Cloud information content analysis of

multi-angular measurements in the

oxygen A-band: application to 3MI and

MSPI

G. Merlin1, J. Riedi1, L. C. Labonnote1, C. Cornet1, A. B. Davis2, P. Dubuisson1, M. Desmons3, N. Ferlay1, and F. Parol1

1

Laboratoire d’Optique Atmosphérique, Université de Lille 1, Sciences et Technologies, Villeneuve d’Ascq, France

2

Jet Propulsion Laboratory, California Institute of Technology, Pasadena, CA, USA 3

Department of Meteorology, University of Reading, Berkshire, UK

Received: 14 September 2015 – Accepted: 6 November 2015 – Published: 4 December 2015

Correspondence to: G. Merlin (guillaume.merlin@ed.univ-lille1.fr)
