SounDigital warrants the original purchaser that this product shall be free of defects in materials and workmanship for a period of ninety (90) days from the original date of purchase. The warranty term is extended to twelve (12) months if installation is performed or approved by an authorized SounDigital dealer (requires proof of installation or approval required on purchase receipt).
This warranty is not transferrable and applies only to the original customer from an authorized SounDigital dealer.
Warranty is void when:
- Defect or problem caused by misuse of the product; - Incorrect installation or non-conformity with the Manual;
- Maintenance made by unauthorized personnel; - Alteration or removal of the seal/serial number; - Exposure to adverse conditions (weather, humidity, etc)
- Damage caused by fall or impact; - Damage caused by natural depreciation;
- Damage caused by transport and/or handling, risks, or smashings.
- Products was purchased more than 12 months ago. Warranty covers:
- Component or material with manufacturing defects; -Workmanship/service needed to repair the equipment.
If you need service on your SounDigital amplifier, send it (freight-prepaid) to SounDigital´s Amplifier Repair Center through an authorized SounDigital dealer (must be accompanied by proof of purchase).
- Any extra information you can get by contacting us at the e-mail address: [email protected]; - In case of manufacturing defect or bad quality of raw material, the max compensation will be the replacement of the product, not allowing any kind of compensation payment;
- New modifications/iterations on a product don't obligate the manufacturer to modify products formerly produced.
Limited Warranty
Customer Service Phone - +55 51 3042 9001 General e-mail: [email protected] Tech Support: [email protected]
Introdução
PrecauçõesCuidado!
Conteúdo da embalegem • 1 Manual do proprietário • 1 Chave Allen 2,5mm • 1 Chave Allen 4mm • 1 Adesivo promocional Canais de contato: Contato Geral [email protected] Suporte Técnico [email protected] Site www.soundigital.com.br Mídias Sociais www.facebook.com/soundigitalsd www.twitter.com/soundigital Fonte de alimentação Tensão de trabalho: 9V á 16V Consumo em repouso: 0,5A Consumo máx. com carga resistiva: 300 A Consumo em programa musical: 150 A total (Fonte + Saída): 70%Potência @ 12,6v ( 0,1% Máx.): 2500W
Potência @ 12,6v (Dobro da impedância/0,1% Máx.): 1375W
Potência @ 14,4v (0,1% Máx.): 3000W
Potência @ 14,4v (Dobro da impedância/0,1% Máx.): 1500W
- / Potência nominal): 90dB
- (Impedância nominal): 0,1%
- (Impedância da potência nominal): 0,08%
- (Impedância da potência nominal): 0,07%
Resposta de freqüência (-1dB) : 10Hz - Resposta de freqüência (-3 dB): 5Hz - Fator de amortecimento (Impedância nominal @100Hz): >1000
Sensibilidade de entrada: 0,5V á 8V Filtro passa alta: 5Hz ~ 80Hz Filtro passa baixa: 80Hz ~ Reforço de graves (Bass Boost) 0 á 12dB
Características Técnicas
Freqüência de reforço de graves 35Hz ~ 55Hz
Resposta de Freqüencia Y: 0,1%/div Marker1 X:---- Hz Y:---% Ch 1 -1% 0,8% 0,6% 0,4% 0,2% 0,0% 20.0 100.0 1.0k 10.0k 20.0k X: 80.0 mV/div Y: 25.0 m%/div 0,25% 0,1% 0,05% 0,025% 0 2500w 2500w 2500w Marker1 X:---- Hz Y:---% Ch 1 -Y: 3.0dB/div 35.0 29.0 23.0 17.0 11.0 5.0 20.0 100.0 1.0k 10.0k 20.0k Marker1 X:---- Hz Y:---% Ch 1 -X X X Dados Dimensionais: Peso: 2,15 kg (4.73 lb)
225mm (8.85")
200mm (7.87")
183mm (7.20") 195mm (7.67") 171mm (6.73")200mm (7.87")
171mm (6.73")
68mm (2.67")Descrição dos painéis
Descrição dos painéis
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 LED LED LED
Instalação
O fusível / disjuntor de proteção deve ser instalado no máximo a 30cm da bateria.
Cuidado!
Capacidade mínima da bateria 150Ah Capacidade ideal de bateria 300Ah Corrente do fusível/disjuntor 150A
Secção do cabo de alimentação e terra 35mm²
Cuidado!
Dicas de instalação
• O aterrameto deverá ser o mais curto possível e deve ser conectado ao chassis do veículo e ao negativo da bateria.
cabos de alimentação ou de saída de audio e de equipamentos elétricos como centrais de injeção eletrônica, motores elétricos e etc.
cortados e provoquem curto circuito. Remova a tinta entre o terminal e a lataria.
Cuidado!
• Escolha um local arejado para a instalação do ventilação sejam obstruidas.
este procedimento pode causar ”looping” de terra (ruidos).
• Utilize alto falantes com potência e impedância
incrementar a performance dos mesmos.
Cuidado!
Cuidado!
e fazem um monitoramento eletrônico de todas as funções, oferecendo ao usuário dos mesmos informações através dos led´s instalados no painel
esta ligado.
- Quando o audio é cortado e este pisca 10 vezes, indica que a tensão de alimentação esta muito baixa (abaixo de 8,9V) ou muito alta (acima de 16V). LED Vermelho
- Quando este pisca durante a reprodução de audio, indica que a tensão de alimentação esta caindo abaixo de 9,5 volts.
- Quando o audio é cortado e este acende constante,
esteja em temperatura normal de uso.
deve ser encaminhado a um de nossos postos assistenciais.
- Durante a reprodução de áudio, faz o monitoramen-to da dismonitoramen-torção no som. Sempre que este acende ou pisca, os alto falantes estão recebendo sinal ou volumeda unidade principal.
- Quando o audio é cortado e este pisca 10 vezes, indica que existe curto ou baixa impedância nos terminais de saída de audio.
Instalação
+12V Fusível 150A Remote +12VCuidado!
Cuidado!
LED LED_Para ajuste do ganho, posicione o volume da unidade principal em 70% do volume total, reproduzindo um programa musical de sua preferência, aumente gradativamente o ganho até a que o LED ‘CLIP’ pisque. Retorne até a posição onde este para de piscar
_Caso, conforme seu gosto pessoal, haja necessidade de incremento de ‘Bass Boost’, certifique-se que o LED ‘CLIP’ não será acionado com esta nova regulagem.
_Algumas unidades principais com tensão alta na saída RCA podem fazer com que a potencia máxima seja atingida mesmo com o ganho posicionado próximo ao mínimo. Neste caso, limite o volume da unidade principal antes do ponto onde o LED ‘CLIP’ começa a piscar.
Dear customer
Congratulations on acquiring your Soundigital! You've just purchased a product of high quality and technology. The Soundigital products are developed to assure maximum efficiency and reliability to your sound system.
Class D Amplifiers:
The main characteristics of Class D amplifiers are: audio quality, efficiency, versatility and compact design.
Here are the advantages of these characteristics: - Audio Quality – Class D amplifiers used to have a limited response in the past and they used to have a worse performance regarding higher frequencies than Class AB amps, despite being more efficient. Introducing new technologies, Soundigital developed a Class D amplifier superior to the Class AB ones in efficiency and performance.
- Efficiency – The Soundigital Class D amplifiers have a total efficiency (power source + output) higher than 70%, assuring a lower than expected battery drain and a heating lower than the expected.
- Versatility of uses –The flat response of all the frequencies of Soundigital amplifiers allows them to be used in all the kinds of systems: SPL, Sound Quality, Trio Eletrico and Pancadao, meeting the needs with extreme quality.
- Compact design – The high efficiency and technology allow our amplifiers to be really compact, making it easy to install them in vehicles where you have limited space.
Important info:
Read this manual and follow its instructions and information carefully. It contains extremely important information to have your amplifier working properly. If you feel the need to contact our Tech Support, you can r e a c h o u r t e c h n i c i a n s t h r o u g h t h e e - m a i l [email protected]
We recommend the use of Soundigital original accessories for a better performance. The crossovers, RCA cables and voltmeters offered by Soundigital follow the same quality standards as our amplifiers, assuring an excellent quality and high power sound system to our customers.
To know our complete line of amplifiers and accessories, visit www.soundigitalusa.com
This “Warning” sign alerts the user of important info. Not following this instructions may cause injuries to the user or damage to the equipment.
Ÿ To prevent injuries to the user or damage to the
amplifier, read all the safety instructions written on this manual;
Ÿ If you have questions about the installation of this
equipment, get in touch with our tech support or with a professional specialized in car audio installation;
Ÿ Before proceeding with the installation of any
electric equipment on your vehicle, unplug the negative (-) terminal of the battery to avoid fires, injuries or damages;
Ÿ Use your sound system safely, exposure to
continuous sound pressure over 85 dB may cause irreversible hearing loss.
Package contents · 1 SD2500.1D Evolution Amplifier · 1 Owner's Manual · 1 Allen wrench 2.5mm · 1 Allen wrench 4mm · 1 Promotional sticker Contacts: Customer Service : +55 51 3042 9001 General e-mail: [email protected] Tech Support: [email protected] Website: www.soundigitalusa.com Facebook: www.facebook.com/comexsoundigital
Technical Specs
Operating Voltage Input Sensivity
Bass reinforcement frequency Current Draw (Stand By)
Current Draw (Music) Max Current Draw
~
-0.5APower @ 12.6v (double impedance/0.1% max THD+N) Power @ 12.6v (0.1% max THD+N)
Power @ 14.4v (0.1% max THD+N)
Power @ 14.4v (double impedance/0.1% max THD+N)
0.1% 0.5V ~ 8V 300 A 150 A 70% 5Hz ~ 80Hz 80Hz ~ 25KHz 2500W 1375W 3000W 1500W 90dB 0.08% 0.07% 10Hz - 20KHz 5Hz - 25KHz 68mm (2.67")
200mm (7.87")
171mm (6.73")
183mm (7.20")225mm (8.85")
195mm (7.67") 171mm (6.73")200mm (7.87")
Y: 0,1%/div THD+N Ratio vs Frequency Marker1 X:---- Hz Y:---% Ch 1 -1% 0,8% 0,6% 0,4% 0,2% 0,0% 20.0 100.0 1.0k 10.0k 20.0k X: 80.0 mV/div Y: 25.0 m%/div 0,25% 0,1% 0,05% 0,025% 0 Output Power 2000w 2000w 2000w
THD+N Ratio vs Amplitude Marker1 X:---- Hz Y:---% Ch 1 -Y: 3.0dB/div 35.0 29.0 23.0 17.0 11.0 5.0 20.0 100.0 1.0k 10.0k 20.0k Vac vs Frequency Marker1 X:---- Hz Y:---% Ch 1 -X X X SD2000. 1D Evolution SD2000. 1D Evolution SD2000. 1D Evolution 1 Channel - 2000w RMS - 1 Ω 1 Channel - 2000w RMS - 1 Ω 1 Channel - 2000w RMS - 1 Ω PowerPowerPower ClipClipClip ProtProtProt Dimensions: Weight: 4.73 lb (2,15kg)
1. Audio Input RCA connector;
2. Audio Output RCA connector;
3. Variable high pass filter control (5Hz ~60Hz);
4. Variable low pass filter control (80Hz ~25KHz);
5. Variable signal gain control;
6. Variable bass boost control (0dB - +12dB);
7. Variable bass reinforcement frequency control (35Hz ~ 55Hz);
8. Negative audio output connector (-);
9. Positive audio output connector (+);
10. Positive power supply connector (+12v) 11. Remote power supply connector (REM); 12. Negative power supply connector (GND); 13. “Protection” LED indicator;
14. “Clip” LED indicator; 15. “Power on” LED indicator.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Unplug the negative (-) terminal of the battery before proceeding with any electrical installation in the vehicle to avoid fire starts, wounds or damage to the amplifier.
Never connect or disconnect the RCA cables with the amplifier on, b e c a u s e i t m a y d a m a g e t h e headunit or the amplifier.
Your Soundigital amplifier needs the correct size of
cables and electrical system
.
The protection fuse/circuit breaker must be installed at a max distance of
.
30cm (1 foot) from the battery
Be careful when drilling holes in the vehicle. Verify if you're not drilling holes in the fuel tank, brake lines or electrical cables of the vehicle.
N e v e r u s e s p e a k e r s w i t h impedance under the nominal impedance of the amplifier or you may damage it.
Gain positioning over the correct spot may cause noise, trigger protection state or damage to the speakers.
Minimum capacity of the battery Recommended capacity of the battery Fuse/circuit breaker size
Size of recommended cable
Use good quality cables (copper if possible) for the connections to the amplifier.
Installation Tips
The ground cable should be the shortest possible and should be connected to the chassis of the vehicle. The surface should be sanded at the contact point to create a clean, metal-to-metal connection between the chassis and the termination of the ground wire.
Keep the RCA cables together, but away from the power or the audio output cables and away from electric equipment such as electronic fuel injection centrals, electric engines, etc.
When passing cables through metallic walls, use rubber grommets to avoid damage to the cable and short circuits.
Choose a proper place to install the amplifier and avoid blocking the side ventilation panels.
Securely mount the amplifier so that it does not come loose in the event of a collision or a sudden jolt to the vehicle. Avoid mounting it on metallic parts of the vehicle, because it may cause an earth loop (you might have noise issues).
Use speakers accordingly to the power and impedance of the amplifier. Verify if the adjustment filters can be used to increase the performance of the equipment.
To avoid unwanted noise in the system, join the ground points of the equipment and audio output to only one point.
Adjust the Low and High pass filters according to your preference and needs of the speakers. If you have any doubts, talk to the speakers manufacturer. If you need to increase the bass response, adjust the frequency and gain of the bass boost according to your preference. Make sure the ‘clip’ LED does not blink with the new setting.
After the end of the electrical installation, connect the negative cable of the battery and, before starting the audio system, check if all connections are correctly done.
In order to adjust the gain, use the headunit volume in 70% of its total, play a musical program of your preference and turn up the gain until the ‘clip’ LED blinks. Set the gain in a position where the ‘clip’ LED doesn't blink.
Some headunits with strong signal output may reach max power even when the gain is next to its minimum. In that case, limit the volume of the headunit right before the point where the ‘clip’ LED starts blinking. The Soundigital amplifiers are micro controlled and
have an electronic monitoring of all of their functions, offering useful information to the user through their leds.
- When constantly on, indicates the amplifier is working. - When the audio is cut off and it blinks 10 times, it indicates the current is under 8.9V or over 16v.
- When it blinks during the audio reproduction, it indicates the input tension is under 9.5 volts. - When the audio is cut off and the led is constantly on, it indicates the amplifier is in protection due to high temperature. Turn the amplifier off until it gets to its working temperature.
- When the audio is cut off and the LED blinks, it means it is defective and must be sent to one of our technical repair centers.
- During the audio reproduction, it makes the sound distortion monitoring. When it turns on, the speakers are receiving distorted signal. So, you should turn down the amplifier's gain or the headunit volume. - When the audio is cut off and it blinks 10 times, it means a short-circuit or low impedance in the audio output.
Blue LED
Red LED
Yellow LED
Remove the paint between the terminal and chassis
2 AWG/35mm² 150Ah 300Ah 150A +12V 150A Fuse Remote +12V
