittings. The determined parameters Rcand σbgare also indicated
with their associated errors.
The determined structural parameters were central density σ0 =
2.4± 1.2 stars arcmin−2, core radius Rc = 0.83 ± 0.34 arcmin
and background level σbg= 0.54 ± 0.07 stars arcmin−2. A cluster
limiting radius (Rlim) was estimated by visually inspecting the
ra-dius where stars from the cluster are completely merged with the background. We found Rlim = 11 ± 1 arcmin for NGC 1981.
Us-ing the distance of 380 pc (see Section 6), 1 arcmin corresponds to 0.11 pc.
5 C O L O U R – M AG N I T U D E D I AG R A M S A N D F I E L D - S TA R D E C O N TA M I N AT I O N
CMDs of open clusters usually present well-defined stellar se-quences such as the main sequence (MS), turn-off and giant branch that provide essential information on the physical properties of these objects. However, the characterization of open clusters is often hin-dered by strong reddening and field-star contamination, especially for the objects projected against the Galactic centre or sparsely populated.
The identification of the cluster stars as opposed to the field-star contamination is very important in the study of these objects. As-sessing membership using proper motion data is only available for
a small subset of the known open clusters, particularly the closest ones. An alternative method for disentangling cluster and field stars consists of using photometric data by means of statistical compari-son of star samples taken from the cluster region and from an offset field. Our decontamination procedure is one of these methods and was based on the work of Bonatto & Bica (2007).
5.1 Decontamination procedure
A field-star decontamination procedure was carried out by firstly selecting an appropriate comparison field presenting stellar den-sity and reddening similar to the cluster. While circular annular fields circumscribed to the cluster area are appropriated for clus-ters in dense regions and homogeneous backgrounds, they failed on regions affected by differential reddening or rapidly changing backgrounds. Therefore, an adjacent field with similar reddening was selected for NGC 1981 considering the nebulosity contamina-tion from NGC 1977 in the southern region of the cluster. Regarding the cluster area, the data included stars within the inner 16 arcmin of the determined centre. This central region corresponds to the cluster visual radius, chosen to encompass the brightest B-type stars in the field.
We built 3D CMDs for both cluster and field-stars with J, J−
H and J− Ksas axes. These colours provide better discrimination
among the clusters sequences on the CMD (Bonatto, Bica & Girardi 2004). The diagrams were divided into small cells of average sizes
J = 0.6 mag, (J − H ) = 0.3 mag and (J − K) = 0.3 mag,
corresponding roughly to ten times the average uncertainties in the colours. These cells are small enough to detect local variations of field-star contamination on the various sequences in the CMD, but large enough to accommodate a significant number of stars. The grids in Fig. 8 illustrate these cell sizes.
Initial cluster membership was assigned to cluster stars within each cell based on their overdensity with relation to the field stars, according to the relation P= (Nclu− Nfld)/Nclu. Null probability was
assigned whenever an excess of field stars over cluster stars occurred in a given cell. A subset of the original cluster sample was created by removing from each cell on the cluster CMD, the expected number of field stars as measured in the control field CMD based on their distance to the calculated centre of the cluster. Particularly, each cell on the cluster CMD had the stars most distant from the cluster centre removed and cells without cluster overdensity had all stars inside their limits removed.
In order to account for the initial choice of parameters, we applied the described method for different grid specifications by changing the position and size of the cells in each of the CMD axes. Cell po-sitions were changed by shifting the entire grid one-third of the cell size in each direction. Cell sizes were increased and decreased by one-third of the average sizes in each of the CMD axes. Considering all possible configurations, 729 different grid sets were used to de-rive final membership probabilities by taking the average, median and mode of the membership obtained in each configuration for each star. An exclusion index was also created by noting how many times each star was removed from the sample and then normalizing by the number of grid configurations.
Possible effects of the offset-field selection were investigated by applying the method to three additional comparison fields 1◦distant from the cluster in different directions northward of the cluster. The average, median and mode of the membership of each star, obtained from the multiple grid configurations, were compared once differ-ent offset fields were employed in the decontamination method. The offset-field selection implied mean deviations of 7 per cent on the
average membership, 8 per cent on the median membership and 12 per cent on the mode membership. These values were adopted as the general uncertainty of these statistical indicators. Final mem-bership probabilities were thus assigned to each star by taking the average of the membership from each grid configuration.
The decontaminated sample was obtained by removing stars based on another two complementary criteria. First, stars with aver-age membership value lower than 7 per cent or median membership value lower than 8 per cent were removed. Secondly, stars with exclusion index larger than 50 per cent were removed. The first criterion ensures the removal of stars that could present null mem-bership, based on the uncertainties of each statistical indicator. The second criterion is based on the exclusion index and decontaminate the cluster sequences by removing the expected field population. The exclusion index threshold (50 per cent) was set to provide the removal of approximately the same number of stars removed by the first criterion.
The adopted criteria complement each other well, acting on dif-ferent parts of the CMD and presenting very little overlapping of the removed stars. The first criterion removes stars with low member-ship probability, acting mainly on regions where the cluster and field population are entangled, presenting roughly the same density on the CMD. For NGC 1981, it represents the lower and mid-MS/pre-MS (Pmid-MS/pre-MS). For the second criterion, it is worth recalling that stars where removed from each cluster CMD cell according to the counts from the offset-field CMD and on the distance from the cluster centre. Therefore, the second criterion cleans the cluster sequences from the stars in the outer regions of the cluster and effectively re-moves from the CMD the stars where field population is dominant. It decontaminates the region of the PMS stars, mainly for the fainter regions (J > 10). Fig. 7 shows the decontamination domain of each criterion.
Figure 7. Decontamination domain of the complementary adopted criteria. Note that stars with lower membership probability (left) were removed by the first criterion whereas stars with higher exclusion index (right) were removed by the second criterion. The colourbar indicates both the member-ship probability (left-hand panel) and the exclusion index (right-hand panel) of stars.
5.2 Results on NGC 1981
In order to increase the statistical sample and better probe the field population, the procedure was applied on stars within 32 arcmin from the cluster centre and the resulting decontaminated sample, used in the subsequent analysis, was truncated at the visual radius of the cluster (16 arcmin). This truncation was done because the adjacent southern clouds associated to NGC 1977 yield a very red-dened population which occupy a well-defined region in the CMD (see Section 8). The CMD locus of this reddened population does not overimpose that of most cluster stars, therefore not interfering with the decontamination procedure. However, even inside the vi-sual radius, very reddened stars presenting J− H > 0.9 and J −
Ks> 1.2 appear on the southern region of the cluster (crosses in
Fig. 8). They were not properly sampled by the field population and therefore could neither be excluded by the procedure nor present re-liable membership probabilities. These stars are likely members of NGC 1977. Fig. 9 shows the sky chart of NGC 1981 up to 16 arcmin, comparing the member and field population. Structural parameters derived in Section 4 are also indicated.
The number of stars removed from the contaminated sample does not account for the entire field population because the expected number of field stars measured on the offset field is still higher than the number of excluded stars. On average, each criterion removed 45 per cent of the field population while presenting a common exclusion rate of 5 per cent and a total decontamination efficiency of 85 per cent. Most of the exclusion takes place in the crowded areas of the CMD as 95 per cent of the stars excluded belong to the lower MS (J > 12).
The choice of the offset field accounts for an average deviation of 5 per cent in the number of stars left in the decontaminated subsamples (member stars). Moreover, the fraction of recurring member stars, independent of the offset field, is greater than 87 per cent. Fig. 8 compares cluster, field and decontaminated stars in the
J × J − H and J × J − Ksdiagrams.
5.3 Comparison with proper motion data
Proper motion data from UCAC2 (Zacharias et al. 2004) and UCAC3 (Zacharias et al. 2010) catalogues were used to investi-gate the reliability of the photometric memberships determined for the cluster stars. We selected stars within 15 arcmin from the clus-ter centre, with 2MASS photometry subject to the constraints de-scribed in Section 2.1 and only those with proper motions and their uncertainties. The corresponding samples amount to 159 objects in UCAC2 catalogue and 99 objects in UCAC3 catalogue.
Comparison of the UCAC2 proper motion with our member-ship results was done using the 2MASS designation to identify the common stars between the data sets. This allowed us to use our photometric membership to discriminate cluster and field stars on the vector point diagram (VPD) (Fig. 10, top panel). Although the photometric members present a concentration near (μRA, μDec.)= (0, 0), this is also true for the field stars, as can be more easily seen in the probability distribution histograms (bottom panels).
As the statistical distance between the cluster and field proper motion distributions is small, it is difficult to separate the popula-tions. This effect becomes more accentuated for clusters where there is a large field to cluster member ratio or when the centroids of the proper motion distributions are very close to each other, such as in the case of NGC 1981. This problem has already been discussed by Cabrera-Ca˜no & Alfaro (1990) and S´anchez & Alfaro (2009) which proposed to use the spatial distribution of the stars, in addition to
Figure 8.Cluster (left), field (middle) and decontaminated (right) CMDs using J− H (top) and J − Ks(bottom) colours. Very reddened stars, present in the
southern region of the cluster were marked with crosses. Stars inside the Rlimare marked with dots. The average cell sizes are indicated by dotted grids. MS
and PMS isochrone fittings are also shown on the right-hand panels. Colourbar on the right indicate the calculated cluster membership probability.
Figure 9. Sky chart comparing the removed field population (open circles) and remaining cluster stars (filled circles). Concentric circles represent the core radius and limiting radius, respectively. Very reddened stars are marked with crosses. Colourbar indicates assigned membership probabilities.
their proper motion distribution, to increase the statistical distance between the populations.
In fact, membership probabilities have been estimated for NGC 1981 by Dias et al. (2006) using UCAC2 proper motion of 160 stars within 15 arcmin of the cluster centre. The comparison between these memberships and the photometric memberships de-rived in this work shows a very poor correlation, as can be seen in Fig. 11 (left-hand panel). Although the small statistical distance between the populations may account for the large scattering in the proper motion membership, especially for the low-membership stars, it seems that the derived photometric memberships are, in average, underestimated in relation to the proper motion ones. This trend is still visible when the low-membership stars are removed from both the photometric and proper motion sample, although the correspondence between the samples improves as most of the re-maining stars present membership differences smaller than 20 per cent (right-hand panel).
UCAC3 provided a complete new reduction of the Southern Proper Motion data that improved the proper motions of faint stars by a factor of 2 compared to UCAC2. Although this first release still presents some unsolved problems as described in Zacharias et al. (2010), we present a comparison of our results with proper motion from UCAC3 in Fig. 12. It is clear that UCAC3 VPD is sparser and less populated than that using UCAC2 data. However, it is currently not possible to realize the origin of this lack of stars (see section 8 in Zacharias et al. 2010). Additionally, while our
Figure 10. Correlation between our membership assignment and proper motion data taken from UCAC2 (top). Mean proper motion uncertainties are indicated. Probability distribution function of member and non-member stars are also shown in the bottom panels for RA (left) and Dec. (right) proper motion directions.
Figure 11. Correlation between the proper motion membership from DALM02 and our photometric memberships (left). Stars between the dotted lines have membership differences smaller than 20 per cent (right).
photometric analysis yields very entangled cluster and field popu-lations in UCAC2 VPD, they are much better discriminated when proper motions from UCAC3 are considered (bottom panels of Fig. 10 and 12). Therefore, membership derived from UCAC3 proper motions might be in closer agreement with our photometric analysis.
6 A S T R O P H Y S I C A L PA R A M E T E R S
The optical data was correlated with the IR data allowing the mem-bership probabilities derived from 2MASS data to be assigned to the stars with BVRI photometry. Although shallower than the IR
Figure 12. Similar to Fig. 10, but using UCAC3 proper motions.
sample and presenting larger photometric uncertainties, the opti-cal data provided a larger spectral base for the CMD analysis and additional constraints on the physical parameters.
Astrophysical parameters were determined by means of fittings of Padova isochrones for 2MASS (Bonatto et al. 2004) and Johnson– Cousins (Marigo et al. 2008) filters on the decontaminated CMDs. PMS evolutionary tracks (Siess et al. 2000) were also employed. We chose only isochrones with overshooting and solar metallicity. As initial values for the cluster physical parameters we were guided by the previous studies of Kharchenko et al. (2005) and Bally (2008).
6.1 Age
The absence of evolved sequences in the CMDs due to the cluster youth makes determination of its age unreliable if one uses standard evolutionary models, i.e. those without accounting for PMS stars. PMS isochrone fittings suggest that stars with ages ranging from 1 to 10 Myr co-exist in the cluster and that most high-membership (P > 0.6) stars seem to fall between the young PMS isochrones of 1–5 Myr. This behaviour is also observed when only the innermost stars (inside the limiting radius) are considered. Fig. 8 shows the isochrone fittings on the decontaminated J×(J −H ) and J ×(J −
Ks) CMDs along with the derived membership of stars. Fig. 13
shows the same fittings on the V × (V − I) and V × (V − J ) CMDs. The average age derived for the cluster is 5± 1 Myr, based on isochrone fittings to both near-IR and optical data.
In photometric studies of star clusters, the MS turn-off is the most reliable feature for determining the age of these objects. However, the identification of this CMD feature in very young clusters is uncertain by the scarcity of massive stars and the isochrones lack
Figure 13.NGC 1981 decontaminated CMDs with optical data. Colours and symbols are the same as in Fig. 8.
of turn-off sensitivity. For these objects the turn-on, the CMD locus where the PMS stars joins the MS, is a good indicator of the age of the stellar population.
From the isochrone fittings shown in Fig. 8, it can be seen that NGC 1981 turn-on is at J ≈ 9, corresponding to an age of 5 Myr. Cignoni et al. (2010) devised a method to derive the age of young stellar systems by detecting the PMS turn-on with the luminosity function (LF). The clustering of stars at magnitudes near the turn-on produces a bump in the LF that becomes increasingly fainter as the cluster ages. By using synthetic simple stellar populations they calibrated a relation between the magnitude MVof this luminosity
bump and the age of the population.
The reddening and distance modulus determined in the present work were used to construct LFs with MJ and MV for both the
original and decontaminated sample, which are shown in Fig. 14. In both cases, it was possible to identify a small bump in the LF at
Figure 14.Luminosity functions in the IR (top) and optical (bottom) bands. The turn-on bumps at MV = 1.3 and MJ= 0.8 can be identified on both
original (left) and decontaminated (right) samples.
MJ = 0.8 ± 0.2 and MV = 1.3 ± 0.6. This bump on the LF
corre-sponds to the age 3.3± 2.7 Myr, according to the age calibration with MVby Cignoni et al. (2010).
However, as stated by Cignoni et al. (2010), reliable identification of the turn-on can only be made in populous clusters containing at least≈50 stars brighter than MV= 5 in order to successfully detect
the bump among the Poissonian fluctuations. Therefore, although we should use this result with caution, it is in agreement, within the uncertainties, with the age and distance modulus obtained by means of isochrone fittings.
6.2 Distance and reddening
Although there were small discrepancies in the derived parame-ters (mainly on reddening) from optical versus IR data, the mean determined values of distance modulus J − MJ = 8.0 ± 0.1 and
colour excess E(B− V ) = 0.07 ± 0.03 provided good isochrone fitting in both cases. With those values the true distance modulus is (m− M)0 = 7.9 ± 0.1, where we have used AJ/AV = 0.282 and AV/E(B− V) = 3.09 (Rieke & Lebofsky 1985), resulting in the
distance of 380±17 pc. The uncertainties were set to accommodate the values derived from the optimal fittings on both optical and IR CMDs. These values are similar to the values found by Kharchenko et al. (2005). The almost 50 per cent deviation between optical and IR reddening values deserves further discussion.
Although the literature reddening value provided a good isochrone fitting on the IR data, the reddening value obtained from the V × (V − I) CMD suggests that the extinction in the optical bands is larger by a factor of 2.
Reddening in the optical bands was also determined in a previ-ous work (Maia 2007) by a linear fit to the zero-age main sequence, (ZAMS; Schmidt-Kaler 1982) in colour–colour diagrams as pro-posed by Munari & Carraro (1996). By selecting the diagram most sensitive to reddening (Fig. 15) and limiting our analysis to stars brighter than V = 13, we derived a reddening value of E(B −
V)= 0.11, which is very close to the value obtained from our best
isochrone fitting on the optical data.
The reddening in the cluster direction, as interpolated in the dust maps by Schlegel, Finkbeiner & Davis (1998), is E(B− V ) = 0.24 ± 0.04. Since these maps are sensitive to dust column den-sity, this value can be considered as an upper limit to the cluster
Figure 15. Colour–colour diagram with the optical data showing the ZAMS.
reddening. Also the cluster may be affected by differential red-dening caused by the dust clouds in the region, especially for its southern part.
7 R A D I A L M A S S F U N C T I O N
To analyse the spatial dependence of the MF, the decontaminated LF in the J band determined in Section 6.2 was used to investigate the regions comprehended within the inner 5.5 arcmin (half limiting radius) and within the range between 5.5 arcmin and the limiting radius (11 arcmin) of NGC 1981. The decontaminated LFs were converted into one MF for each region by fitting a mass–luminosity relation (in J band) from the combined PMS and evolved isochrones of 5 Myr at solar metallicity. The power law φ(m) = Am−(1+χ), where A is a normalization factor and χ is the MF slope, was fitted to the data in both regions. The MFs were normalized by the number of stars (N) inside each region (N= 25 for the inner region and N = 81 for the outer region). The outer region MF fit was limited to stars less massive than≈1 M due to its small number of brighter stars. The MFs of the selected regions are presented in Fig. 16, together with the power-law fits and the determined slopes.
Both regions have MFs that are flatter than the Salpeter (1955) one, with slopes χ= 0.65 ± 0.08 (inner region) and χ = −0.44 ± 0.03 (outer region). Total mass inside each region was calculated by summing over selected mass ranges. We obtained for the inner region m = 30 ± 6 M (0.4 < m(M) < 6) and for the outer region m = 107 ± 13 M [0.2 < m(M) < 9). For the inner region, the mass was also calculated by integrating the derived power law over the same mass range yielding m= 38 ± 2 M. We should note that this mass implies an uniform distribution of stellar masses while the observed distribution of the brightest stars suffers from small number statistics.
The relaxation time of a star system can be defined as trelax=
(N/8 ln N)tcross, where tcross = R/σv is the crossing time, N is the
total number of stars and σv is the velocity dispersion (Binney &
Tremaine 1987; Lada & Lada 2003). By using the dispersion in proper motion given by DAML02 for 31 stars within 11 arcmin from the cluster centre with membership probability (derived by DAML02) above 50 per cent and assuming an isotropic distribu-tion of spatial velocities, we estimated a mean velocity dispersion
σv ≈ 8 km s−1. Combining this information with the limiting radius,
Figure 16. Mass function of stars inside the inner 5.5 arcmin (top) and within the range 5.5–11 arcmin (bottom). Power-law fittings, resulting slopes and total mass are indicated. Error bars correspond to 1σ fluctuations.
we get tcross = R/σv = 0.15 Myr and trelax= 0.41 Myr for N =
106 stars.
Although unexpected for such a young object, dynamical evolu-tion can be responsible for rapid collapse of the cluster core causing mass segregation and evaporation of stars in outer regions. This may have occurred in NGC 1981 since the relaxation time of the cluster is much smaller than its age. As shown in Fig. 16, the MF slope is larger for the inner 5.5 arcmin than for the outer 5.5–11 arcmin annular region between the mass range 0.4–1.1 M. This is in apparent contradiction with the expected consequences of dy-namical evolution, i.e. the existence of an excess of low-mass stars and depletion of massive ones (eventually grouped in binaries and/or multiple systems) in the outer region compared to the inner region. However we indeed do not found any star with mass lower than 0.4 M in the inner region but 23 stars in the same mass range in the outer region, in agreement with the mass segregation scenario.
8 S TA R D E N S I T Y M A P S
We have mapped the projected spatial star density and the frequency of stars in different positions of the CMD (Hess diagram). First, we show in Fig. 17 the star density map and the corresponding Hess diagram of a large region around NGC 1981 including the Orion nebula cluster (ONC). Both diagrams were built by dividing the plots in square cells of 32 pixels on a side, which in Fig. 17 correspond to 5.6 arcmin for the spatial map, 0.1 in (J− Ks) and
0.4 mag in J for the Hess diagram. The density diagrams are then smoothed by a cubic convolution interpolation method.
The data comprise all sources extracted from 2MASS cata-logue obeying the photometric quality constraints mentioned in Section 2.1. The ONC dominates the density map southwards of NGC 1981 which the centre, as determined in Section 3, is indicated by a square. Even though, an overdensity compared to the adjacent neighbourhood can be noticed at the position of NGC 1981. The Hess diagram provides evidence that most of the stellar content in the ONC consists of red low-mass stars.
Smaller sky and CMD areas were considered around NGC 1981 in Fig. 18. The square cells of 32 pixels correspond to 2.4 arcmin for the spatial map and 0.02 in (J− Ks), 0.3 mag in J for the Hess
diagram. The spatial map has 1.3× 1.3 deg2 and the associated Hess diagram has been limited to contain only stars with (J −
Ks) < 0.6, thus excluding the reddest stars. Such a colour constraint
clearly separates the spatial map in two regions: a denser star field northwards of NGC 1981 (but including it) and a more rarefied star field southwards of NGC 1981. It clearly reflects the presence of dust revealing a boundary between a heavy obscured stellar field and a region with lower extinction. It also indicates where the reddest stellar population lies in the area. The cut in colour eliminates
Figure 17. Star density map (left) and Hess diagram (right) of a region 3× 3 deg2centred in NGC 1981 (square) based on 2MASS data.
Figure 18. Same as Fig. 17 but for a smaller region centred in NGC 1981 and (J− Ks) < 0.6.
reddened stars by dust but also PMS stars, known to be abundant in the ONC region.
Fig. 19 shows the spatial stellar density plots for the same area as in Fig. 18, but with progressive cuts in star brightness, allowing one to connect the density peaks with different populations char-acterized by a limit magnitude. The plots show the emergence of NGC 1981 as the limiting magnitude varies from J= 15.8 to 10.
Although NGC 1981 is in a region of intense star formation with clouds of dust and gas, it has presently inhabited a relatively dust-free field, perhaps as a consequence of the cluster evolution. Its massive stellar content may have contributed to the energy release into the interstellar medium, either by means of exploding super-novae and/or winds due to radiation pressure. Our study concludes that NGC 1981 is a cluster older than the ONC and NGC 1977, which are still embedded in the parental gas and dust cloud, and
Figure 19.Star density maps for (J− Ks) < 0.6 and variable J magnitude
limit as indicated.
Figure 20. Decontaminated star density map (left) and Hess diagram (right) for a circular region of R= 15 arcmin centred in NGC 1981.
that its structure is best visualized by considering stars brighter than
J= 12.
Fig. 20 shows the same analysis applied to probable members inside a circle of radius R= 15 arcmin centred in the cluster. As a consequence of the method applied for field decontamination, the cluster stellar content is more clearly defined down to the photo-metric limit of the data. The underlying stellar field and the cluster stellar population were indistinguishable in the previous contami-nated diagrams for stars fainter than J= 12 (Figs 17–19). In Fig. 20, a population of PMS members stands out in the Hess diagram.
9 D I S C U S S I O N A N D C O N C L U S I O N S
We investigated the stellar object NGC 1981, a young star cluster in the Gould’s Belt nearby the ONC containing a small population of massive B-type stars. We employed near-IR data from 2MASS to calculate the cluster centre at α = 5h35m08s, δ = −04◦2035
and to subsequently derive the structural parameters from King-profile fittings obtaining a core radius Rc = 0.09 ± 0.04 pc and
central density σ0= (2 ± 1) × 102stars pc−2. A limiting radius of Rlim= 1.21 ± 0.11 pc was also derived from the RDP.
We devised a decontamination procedure based on the method by Bonatto & Bica (2007) to statistically remove the underlying field population from the cluster CMD by using an offset field to sample the background contamination. Tested on NGC 1981 with multiple offset fields, the procedure reliably presented an average field-star exclusion efficiency of 84 per cent, separating cluster members with an average deviation of 5 per cent in the number of stars. It also provides photometric membership for the member stars with average uncertainty of 6 per cent, depending on the selection of the offset field.
By using optical BV(RI)Cdata alongside 2MASS data, we
per-formed isochrone fittings on the decontaminated data and deter-mined average values of reddening E(B− V ) = 0.07 ± 0.03, distance modulus (m− M) = 7.9 ± 0.1(d = 380 ± 17 pc) and age 5± 1 Myr. The relation between the turn-on MVand age (Cignoni
et al. 2010) was also used as an additional check for the cluster age. In this case the age derived was 3.3± 2.7 Myr. The scarcity of bright stars make this value unreliable as sole indicator of age. We use it to infer that the luminosity of the turn-on is consistent with the age and distance modulus found by isochrone fittings.
By comparing our derived memberships with proper motions from UCAC2 catalogue, we showed that while the small statistical distance between cluster and field populations may have hardened their separation in the VPD, the photometric method was capable to discern these very entangled populations. Indeed, by comparing our derived memberships with proper motions from UCAC3, we
were able to distinguish a clear concentration of member stars over a sparse distribution of non-member stars in the VPD.
We derived MFs for stars inside the inner 5.5 and 11 arcmin (limiting radius) and evaluated the total mass inside these regions:
m= 30 ± 6 M and m = 107 ± 13 M, respectively. After fitting
a power law to the data, the calculated slopes χ = 0.65 ± 0.08 (inner region) and χ = −0.44 ± 0.03 (outer region) are flatter than the Salpeter MF, indicating a depletion of low-mass stars in the outer region relative to the inner region. Cluster evolution and mass segregation can explain this effect if the cluster has had time to dynamically evolve. In fact, by using proper motion data from DALM02 for stars inside the limiting radius, we have derived tcross=
0.15 Myr and trelax= 0.41 Myr, meaning that the cluster stars had
time to interact gravitationally with each other forming binaries and/or multiple systems composed by massive stars that settle in the cluster centre and leading to the ejection of low-mass stars towards the cluster outer regions.
The cluster might have undergone mass loss in the earlier stages of the star-forming process leading to the present sparse struc-ture. The energy released into the medium by the evolution of the most massive stars (i.e. by supernovae and stellar winds) may have cleared the cluster from its parental cloud of gas and dust causing a collapse of the core due to the changing gravitational potential and subsequent evaporation of stars in its outer regions.
Through stellar density maps, we discriminated the presence of an embedded red population of stars just south of NGC 1981. These stars are likely members of the young object NGC 1977 and still contaminate the southern population of NGC 1981. These maps also demonstrate the power of the procedure employed to disentangle field stars from the cluster population.
As the majority of young open clusters, NGC 1981 is not expected to live longer than a few Myr, evolving from its actual state of marginally bound system to a loose stellar association and finally dispersing itself into the Galactic disc.
AC K N OW L E D G M E N T S
We thank the referee, G. Carraro, for helping to improve this paper. We also thank C. Bonatto for the insightful comments that helped to develop this work. We thank the Brazilian financial agencies FAPEMIG (grants APQ00154/08, APQ00117/08) and CNPq. We also thank the OPD staff for their support at the observatory. This publication makes use of data products from the Two Micron All Sky Survey, which is a joint project of the University of Massachusetts and the Infrared Processing and Analysis Center/California Insti-tute of Technology, funded by the National Aeronautics and Space Administration and the National Science Foundation. This research has made use of the WEBDA data base, operated at the Institute for Astronomy of the University of Vienna, and of the SIMBAD data base, operated at CDS, Strasbourg, France. This research has made use of Aladin.
R E F E R E N C E S
Bally J., 2008, in Reipurth Bo, ed., Handbook of Star Forming Regions, Vol I: The Northern Sky, ASP Monograph 4, p. 459
Binney J., Tremaine S., 1987, Galactic Dynamics. Princeton Univ. Press, Princeton, NJ
Bonatto C., Bica E., 2007, MNRAS, 377, 1301 Bonatto C., Bica E., Girardi L., 2004, A&A, 415, 571 Bonatto C., Santos J. F. C. Jr, Bica E., 2006, A&A, 445, 567 Cabrera-Ca˜no J., Alfaro E. J., 1990, A&A, 235, 94
Cignoni M., Tosi M., Sabbi E., Nota A., Degl’Innocenti S., Prada Moroni P. G., Gallagher J. S., 2010, ApJ, 712, L63
D’Antona F., 2002, in Geisler D., Grebel E. K., Minniti D., eds, Proc. IAU Symp. 207, Extragalactic Star Clusters. Astron. Soc. Pac., San Francisco, p. 599
Dias W. S., Alessi B. S., Moitinho A., Lepine J. R. D., 2002, A&A, 389, 871 (DAML02)
Dias W. S., Assafin M., Fl´orio V., Alessi B. S., L´ıbero V., 2006, A&A, 446, 949
Elias F., Alfaro E. J., Cabrera-Ca˜no J., 2009, MNRAS, 397, 2 Hron J., 1987, A&A, 176, 34
Jacobson H. R., Pilachowski C. A., Friel E. D., 2008, in Funes J. G., Corsini E. M., eds, ASP Conf. Ser. Vol 396, Formation and Evolution of Galaxy Disks. Astron. Soc. Pac., San Francisco, p. 73
Kharchenko N. V., Piskunov A. E., R¨oser S., Schilbach E., Scholz R. D., 2005, A&A, 438, 1163
King I., 1962, AJ, 67, 471
Lada C. J., Lada E. A., 2003, ARA&A, 41, 57
Landin N. R., Ventura P., D’Antona F., Mendes L. T. S., Vaz L. P. R., 2006, A&A, 456, 269
Landolt A. U., 1992, AJ, 104, 340 Lesh J. R., 1968, ApJS, 17, 371
Maia F. F. S., 2007, MSc dissertation, Universidade Federal de Minas Gerais, Brazil
Marigo P., Girardi L., Bressan A., Groenewegen M. A. T., Silva L., Granato G. L., 2008, A&A, 482, 883
Muench A., Getman K., Hillenbrand L., Preibisch T., 2008, in Reipurth Bo, ed., Handbook of Star Forming Regions, Vol I: The Northern Sky, ASP Monograph 4, p. 483
Munari U., Carraro G., 1996, A&A, 314, 108 Pavani D. B., Bica E., 2007, A&A, 468, 139
Piatti A. E., Clari´a J. J., Abadi M. G., 1995, AJ, 110, 2813
Piskunov A. E., Kharchenko N. V., R¨oser S., Schilbach E., Scholz R. D., 2006, A&A, 445, 545
P¨oppel W. G. L., 2001, in Montmerle T., Andr´e P., eds, ASP Conf. Ser. Vol. 243, From Darkness to Light: Origin and Evolution of Young Stellar Clusters. Astron. Soc. Pac., San Francisco, p. 667
Rieke G. H., Lebofsky M. J., 1985, ApJ, 288, 618 Salpeter E., 1955, ApJ, 121, 161
S´anchez N., Alfaro E. J., 2009, ApJ, 696, 2086
Santos J. F. C. Jr, Bonatto C., Bica E., 2005, A&A, 442, 201 Schlegel D. J., Finkbeiner D. P., Davis M., 1998, ApJ, 500, 525
Schmidt-Kaler Th., 1982, in Landolt-Bornstein New Serires Vol. 2b: Astron-omy and Astrophysics/Star and Star clusters. Springer-Verlag, Newbak, p. 14
Sestito P., Bragaglia A., Randich S., Pallavicini R., Andrievsky S. M., Korotin S. A., 2008, A&A, 488, 943
Sharpless S., 1952, ApJ, 116, 251
Siess L., Dufour E., Forestini M., 2000, A&A, 358, 593 Skrutskie M. F. et al., 2006, AJ, 131, 1163
Subramaniam A., Gorti U., Sagar R., Bhatt H. C., 1995, A&A, 302, 86 Zacharias N., Urban S. E., Zacharias M. I., Wycoff G. L., Hall D. M., Monet
D. G., Rafferty T. J., 2004, AJ, 127, 3043 Zacharias N. et al., 2010, AJ, 139, 2184
