Display symbols
Content of the box
Installing the telephone
Pick up the device or press the ∑ key. The display will show the time elapsed since the line was connected (after 10 seconds) and the menu. Scroll through the numbers of the list with Ωπ keys to select the name number to call. Select one of the 4 types (Generic, Mobile, Home, Office) and press the [OK] key 2 times to confirm the selection.
Pick up the handset or press the ∑ key to dial the line. The number will be displayed and then switched off. When a call comes in, the mobile phone icon (d) is displayed if the call has not been answered. The name number of the caller is automatically stored in the 1st place of the "Receive" list (Call List submenu). When in the mobile mode, the user can press ∑ key to activate the loudspeaker, allowing the people near the phone to listen to the conversation. The user can then go back to handset mode by pressing ∑ key again or switch to hands-free mode by pressing and holding the ∑ key, holding down the handset and then releasing the ∑ key.
Select a list memo using the Ωπ key and press the [Display] key to display the corresponding entry. The activation code is displayed followed by the entered number, the line is activated in hands-free mode and the displayed sequence is output to the phone. The service is activated. The activation code is displayed, the line is engaged in hands-free mode, and the displayed sequence is output to the phone. The service is activated.
This operation sends the R4 code to the line. The other 2 participants connect immediately and the user can leave the line. The SMS memory can hold up to 20 messages (received + outgoing), 160 alphanumeric characters for each message. The phone can store up to 80 messages (sent + received) / box, depending on the length of the messages. Use the Ωπ keys to select the SMS mailbox number (from 0 to 9) of the user to whom you want to send a message.
Details to display information of the message (destination number, box destination number, date and time of message sending).
Wall intallation
Telephone start-up
Replacing the batteries
Delivery configuration
Technical and functional features
Ring Clock Quick Call Direct Call PABX Prefix PABX Pause Flash CLI on CW Language Lock PIN Reset Code Keypad Lock.
Setting the language
Setting the light on the display
In the "Edit name" submenu, it is possible to display and change the name of a telephone directory number. Press the [Add] key, use the Ωπ keys to select the name-number of the directory you want to add, then press [OK] to confirm. If you selected “Add”, press [OK] key to confirm, select the name-number of the directory to add with Ωπ keys, then press [OK] key to confirm.
Serring time and date
Setting the ringer
- Setting the ringer melody
- Setting the ringer volum level
- Setting the ring mode
- VIP filter
It is possible to choose the ringtone volume level between 3 different levels: minimum (1), medium (2), maximum (3). Press the Ωπ pour buttons to select the desired volume level (from 1 to 3), then press the [OK] key to confirm.
Setting the “Fast call”
Setting “Direct call”
Setting PABX prefix
Setting PABX pause
Setting Flash time
Setting CLI on CW
Setting the keypad lock PIN
Reset code
In both cases, after 10 seconds, the display will show the time elapsed since the line was connected. The phone will return to idle mode and the display will show the current time and date.
Hands-free mode
Answering to an incoming call
Making a call
Normal call
Call with pre-selection
Calling a last number dialled
The display shows the elapsed communication time (mm:ss), then it returns to idle mode. If the line has been busy (via handset or by pressing the ∑ key), it is possible to call the very last number called as follows:.
The Phonebook
- Storing in the Phonebook
- Show numbers of the Phonebook
- Modify numbers of the Phonebook
- Modify names of the Phonebook
- Modify a Ring melody associated to a name of the Phonebook
- Ring filter
- Erase a name of the Phonebook
- VIP list
- Black list
- Free memory
- Storing a number of the CLI list in the Phonebook
- Storing a number of the LN dialled list in the Phonebook
The "Show numbers" option allows the user to display numbers associated with a name from the phone book. In the "Edit numbers" sub-menu it is possible to display and personalize a phonebook number. Erase digits to the left of the cursor via [Erase] or ∂ keys, insert the edits, then press [Save].
Select a speed dial memory key (a number from 0 to 9) using the Ωπ keys and press the [Set] key to confirm. Press the Ωπ buttons to select the new melody number (from 0 to 15), with 0 corresponding to the default melody. Press the Ωπ buttons to select the name to be added to the VIP or blacklist.
If "Call only VIP" is activated, the phone will ring for incoming calls from numbers on the VIP list. If "Blacklist" has been activated, the phone will not ring for incoming calls from numbers on the blacklist. % of free memory and the numbers of the stored items will be displayed.
Dialling numbers of the Phonebook / VIP / Fast call
Caller identification
Call a number of the "Received" call list
The line is busy in hands-free mode and the selected number will be displayed and then dialed.
Erase numbers of the "Received" call list
When in conversation, an acoustic signal will be heard in case of a 2nd call. The 2nd incoming call number is displayed if the service is available and if the phone is set up correctly. Press the ≥ key to put the 1st call on hold and to answer the 2nd call.
Note: When receiving the 2nd call, the user can press the [Options] key to use a list of options that can simplify the automatic management of this function (see section 5.2).
Mute the Microphone
Loudspeaker volume adjusting
Group listening mode
Keyboard lock
Reminders (alarms)
Enter the day by selecting the ddd field and entering a number from 1 to 7. Enter hours and minutes as hh:mm. Select the reminder you want to deactivate/activate with the Ωπ keys and press the [Show] key. Delete the text with the [Clear] or ∂ keys, enter the new text with the alphanumeric keys and press the [OK] key to confirm.
At the programmed time of a reminder, the phone beeps and the accompanying note is displayed. If no action will be taken, the phone will beep for 1 minute, then the icon will be displayed. When the warning signal beeps, it is possible to press [Répéter] to repeat the Reminder 5 minutes later.
Phone info
The phone provides a Network Services menu to use in easy mode services such as Call Forwarding, Fixed Destination Calling, Call Waiting handling and Call Back (CCBS). Some services may not be available on the phone line; please contact Belgacom to ask for more information.
Call forwarding
Call forwarding unconditional
The activation code is displayed followed by the entered number, the line is busy in hands-free mode and the displayed sequence is called. The deactivation code is displayed, the line is busy in hands-free mode and the displayed sequence is called.
Call forwarding if not reply
The line is busy in hands-free mode and the code of the selected service is called. When the user is inactive and a dialed number is displayed, he can press the [Options] key. The line is busy in hands-free mode and the code #31* followed by the number is displayed and called.
The line is busy in hands-free mode and the code *31* followed by a number is displayed and dialed. When in talk mode and if a second call is received, the user can reject the new call by pressing . Press the [Options] key, select "Reject 2nd Call" with the Ωπ keys and press the [OK] key to confirm. This operation sends the R0 code to the line.
Press the [Options] key, select "Terminate call" using the Ωπ keys and press the [OK] key to confirm. This action sends the R1 code to the line.
Call foewarding when busy
Fixed destination call
This service allows you to call a predefined number after the line is busy for a few seconds via the handset or by pressing the ∑ key.
Call waiting (2nd call)
Ring back
PhoneMail and services
- Save a displayed number
- Introducing a pause
- Make a call as visible
- Make a call as anonymous
The following options are available: Call to call the service number Details to display the service number Edit Name to change the service name. In idle mode, if a new message is in PhoneMail, the display will show the b icon and the number of messages to check. When all the messages have been heard, the icon and the information in standby disappear.
This option allows the user to insert a barring code to mask the number of the called user.
Options in conversation mode
- Activate call-back
- Start 2nd call
- Accept 2nd call
- Alternate
- Conference call
- Call transfer
- Reject 2nd call
- Terminate call
- Modify the SMS center numbers
- Assign a name to a SMS Box
- Assign a number to a SMS Box
- Assign a PIN code to a SMS Box
- Activate / Deactivate EATONI function
- Deactivate a SMS Box
- Activate a SMS Box
Activate call transfer by pressing [Options], select "Call transfer" with Ωπ keys and press [OK] to confirm. MAESTRO 2055 can send and receive SMS according to the SMS service requirements offered by Belgacom. To use the SMS service, the Maestro 2055 must be correctly configured as described in par.
Settings to assign drawer name, drawer number (from 0 to 9), PIN code to access the drawer, to activate or deactivate the Eatoni function, to deactivate Boc. Memory available to check % free memory, name of received/written messages. Important: if another SMS terminal is already connected to the line, it is important that the two terminals have different SMS mailbox numbers.
Change the service center number (delete via [Delete] or ∂ keys and enter the new number). Eatoni function (predictive - text system for letter selection) helps the user to write SMS messages. Note: An activated SMS box will display the symbol to the left of its name.
SMS Sending
Reading and Options of the SMS sent
Enter the PIN code, press the [OK] key to confirm and access the SMS messages menu. Clear to clear the displayed message and its parameters. Send to send the displayed message.
SMS Receiving
Reading received SMS
Options menu “Read received”
EATONI (SMS only)
If "Uppercase" has been selected, "Lowercase" will take its place. If "Symbols" has been selected, the user can select the desired symbol via the Ωπ keys and confirm it with the [OK] key. To avoid the spread of these substances in our environment and to reduce the pressure on natural resources, we encourage you to use the appropriate take-back systems. These systems will reuse or recycle most of the materials in your end-of-life equipment in a responsible manner.
If you need more information on collection, reuse and recycling systems, please contact your local or regional waste administration.
