SiSeRHMap v1.0: a simulator for mapped

seismic response using a hybrid model

G. Grelle1, L. Bonito2, A. Lampasi3, P. Revellino2, L. Guerriero2, G. Sappa1, and

F. M. Guadagno2

1

Department of Civil and Environmental Engineering, University of Rome “La Sapienza” via Eudossiana, 18 – 00184 Rome, Italy

2

Department of Science and Technologies, University of Sannio, via Dei Mulini 59/A – 82100 Benevento, Italy

3

ENEA Frascati Research Center, Via Enrico Fermi 45, 00044 Frascati (Rome), Italy

Received: 19 March 2015 – Accepted: 21 May 2015 – Published: 17 June 2015 Correspondence to: G. Grelle ([email protected])
