DOES OVERHEAD IRRIGATION WITH SALT AFFECT GROWTH, YIELD, AND PHENOLIC CONTENT OF LENTIL PLANTS?
ANASTASIA GIANNAKOULA1, I. F. ILIAS1, JELENA J. DRAGIŠIĆ MAKSIMOVIĆ2*,
V. M. MAKSIMOVIĆ2 and BRANKA D. ŽIVANOVIĆ2
1 Dept. of Crop Production, AlexandreioTechnological Institute of Thessaloniki, Sindos 57400, Greece 2 Institute for Multidisciplinary Research, 11030 Belgrade, Serbia
Abstract - Overhead irrigation of lentil plants with salt (100 mM NaCl) did not have any significant impact on plant growth, while chlorophyll content and chlorophyll fluorescence parameter Fv/Fm were affected. Under such poor irrigation water quality, the malondialdehyde content in leaves was increased due to the lipid peroxidation of membranes. In seeds, the total phenolic content (TPC) was correlated to their total antioxidant capacity (TAC). High performance liquid chro-matography-mass spectrometry (HPLC-MS) detection showed that flavonoids (catechin, epicatechin, rutin, p-coumaric acid, quercetin, kaempferol, gallic acid and resveratrol) appear to be the compounds with the greatest influence on the TAC values. Catechin is the most abundant phenolic compound in lentil seeds.Overhead irrigation with saltreduced the concentration of almost all phenolic compounds analyzed from lentil seed extracts.
Keywords: Antioxidant activity,chlorophyll, Lens culinaris Medik, lipid peroxidation, overhead irrigation, phenolics
INTRODUCTION
Lentils are believed to have originated and been con-sumed since pre-historic times. They are one of the first crops to have been cultivated. Lentil seeds dat-ing back 8,000 years have been found at archeologi-cal sites in the Middle East. The lentil is considered an “ancient crop for modern times” (Sandhu and Singh, 2007). In the modern and technologically ad-vanced world, among other crops the annual legume lentil crop (Lens culinaris Medik.) is widely cultivated in more than 35 countries of 5 different continents, throughout Europe, Asia, and North Africa. This crop became very popular among the people of the third world countries as an important protein source. The plants are grown for their small lens-shaped edible seeds, which are rich in protein (35-40%) and carbo-hydrates, and are a good source of calcium,
yield in lentil growing regions, worldwide (Muehl-bauer et al., 1995, 2006). Lentils are well adapted to dry land farming, but under severe water stress the crop responds favorably to irrigation.
It is well known that a growing crop has a basic demand for good water quality to produce the maxi-mum yield. Given that water deficiency for crop pro-duction has become a common problem worldwide, new irrigation strategies must be established to use the limited water resources more efficiently. Over-head irrigation might partly mitigate the problem of water deficiency. Unlike surface irrigation systems, sprinklers are more efficient as the quantity of water to be applied can be adequately controlled. Regular watering of crop plants leads to the accumulation of salts in the soil and thereafter emerges as salt stress. High soluble salts can directly injure roots, interfer-ing with water and nutrient uptake. Salts can accu-mulate in plant leaf margins, causing burning of the edges. The most common salt in irrigation water is sodium (Na+). Drought and salt stress are the main
threat to lentil growing. Modern agricultural man-agement practices apply different strategies to alle-viate the impact of these stresses on the quality and quantity of the harvested yield. Supplemental irriga-tion is a viable opirriga-tion that can be used by farmers in the Mediterranean region to increase lentil pro-duction under water shortage conditions. Also, ag-ricultural scientists are trying to improve dry land lentil yields through breeding with the objective of increasing lentil adaptation to environmental stress. The key strategy used to combat drought has been to match crop development with the period of soil moisture availability.
Different physiological and biochemical meth-ods are used for screening the effect of various biotic and abiotic stresses on crop production. Plant growth performance, chlorophyll content in leaves, chlorophyll fluorescence in vivo, malondi-aldehyde (MDA) content and antioxidant activ-ity (total phenolic content and total antioxidant capacity) are tested in this study on lentil plants exposed to overhead irrigation with water supple-mented with salt.
The aim of this study was to investigate if over-head irrigation with salt affects the growth, yield and phenolic content of lentil plants.
MATERIALS AND METHODS
Plant material
Lentil seeds (Lens culinaris Medik. cv. “Dimitra” - local Greek variety) were sown by hand indi-vidually and randomly in thirty-nine experimen-tal plots. A field experiment was conducted from November to June in northern Greece. The experi-ment was established on a sandy loam (Xeroflu-vent) soil consisting of 644 g sand,280 g silt, 76 g clay, 7 g organic C·kg-1 with a pH of (1:2 H
2O) 7.6.
The electrical conductivity (EC) of the saturated soil extract at 0-60 cm depth was 2 dS/m. Nitro-gen and phosphorus were applied as ammonium sulpho-phosphate (20-10-0, F-TOP Ledra Ltd, Thessaloniki) at 100 and 50 kg·ha-1, respectively,
and incorporated into the soil prior to lentil plant-ing. An additional 50 kg N·ha-1 as ammonium
ni-trate (33.5-0-0, F-TOP Ledra Ltd, Thessaloniki) was applied in late March. A set of 21 plants from each plot was foliar-sprayed (to run-off) with a low-pressure hand-wand sprayer two times at 14-day intervals with 100 mM NaCl. The first appli-cation was made 7 weeks after germination. Con-trol plants were treated with water and surfactant (Syngenta, Ontario, Canada).
Lipid peroxidation assay
The level of lipid peroxidation was determined by measuring the amount of malondialdehyde (MDA) produced by thiobarbituric acid (TBA) reaction as described by (Health and Packer, 1968; Hodges et al., 1999). Leaf tissue was homogenized in TBA solution was comprised of 20.0% (w/v) trichloroacetic acid and 0.01% butylated hydroxytoluene, at 4°C.
Absorb-ances were read at 440 nm, 532 nm, and 600 nm. The concentration of MDA was calculated from the dif-ference of absorbance at 400 nm, 532 nm and 600 nm using the extinction coefficient 157 mM-1cm-1 and
Chlorophyll determination
Total chlorophyll concentration (Chl a+b) was calcu-lated from the equations previously reported by Win-termans and Mots (1965). Samples (five discs each) were taken from plants of each treatment with ten fully expanded leaves. Leaf discs were extracted with 96% ethanol in a water bath at 80°C. Full extraction of chlorophyll was achieved when the sample was discolored. The absorption of the extracts was meas-ured at 665 nm and 649 nm with an LKB Ultraspec II spectrophotometer expressed as mg·g-1 FW.
Photosynthetic parameters
Chlorophyll fluorescence indices provide direct information on the functionality and effective-ness of photosynthesis (Lichtenthaler et al., 2005; Maxwell and Johnson, 2000). The chlorophyll fluorescence emission was measured from fully developed leaves in vivo with a pulse-amplitude modulation fluorometer (Plant Efficiency An-alyzer-PEA, Hansatech 2.02, Walz, Effeltrich, Germany), as previously described by Kofidis et al. (2008). The minimum fluorescence yield (Fo)
of the plants adapted to darkness for 20 min was determined under weak red modulated radiation. The mid-part of the front was held in the leaf clip of the fluorometer at a standard distance from the optic fiber probe and a weak 5s far-red (735 nm) pulse was sent to fully oxidize the electron trans-port chain. The maximum fluorescence yield (Fm)
of the dark-adapted plants was reached by expos-ing the PSII to a saturatexpos-ing pulse (0.8s) of white light. The difference between Fm and Fo gave the
variable fluorescence (Fv= Fm−Fo). The maximum
photochemical efficiency of PSII was calculated as the ratio of variable fluorescence to maximal fluo-rescence (Fv/Fm), and represents the efficiency of
open PSII in the dark-adapted state.
Determination of total phenolics content (TPC) and total antioxidant capacity (TAC)
For extraction of phenolics, the lentil seeds were ho-mogenized in 80% methanol at a 1:5 FW:methanol),
using Fast Prep-24 System (M.P. Biomedicals, Irvine, California, USA) for sample homogenization. The homogenates were centrifuged at 10,000 x g for 20 min and supernatants were used for further analyses. Four extracts were prepared for each sample ana-lyzed.
The amount of TPC in extracts was determined according to the Folin-Ciocalteu’s spectrophotomet-ric (2501 PC Shimadzu, Kyoto, Japan) procedure (Singleton and Rossi, 1965) using gallic acid (GA) as a standard for the calibration curve. Samples were mixed with 0.25 N Folin-Ciocalteu reagent, and after 3 min 0.2 M sodium carbonate solution was added and incubated for 60 min. Results were read at 724 nm and expressed as mg eq·GA g-1 FW.
Determination of TAC was done following the ABTS method (Arnao et al., 1999). The reaction mixture contained 2 mM ABTS (2,2-azino-bis-3-ethylbenzothiazoline-6-sulfonic acid), 15 μM hydro-gen peroxide and 0.25 μM horse radish peroxidase (HRP) in 50 mM phosphate buffer pH 7.5. The reac-tions were monitored at 730 nm (2501 PC Shimadzu, Kyoto, Japan) at 25°C until a stable absorbance was obtained due to ABTS radical formation. Afterwards, different concentrations (0.1-0.8 mM) of ascorbic acid (AsA) were added for a standard curve set-up. The adding of the methanol extracts of lentils to the reaction mixture resulted in absorbance decreasing because of ABTS radical depletion. Absorbance al-terations were read from standard curve and results were expressed mg eq AsA· g-1 FW.
HPLC-MS analysisof phenolic compounds
appro-priate guard column. Two mobile phases, A (0.1% formic acid) and B (acetonitrile) were used at a flow of 0.4 mL min-1 with the following gradient profile:
the first 15 min from 10 to 30% B, followed by 15 min reverse to 10% B and with additional 5 min of equi-libration time. For LC/MS analysis, signals for each compound were detected in negative ESI SIR Mode with the following parameters: capillary voltage 3.0 kV, cone voltage -35 V, extractor and RF lens voltages were 3.0 and 0.2 V respectively. Source and desolva-tion temperatures were 140°C and 400°C, respective-ly, with N2 gas flow of 500 L·h-1. The data acquisition
and spectral evaluation for peak confirmation were carried out by the Waters Empower 2 Software (Wa-ters, Milford, USA).
Statistical analyses
An analysis of variance (ANOVA) was performed for the lentil parameters (plant height, dry weight per plant, grain yield-seed weight, and 1000-seed weight) using the SPSS 11.0.1 for Windows statisti-cal package (SPSS, Chicago, USA). For comparison of the means, Fisher’s Protected LSD test at the 5% level was employed. Data for TPC, TAC and specific phenolic compounds were subjected to statistical analysis using Mann-Whitney U nonparametric test (Statistica 6.0; StatSoft, Inc., USA).
RESULTS
Growth measurements
Lentil plant growth performance was not affected by overhead irrigation with salt as compared to the con-trol plots (Fig. 1A), while the dry weight per plant (Fig. 1B) and seed weight per plant (Fig. 1C) were affected after this treatment.
Photosynthetic parameters and MDA content
Although salt treatment reduced the chlorophyll content in the lentil leaves (Fig. 2A), the fluorescent parameters Fv/Fm and Fv/Fo ratio were increased,
pointing to the absence of detrimental salinity effects on leaf photochemistry (Fig. 2C, D). The MDA
con-tent in lentil leaves was increased upon salt treatment (Fig. 2B).
Phenolic pattern of lentil seeds
Total phenolic content (TPC) and total antioxidant capacity of the phenolic compounds (TAC) were de-termined from lentil seeds treated with NaCl. TPC and TAC parameters followed the same pattern dis-playing reduced values upon treatment (Fig. 3A, B). The qualitative and quantitative profiles of the phe-nolic compounds were determined by HPLC (Table 1). HPLC analysis detected phenolic acids (gallic acid and p-coumaric acid) and flavonoids (epicatechin, catechin, resveratrol, kaempferol, quercetin and ru-tin). Among the detected flavonoids, catechin was dominant in all treatments. The content of specific phenolic compounds was decreased by salt treat-ment (Table 1).
DISCUSSION
Fig. 1. Effects of overhead irrigation with NaCl (100 mM) on A-plant height (cm), B-dry weight/plant (g), C-seed weight/plant (g) of Lens culinaris Medik. plants. Vertical bars indicate S.E. (n=4).
Fig. 2. Effects of overhead irrigation with NaCl (100 mM) on A-chlorophyll content chl a+b (mg·g-1 FW), B-the level of lipid
peroxida-tion determined as MDA content (nmol·g-1FW), and C, D-chlorophyll fluorescence parameters (F
o – initial fluorescence, Fv – variable
line with previously reported data (Özdemir et al., 2004, Jovanović et al., 2011). The chlorophyll con-tent and fluorescence were also affected by salin-ity, which is in accordance with one group of data (Masojidek and Hall, 1992; Belkhodja et al., 1994), but opposite to other reports (Robinson et al. 1983; Morales et al. 1992). These conflicting data could be explained by “crosstalk” between different environ-mental stresses such as salt and high temperature (Alexieva et al., 2003). Moreover, the lentil plants screened for salt tolerance in this study were grown under natural field conditions of Mediterranean northern Greece and were probably exposed to dif-ferent environmental constraints. The interaction between these stresses could be taken as a part of
the adaptive mechanisms of plants to survive under saline conditions and high temperatures.
Oxidative stress induced by salinity is closely associated with a diverse assortment of diseases and with depressed levels of antioxidant molecules, low levels of enzymes which form a part of the antioxi-dant defense system and increased levels of oxida-tion products (Fernandez-Orozco et al., 2003). Nat-ural phenolics exert their beneficial health effects mainly through their antioxidant activities (Bravo, 1998; Dueńas et al., 2002, 2003). These compounds are capable of removing free radicals, chelating metal catalysts, activating antioxidant enzymes, and inhibiting oxidases (Heim et al., 2002). The
Fig. 3. Effects of overhead irrigation with NaCl (100 mM) on A-total phenolic content (TPC) in mg eq GA·g-1 FWand B-total
contributions of total phenolics to the total TAC was reported previously (Fernandez-Orozco et al.
2003;Amarowicz et al., 2003;Han and Baik, 2008). Recent data (Amarowicz et al., 2009) demonstrated that phenolic acids from red lentil extract partici-pated in TPC by about 20%, which is in line with our results. In our lentil extracts, the correlation coefficient between potent antioxidant capacities and high contents of phenolic substances in salinity treatments was r2 = 0.76 (data not shown). These
results indicated that different phenolic substances had different degrees of contribution to the overall antioxidant activities (Amarowicz et al., 2004). In addition, it is becoming increasingly apparent that phenolics can display various biological activities through a number of molecular mechanisms and that not all of these activities could be directly re-lated to the molecular function as antioxidants. The data previously reported indicate that the content of phenolic compounds in plants can be changed by salt stress, which is critically dependent on the salt sensitivity of plants (Kim et al., 2007) and the level of salt stress (Yuan et al., 2010).
In conclusion, overhead irrigation of lentil plants should be conducted with care, keeping in mind the quality of the water used for this purpose. Although the concentration of salt applied in this work was relatively high, the growth of the lentil plants was not impaired by overhead irrigation. The absence of salt
effects on plant growth could be explained by a possi-ble high salt tolerance of the lentil cultivar “Dimitra” grown in this Mediterranean area. Interestingly, seed yield was increased upon salt treatment. The phe-nolic content of lentil plants and seeds was reduced by overhead irrigation with salt. It is well recognized that saline water use through sprinklers may cause leaf burn due to the accumulation of toxic quantities of salt, which is very important for sensitive crops that exhibit high rates of foliar salt absorption during periods of high evaporative demand (Minhas,1996). Overhead watering with salt performed in this study did not cause any apparent yellowing of the lentil leaves. These data implicate the use of overhead irri-gation by sprinklers rather than by surface for grow-ing this lentil cultivar in areas hit by salinity.
Acknowledgments - This work was supported by the Alex-ander Technological Educational Institute of Thessaloniki, Greece and the Serbian Ministry of Education and Science (grants 173028 and 173040).
REFERENCES
Alexieva, V., Ivanov, S., Sergiev, I., and E. Karanov (2003). Inter-action between stresses. Bul. J. Plant Physiol., Special Issue, 1-17.
Amarowicz, R., Estrella, I., Hernández, T., Dueńas, M., Troszyńska, A. Kosińska, A., and R. Pegg (2009). Antioxidant activity of a red lentil extract and its fractions. Int J Mol Sci.10, 5513-5527.
Table1. Effects of overhead irrigation with NaCl on concentration of phenolic compounds (µg·g-1 FW)in lentil seeds detected by HPLC.
FW-fresh weight. Values are means ± S.E., n= 4. Means marked with different letters are significantly differ at p = 0.05.
Phenolic compounds Control NaCl
Concentration µg·g-1 FW
Resveratrol 2.79 ± 0.06 a 2.71 ± 0.00 b
p-Coumaric acid 5.93 ± 0.72 a 4.70 ± 0.58 a
Kaempferol 0.59 ± 0.01 a 0.56 ± 0.01 b
Gallic acid 11.65 ± 0.68 a 9.02 ± 0.30 b
Quercetin 1.22 ± 0.63 a 0.23 ± 0.00 b
Catechin 66.86 ± 1.56 a 23.17 ± 5.18 b
Epicatechin 2.73 ± 0.24 a 2.64 ± 0.10 a
Amarowicz, R., Karamac, M., and F. Shahidi (2003). Antioxidant activity of phenolic fractions of lentil (Lens culinaris). J Food Lipids. 10, 1-10.
Amarowicz, R., Troszyńska, A., Barylko-Pikielna, N., and F. Sha-hidi (2004). Polyphenolic extracts from legume seeds: cor-relations between total antioxidant activity, total phenolics content, tannins content and astringency. J Food Lipids.
11, 278-286.
Arnao, M. B., Cano, A., and M. Acosta (1999). Methods to mea-sure the antioxidant activity in plant material. A compara-tive discussion. Free Radic. Res.31, 89-96.
Belkhodja, R., Morales, F., Abadia, A., Gomez-Aparisi, J., and J. Abadia (1994). Chlorophyll fluuorescence as a possible tool for salinity tolerance screening in barley (Hordeum vulgare L.). Plant Physiol. 104, 667-673.
Bor, M., Özdemir, F., and I. Türkan (2003). The effect of salt stress on lipid peroxidation and antioxidants in leaves of sugar beet Beta vulgaris L. and wild beet Beta maritima L. Plant Science164, 77-84.
Bravo, L. (1998). Polyphenols: chemistry, dietary sources, metab-olism, and nutritional significance. Nutr Rev.56, 317-333.
Dueńas, M., Hernández, T., and I. Estrella (2002). Phenolic com-position of the cotyledon and the seed coat of lentils (Lens culinaris L.). Eur Food Res Technol.215, 478-483.
Dueńas, M., Sun, B., Hernández, T., Estrella, I., and M. I. Spranger (2003). Proanthocyanidin composition in the seed coat of lentils (Lens culinaris L.). J Agric Food Chem.51, 7999-8004.
Fernandez-Orozco, R., Zieliński, H., and M. K. Piskuła (2003). Contribution of low-molecular-weight antioxidants to the antioxidant capacity of raw and processed lentil seeds. Nahrung. 47, 291-299.
Ghoulam, C. and K. Fares (2001). Effect of salinity on seed ger-mination and early seedling growth of sugar beet. Seed Sci. Technol.29, 357–364.
Han, H. and B. K. Baik (2008). Antioxidant activity and phenolic content of lentils (Lens culinaris), chickpeas (Cicer arieti-num L.), peas (Pisum sativum L.) and soybeans (Glycine max), and their quantitative changes during processing. Int J Food Sci Technol. 43, 1971-1978.
Health, R. L. and L. Packer (1968). Photoperoxidation in isolated chloroplasts. Arch. Biochem. Biophys.125, 189–198.
Heim, K. E., Tagliaferro, A. R., and D. J. Bobilya (2002). Flavonoid antioxidants: chemistry, metabolism and structure-activi-ty relationships. J Nutr Biochem. 13, 572-584.
Hodges, D. M., DeLong, J. M., Forney, C. F., and R. K. Prange (1999). Improving the thiobarbituric
acid-reactive-sub-stances assay for estimating lipid peroxidation in plant tis-sues containing anthocyanin and other interfering com-pounds. Planta. 207, 604-611.
Jovanović, Ž. S., Maksimović, V. R., and S. R. Radović (2011). Bio-chemical and molecular changes in buckwheat leaves dur-ing exposure to salt stress. Arch. Biol. Sci. 63, 67-77.
Kim, H. J., Fonseca, J. M., Choi, J. H., Kubota, C., and D. Y. Kwon (2007). Salt in irrigation water affects the nutritional and visual properties of romaine lettuce (Lactuca sativa L.). J Agric Food Chem.56, 3772–3776.
Kofidis, G., Giannakoula, A., and I. F. Ilias (2008). Growth, anat-omy and chlorophyll fluorescence of coriander plants( Co-riandrum sativum L.) treated with prohexadione calcium and daminozide.Acta Biol. Cracov. Bot.50, 55-62.
Lichtenthaler, H. K., Buschmann, C., and M. Knapp (2005). How to correctly determine the different chlorophyll fluores-cence parameters and the chlorophyll fluoresfluores-cence de-crease ratio Rfd of leaves with PAM fluorometer. Photo-synthetica. 43, 379-393.
Mamo, T., Richter, C., and B. Heiligtag (1996). Salinity effects on the growth and ion contents of some chickpea (Cicer arietinum L.) and lentil (Lens culinaris Medic.) varieties. J Agr. Crop Sci.176, 235-247.
Masojidek, J., and D. O. Hall (1992). Salinity and drought stresses are amplified by high irradiance in sorghum. Photosyn-thetica. 27, 159-171.
Maxwell, K., and G. H. Johnson (2000). Chlorophyll fluorescence: a practical guide. J Exp. Bot.51, 659–668.
Minhas P. S. (1996). Saline water management for irrigation in India. Agr. Water Manage. 30, 1-24.
Moradi, F., and A. M. Ismail (2007). Responses of photosynthe-sis, chlorophyll fluorescence and ROS-scavenging systems to salt stress during seedling and reproductive stages in rice. Ann. bot.99, 1161–1173.
Morales, F., Abadia, A., Gomez-Aparis, J., and J. Abadia (1992). Effects of combined NaCl and CaCl2 salinity on
photosyn-thetic parameters of barley grown in nutrient solution. Physiol. Plantarum. 86, 419-426.
Muehlbauer, F. J., Cho, S., Sarker, A., McPhee, K. E., Coyne, C. J., Rajesh, P. N., and R. For (2006). Application of bio-technology in breeding lentil for resistance to biotic and abiotic stress. Euphytica.147, 149–165.
Muehlbauer, F. J., Kaiser, W. J., Clement, S. L., and R. J. Summer-field (1995). Production and breeding of lentil. Advances in Agronomy. 54, 283–332.
lipid peroxidation, proline content and antioxidative sys-tem of rice (Oryza sativa L.) under salinity stress. Plant Growth Regul. 42, 203-211.
Parida, A., and A. B. Das (2005). Salt tolerance and salinity ef-fects on plants. Ecotoxicol. Environ. Safety. 60, 324-349.
Robinson, S. P, Downton, W. J. S., and J. Millhouse (1983). Pho-tosynthesis and ion content of leaves and isolated chloro-plasts of salt-stressed spinach. Plant Physiol. 73, 238-242.
Sairam, R. K., and A. Tyagi (2004). Physiology and molecular biology of salinity stress tolerance in plants. Curr. Sci. 86, 407-421.
Sandhu, J.S., and S. Singh (2007). History and origin, In: Lentil-An Lentil-Ancient Crop for Modern Times (Eds. S. S. Yadav, D. L. McNeil, andP. C. Stevenson), 1-11. Springer, Dordrecht, the Netherlands.
Sidari, M., Muscolo, A., Anastasi, U., Pretti, G., Pretti, G., and C. Santonoceto (2007). Response of four genotypes of lentil to salt stress conditions. Seed Sci. Technol.35, 497-503.
Singleton, V. L., and J. A. Jr. Rossi (1965). Colorimetry of total phenolics with phosphomolybdic-phosphotungstic acid reagents. Am J Enol Viticult. 16, 144-158.
Wintermans, J. F. G. M., and A. de Mots (1965). Spectrophoto-metric characteristics of chlorophylls a and b and their pheophytins in ethanol. Biochem. Biophys. Acta. 109, 448-453.
Yuan, G., Wang, X., Guo, R., and Q. Wang (2010). Effect of salt stress on phenolic compounds, glucosinolates, myrosinase and antioxidant activity in radish sprouts. Food Chem.
