Mesoscopic surface roughness of ice

crystals pervasive across a wide range of

ice crystal conditions

N. B. Magee, A. Miller, M. Amaral, and A. Cumiskey

The College of New Jersey, Ewing, NJ

Received: 19 December 2013 – Accepted: 19 February 2014 – Published: 28 March 2014 Correspondence to: N. B. Magee (magee@tcnj.com)
