Electrical and hydraulic connections are all located on the top of the unit facilitating installation and maintenance operations. Careful sound insulation of the unit with suitable sound absorbing material gives all units noise limitations that allow the use of WRL as well. The electronic adjustment, through the use of the external air temperature probe "KSAE" (ACCESSORY) and according to the external conditions, automatically modifies the set point of the water temperature of the system, thus improving the energy efficiency of the system.
Mechanical thermostatic valve The mechanical valve, with external equalizer placed at the evaporator inlet, modulates the flow of gas to the evaporator, according to the heat load, to ensure a correct heating level of the inlet gas. To avoid unnecessary water consumption, it is recommended to install a shut-off device upstream of the water main supply. Thanks to the use of a modern electronic adjustment and of an external air temperature probe "KSAE" (ACCESSORIES), the chiller can adjust the temperature of the water produced, with change of the climatic conditions, which the energy efficiency of the system.
The unit's control panel allows quick setting of the machine's operating parameters and viewing them. The card saves all default settings and any changes, with the installation of the accessory remote control panel PR3 you can remotely control the switching on and off, setting the operating mode (cold-hot) and displaying the overview alarm. PR3: Simplified remote control panel, allows you to perform the basic operations of the device with notification alarm, Remote control with shielded cable up to 150 m.
The minimum flows were calculated based on the characteristics of the water flow control device (differential pressure switch). The correction factor for pressure drop takes into account the different flow resulting from the application of the correction factor for water flow. To calculate the percentage of glycol based on the outside air temperature, enter from the left axis and when you reach the curve, draw a vertical line that will intercept all the other curves; the points obtained on the above curves represent coefficients for the correction of cooling capacity and power input, flows and pressure drops (remember that these coefficients must be multiplied by the nominal value of the size in question);.
To calculate the percentage of glycol based on the produced water temperature, enter from the right axis and when you reach the curve, draw a vertical line that will. The initial stages for "OUTDOOR AIR TEMPERATURE" and "PRODUCED WATER TEMPERATURE" are not directly related, so it is not possible to refer to the curve of one of these stages to obtain the corresponding point on the curve of the other stage. Pc Correction factors for cooling power Pe Correction factors for input power Ph Correction factor for heating power.
Although the graph shows a maximum outside air temperature of -40°C, the operating limitations of the unit must be taken into account. The standard preload value of the pressure of the expansion tank is 1.5 bar, the maximum value is 6 bar. For example: if the level difference H is equal to 20 m, the calibration value of the vessel will be 2.3 bar.
