This balance not only makes the air curtain more efficient, but also has other benefits. Most of our air curtains are prepared for the SIRe control system, which automatically manages the air curtain operations. It even adjusts itself to the seasons, and with its weekly calendar, the air curtain operates automatically when needed.
The air curtain has a control panel discreetly integrated into the gable and can be controlled with a separate remote control. The air curtain has an integrated control system and can also be controlled remotely, making it very easy to install and use. The air curtain has a control panel discreetly integrated into the gable and can be controlled with a separate remote control.
Adjustable exhaust grille allows to direct the air for optimal air curtain effect. The elegant design of the air curtain makes it particularly suitable for environments where demands are placed on a high standard of design. The air curtain is installed above the door and the exhaust duct is adapted to the diameter of the door, giving a neat and discreet solution.
The air curtain is mounted vertically and the curved design integrates neatly with the door.
AGS5500
The unit easily tilts onto a bracket used for wall and ceiling mounting. The PA1006 is a compact door heater that heats the incoming air and provides greater comfort inside. Installation on the ceiling or installation in a suspended ceiling leaves the walls free and enables discreet heating.
More detailed information about important factors to consider when choosing a radiant heater can be found on the previous pages. HP can be recessed into suspended ceilings, mounted externally with ceiling brackets, or suspended from a wire. If the heater is suspended from cables, use the four fixing points on the heater.
IRCF is mounted horizontally on the ceiling or on the wall with the supplied bracket. CIR is mounted horizontally on the ceiling or on the wall with the supplied adjustable mounting brackets. Three IH/IHC units can be mounted on the IHT bracket to provide heat in all directions.
The IH/IHC can also be mounted directly to the post using a standard bracket and a U-bolt. Today, we have a complete range of high-quality equipment modeled after the demanding climate of Scandinavia. The heaters are also robust and will withstand harsh treatment in aggressive environments, while at the same time having the lowest sound level on the market.
The brackets can be rotated, which means Elektra can also be used as a portable fan heater. The output can be selected using the output selector on the unit or on the external control panel. The Tiger fan heater is portable, models up to 15 kW can also be hung on the wall.
These models do not have the 230V connection on the back and are equipped with P416-6 connectors. By turning the unit, the water connections will be on the left or right side.
SWS 400V3~
SWS 230V~
TK, TD, basic offer thermostats
On/off control (for slow systems) or proportional control (for faster systems) on the same thermostat. View the guide for the selected SIRe level - Basic, Competent or Advanced and select the valve kit that suits the requirements and characteristics of the system. Complete kit with two-way control and adjustment valve, on/off actuator, shut-off valve and bypass.
Complete kit with two-way pressure-independent control and adjustment valve, on/off actuator, shut-off valve and bypass. Two-way pressure-independent control and adjustment valve ensures that the flow is always constant. Complete kit with two-way control and regulating valve, modulating (stepless) actuator and shut-off valve.
Complete set with two-way pressure-independent control and adjustment valve, modulating actuator (stepless) and shut-off valve. Complete valve sets with multi-function terminal valves enable new functions and ensure consistent flow and precise control using the modulating actuator. Two-way pressure-independent control and regulation valve with modulating actuator and shut-off valve.
Two-way combined control and adjustment valve with on/off actuator, shut-off valve and bypass. VOSP, pressure-independent valve set on/off Two-way pressure-independent control and adjustment valve with on/off actuator, shut-off valve and bypass. VOT, 3-way control valve and actuator on/off 3-way control valve with on/off actuator, DN15/20/25.
VRS20/25
1 Protection against solid objects ≥50 mm 2 Protection against solid objects ≥12.5 mm 3 Protection against solid objects ≥2.5 mm 4 Protection against solid objects ≥1.0 mm. 3 Protection against splashing water 4 Protection against splashing water 5 Protection against water jets 6 Protection against heavy seas. If the sound level is increased by 10 dB, the result is twice as loud (as perceived by the human ear).
It is also useful to know that two equally loud sound sources give an increased sound level of 3 dB. Suppose you have two inlets with two air curtains at each inlet, all four units with a sound level of 50 dB. The first opening will have a total sound level of 53 dB plus an additional 3 dB from the next opening.
Wooden fascia with 15 cm insulation and plaster 0.27 Wooden fascia with 20 cm insulation and plaster 0.25 Wooden fascia with 25 cm insulation and plaster 0.22 Brick fascia with 15 cm insulation and plaster 0.27 Brick fascia with 20 cm insulation and plaster 0.24 Lightweight concrete with 15 cm insulation 0.25 Lightweight concrete with 20 cm insulation 0.2 Sheet metal fascia with 5 cm insulation 0.8 Sheet metal fascia with 10 cm insulation 0.4 Sheet metal fascia with 15 cm insulation 0.3 New construction for low energy house 0.18. Sheet metal pitched roof, with 20 cm insulation 0.24 Brick pitched roof, with 20 cm insulation 0.23 Older building. Sheet metal roof with 5 cm insulation 0.8 Sheet metal roof with 10 cm insulation 0.6 Sheet metal roof with 25 cm insulation 0.2 Windows.
