C O M P R E S S I O N

F L E X U R E

T E N S I O N

(12)

FORNEY Headquarters, Seven Fields, PA FORNEY Machine Brochure, 1950s

Reliability is the foundation of our reputation and our leadership. FORNEY’s policy of uncompromising quality has sustained civil engineering projects around the world.

The FORNEY name “deﬁ nes” the testing industry. Working with DOTs, universities and government regulators, FORNEY designed all the major developments in the industry.

First to introduce:

• Frame rigidity for repeatable data and machine life • Exceed ACI requirements

• Service-free valve system • Full 3-year Warranty • Constant customer support

FORNEY is headquartered in Seven Fields, PA, USA with sales and service networks worldwide.

FORNEY is the leading designer and

manufacturer of equipment for the Construction Materials Testing industry (CMT). Constant research and constant innovation since the 1950s is the basis of our leadership.

(13)

11

724 346 7400 • 800 367 6397

A Machine for all

Specimens

Concrete must be tested at every step of the construction process—from

mix design to core sampling – all deﬁ ned by ASTM, AASHTO, BS and EN.

Most tests are performed on hardened concrete cubes and cylinders. There

is a FORNEY testing machine for every type of specimen. Choose from our

Range of machines or work with our engineers to design one

for your unique application.

C Y L I N D E R S C U B E S B E A M S B R I C K S B L O C K S PAV E R S C A B L E S R E B A R S B R I Q U E T T E S FA S T E N E R S F L AT S S T R A N D S

(14)

C I V I L E N G I N E E R S

S TAT E D O Ts

U N I V E R S I T I E S

P R I VAT E L A B S

(15)

13

Repeatable and precise results

Frames that exceed ACI requirements coupled with sophisticated machine design ensure continued and repeatable results over years and years of use.

Safety of Men and Machines

The safety of all lab technicians and service person-nel is paramount. A FORNEY machine is designed with the operator in mind—novice or experienced, male or female.

Easy to use

Ergonomic design and thoughtful details ensure easy testing, even for new operators. Accessibility to frequently maintained parts ensures faster servicing, often eliminating the need for outside service contractors.

Customer Support

At all levels of ownership, a FORNEY customer is supported with 24-hour troubleshooting advice, starting with FORNEY’s trained and experienced sales professionals. Modern computer systems keep the global network in touch and working smoothly. Professionals need downloadable instruction manuals, shipment tracking and solid technical advice.

(16)

Capacity

in Compression Cylinder

lbf kN

2x4"

Values in psi (MPa)

3x6"

4x8"

6x12"

Best Seller 250,000 1,112 32,813 (226) 14,583 (100) 19,894 (137) 8,842 (61) Standard Series 300,000 1,334 32,813 (226) 14,583 (100) 28,488 (196) 10,610 (73) 400,000 1,779 32,813 (226) 14,583 (100) 28,488 (196) 14,147 (97) 500,000 2,224 32,813 (226) 14,583 (100) 28,488 (196) 17,683 (121) 600,000 2,668 32,813 (226) 14,583 (100) 28,488 (196) 21,220 (146) 700,000 3,113 32,813 (226) 14,583 (100) 28,488 (196) 24,757 (170) Premium Series 300,000 1,334 32,813 (226) 14,583 (100) 28,488 (196) 10,610 (73) 400,000 1,779 32,813 (226) 14,583 (100) 28,488 (196) 14,147 (97) 500,000 2,224 32,813 (226) 14,583 (100) 28,488 (196) 17,683 (121) 600,000 2,668 32,813 (226) 14,583 (100) 28,488 (196) 21,220 (146) 700,000 3,113 32,813 (226) 14,583 (100) 28,488 (196) 24,757 (170) Beam Testers 30,000 133 9,549 (65) 4,244 (29) 2,387 (16) — Block Testers 450,000 2,000 32,813 (226) 14,583 (100) 28,488 (196) 14,147 (97) 500,000 2,224 32,813 (226) 14,583 (100) 28,488 (196) 17,683 (121) 600,000 2,668 32,813 (226) 14,583 (100) 28,488 (196) 21,220 (146) High Capacity Testers 400,000 1,779 32,813 (226) 14,583 (100) 28,488 (196) 14,147 (97) 600,000 2,669 32,813 (226) 14,583 (100) 28,488 (196) 21,220 (146) 800,000 3,600 32,813 (226) 14,583 (100) 63,643 (438) 28,298 (195) 1,000,000 4,500 32,813 (226) 14,583 (100) 79,554 (548) 35,373 (243) 1,500,000 6,700 32,813 (226) 14,583 (100) 107,823 (743) 47,942 (330)

(17)

15

724 346 7400 • 800 367 6397

Part

Cube Brick Beams Blocks

2"

6"

8"

2x4x8"

6x6x20"

Single

In Prism

25,772 (118) 6,944 (48) 3,906 (27) 7,812 (53) 208 (1.434) — — F-25EX 25,772 (118) 8,333 (57) 4,687 (32) 9,375 (64) 250 (1.723) — — F-30EX 25,772 (118) 9,944 (68) 6,250 (43) 9,375 (64) 333 (2.295) — — F-40EX 25,772 (118) 9,944 (68) 7,812 (53) 9,375 (64) 416 (2.868) — — F-50EX 25,772 (118) 9,944 (68) 9,375 (64) 9,375 (64) 500 (3.447) — — F-60EX 25,772 (118) 9,944 (68) 10,937 (75) 9,375 (64) 583 (4.019) — — F-70EX 25,772 (118) 8,333 (57) 4,687 (32) 9,375 (64) 250 (1.723) — — FX-300 25,772 (118) 9,944 (68) 6,250 (43) 9,375 (64) 333 (2.295) — — FX-400 25,772 (118) 9,944 (68) 7,812 (53) 9,375 (64) 416 (2.868) — — FX-500 25,772 (118) 9,944 (68) 9,375 (64) 9,375 (64) 500 (3.447) — — FX-600 25,772 (118) 9,944 (68) 10,937 (75) 9,375 (64) 583 (4.019) — — FX-700 7,500 (51) — — — 25 (0.172) — — LA-270 25,772 (118) 8,333 (57) — 9,375 (64) 333 (2.295) 2,083 (14) — F-401 25,772 (118) 9,944 (68) — 9,375 (64) 416 (2.868) 3,906 (26) 3,906 (26) F-502 25,772 (118) 9,944 (68) — 9,375 (64) 500 (3.447) 4,687 (32) 4,687 (32) F-602 25,772 (118) 8,333 (57) — 9,375 (64) 333 (2.295) 2,083 (14) — LT-704 25,772 (118) 9,944 (68) — 9,375 (64) 500 (3.447) 4,687 (32) — LT-706 25,772 (118) 9,944 (68) 12,500 (86) 9,375 (64) 500 (3.447) 6,250 (43) — LT-708 25,772 (118) 9,944 (68) 15,625 (107) 9,375 (64) 500 (3.447) 7,812 (53) — LT-710 25,772 (118) 9,944 (68) 21,177 (146) 9,375 (64) 500 (3.447) 11,718 (80) — LT-715

(18)

BUILT FOR PRECISION

The load frame of the F-25EX is manufactured from structural steel angles with top and bottom crossheads of solid steel plate. The hydraulic cylinder assembly is mounted to the top crosshead, with force being applied in a downward direction. This design eliminates buildup of foreign material around the piston cylinder area. The machine has a 6 inch diameter power piston. Hydraulic pressure is supplied to the power piston assembly by a two-stage pump. The hydraulic control system is comprised of a single control valve.

GREAT FOR FIELD OR LAB USE

The F-25EX is designed to be placed on a ﬂ oor, used in the ﬁ eld, or it can be bolted to a benchtop. As a Field Model, the F-25EX is compact, extremely rugged, and portable. It’s an excellent choice for testing at the jobsite.

The Best Seller becomes a Laboratory Model when the optional stand is added. The stand raises the controls to an ergonomic operating level. The base of the stand has bolt holes for ﬂ oor mounting.

CYLINDER SPLITTING ASSEMBLY

This test, also known as the Brazilian cylinder splitting test, is performed with the cylinder placed on its side.

CUBE

The F-25EX is used to test cylinders and cubes, as well as other specimens.

LABORATORY MODEL

F-25EX morphs into a Laboratory Machine with the addition of an optional stand. The base has bolt holes for floor mounting.

(19)

17

724 346 7400 • 800 367 6397

Best

Seller

DESIGNED FOR USERS

FORNEY designs machines for efﬁ ciency and easy operation. The F-25EX’s load readout, hydraulic pump and control valve are directly connected to the compression unit. Troubleshoot-ing is simple, allowTroubleshoot-ing the machine to be in continuous use, important in maintaining productivity. The machine’s single unit design permits easy installation and provides portability without disassembling of hydraulic or electrical components. EASY-CHANGE ACCESSORY SYSTEM The F-25EX comes ready-to-go, equipped to test 6x12 inch cylinders. F-25EX (and all the other FORNEY machines) can also be used to test many different samples. With the FORNEY original Easy-Change Accessory System, production levels stay high — saving time, saving money. Shown here on an F-25EX. It can be used on any machine.

Y y

F-25EX, THE BEST SELLER

Field Model, also known as Floor Model

These rugged machines are extremely versatile. FORNEY knows the

way customers use testing machines. The

F-25EX is easy to learn.

the world’s

most popular

machine

STAND

The heavy-duty optional stand is used for mounting the F-25EX at a convenient working height.

(20)

Premium

FX Series

The Premium testers have additional features that make them quieter, cleaner and safer. They will impress your customers and they are ideal for corporate labs.

Premium Features Clean, Quiet and Safe

• Enclosed daylight opening and hydraulic piston • Piston over-extension limit switch

• Two Sturdy Fragment Guard Doors with see through Lexan®_{inserts for superior dust control}

Comfortable operation

• Digital arm adjusts to eye level of operator

• Platen and control valve placed for operator comfort • Writing shelf and separate document holder Easy to Calibrate & Maintain

• FORNEY original Easy-Change Accessory System • Removable front and side panels

• Quick release transducer

• The sophisticated oil system makes it easy to change and monitor oil level, temperature, ﬁ lters and drain valve.

PREMIUM COMPRESSION MACHINE F-250FX

This FX machine is a premium machine for compression testing. The platen and control valve are ergonomically placed for operator comfort and the writing shelf and document holder add convenience. Pump reservoir and drain valve are enclosed within the base. Includes drain valve, site glass, ﬁ lter, piston over-extension limit switch, solid see-through fragment doors, enclosed and

CENTERING BLOCK OPTION

3-year

bumper-to-bumper

warranty worldwide

(21)

19 724 346 7400 • 800 367 6397

Standard

&

Premium

Testers

Standard EX Series

This Series features basic, rugged, time-proven design. These machines provide excellent value. They are ideal for concrete producers, private laboratories and use at the jobsite. Designed for economy, they are the standard around the world.

Standard and Premium Testers are designed by FORNEY, built by

FORNEY and are sold directly from FORNEY. No matter the job,

no matter the budget, these testers exceed regulation standards.

They are ideal for the general lab because of their versatility.

Standard Features

• Frame is manufactured from solid steel into a one-piece, welded unit that exceeds ACI 363R recommendations. Steel fragment guard doors • High Pressure Safety valve

• Hydraulic power piston assembly is bolted to the bottom of the load frame with force applied in upward direction

• The FORNEY original Easy-Change accessory holding system

• 24-month warranty on all metal parts, 12-month warranty on electronics and hydraulics

• ¾ horsepower pump and electrics available 110/220 VAC

se of their versatility.

STANDARD COMPRESSION MACHINE F-30EX

EX Series machines are economical, rugged, accurate and dependable. This F-30EX has a 300,000 lbf capacity frame and the 2-channel Co-Pilot Digital Indicator.

(22)

2,224 kN

600,000 lbf

2,668 kN

BS1610, 1881 CARRIER BRACKET BLOCK TESTER F-502

This extended frame machine tests one or two blocks in prism and capable of loading a block to 500,000 lbf (2,224 kN). The carrier bracket moves the platen in and out of the machine.

CARRIER BRACKET

FORNEY Block Testers have solid steel one-piece welded frames.

In addition, it’s important to have sufﬁ cient daylight for the sample;

the Carrier Bracket (moves heavy platen in and out) must be sturdy

and also move smoothly; the Holding Stem must not only move the

platen to the right level, but must also provide complete safety

for the operator. FORNEY Block Testers have all these

(23)

21

724 346 7400 • 800 367 6397• 800 367 6397

FORNEY manufactures Block Testers to meet three important

standards: ACI, ASTM and FORNEY’s own! FORNEY has been designing

and manufacturing Block Testers for over 50 years and the FORNEY

Series is the largest in the industry.

Block

Testers

BLOCK TESTER F-401

This machine is designed to test full-size single block. It is capable of loading a block to 450,000 lbf (2,000 kN). The holding stem is essential for raising and lowering the block platen.

(24)

The FORNEY Beam Tester Series is speciﬁ cally designed to test the ﬂ exure

of beams and the compressive strength of all low-strength specimens.

These machines are versatile and can be conﬁ gured to suit any lab or ﬁ eld

situation. Ideal for testing concrete used in highways and airport runways.

features unique built-in handles. It is the only truly portable Beam Tester in the industry that meets ASTM code.

becomes a Laboratory Model. The controls are at a convenient working height and it is bolted to the ﬂ oor for added stability.

BEAM TESTER – DESKTOP MODEL

BEAM TESTER – LABORATORY MODEL

The Laboratory Model tests beams with either center point or third point loading. It can be used to test many other low-strength specimens using the FORNEY Easy-Change Accessory System.

(25)

23

724 346 7400 • 800 367 6397

Beam

Testers

FORNEY Beam Testers can also be used to test many other low-strength samples such as grout, pavers, cubes and other materials with failure below 30,000 lbf. The large selection of accessories and the FORNEY Easy-Change Accessory System makes accessory changing fast and safe.

and attached to any compression machine. This is an economic solution that covers several compression needs at all at once because one Digital is driving two frames!

BEAM TESTER ACCESSORY MODEL

The Accessory Model is combined with the FORNEY F-25EX testing machine and the exclusive TestPilot Digital Indicator. The TestPilot operates both frames so only one pump and one valve are needed—an economical choice. Combining the Accessory Model Beam Tester with another machine saves time because cylinder and beam accessories can be set up simultaneously—no time is wasted changing platens.

MANUAL BEAM TESTER

This hand-operated pump is ideal for testing in areas where electricity is unavailable.

BEAM TESTER EQUIPPED WITH 2-INCH CUBE ASSEMBLY

A quick and easy change of accessories allows 2-inch cubes to be tested—the Beam Tester’s lower capacity is ideal for tests on mortar cubes as well as other low-strength samples.

L ESTER t l b B A T w m D b o c M m a s c

(26)

The FORNEY Universal Testing Machines are dual purpose, testing

in tension or compression. Ideal for rebar.

FORNEY designs and builds these machines assuring you of

single-source responsibility and virtually maintenance free operation. All FORNEY

Universal Testing Machines exceed ASTM and ACI speciﬁ cations for frame

rigidity and are backed by FORNEY technical support services.

UNIVERSAL TESTER LT-920

With a capacity of 400,000 lbf in compression and 200,000 lbf in tension (1,800 and 900 kN), this machine can pull rebar up to 35 mm diameter. The separate console provides protection from vibration and houses sophisticated equipment.

(27)

25

724 346 7400 • 800 367 6397

FORNEY’s load frame delivers superior distortion resistance and testing

accuracy. That’s because we use a solid welded steel frame—no tie rods

to come loose or out of alignment.

Versatile Combination

When paired with the 4-Channel TestPilot Digital Indicator, all FORNEY

Universal Testers measure:

• Force (to full capacity)

• Vertical Displacement

• Horizontal Displacement

• Force (in low range)

Universal

Testers

GRIPPERS

FORNEY Universal Testers pull a large variety of samples, such as this one-inch-diameter rebar (size: No.8). FORNEY builds Universal Testers that can pull rebar in the ASTM range of No. 3 to No. 18.

UNIVERSAL TESTER LT-950

A real laboratory powerhouse, the LT-950 has a capacity of 400,000 lbf in both tension and compression. It is equipped with Hydraulic Grips for Civil Engineeriing and Hydraulic Grips for Metallurgical use.

(28)

Capacity Max. Mat'l Size (Daylight) Tension Values in lbf (kN) Compression Values in lbf (kN) Tension Values in inches (cm) Compression Values in inches (cm)

Cement Briquette & Cube Tester Flats & Rounds .75in (19mm)

20,000 (90)

60,000 (270)

Optional 6 dia x 22 height (15.3 dia x 55.9 height)

Cylinders, 2in Cube, Flexural Flats & Rounds 0.79in (20mm)

60,000 (270) 60,000 (270) 2.25 x 1 x 30 (5.7 x 2.5 x 76.2) 6 dia x 19 height (15.3 dia x 48.3 height)

Rebar Tester up to 1.25in (32mm) Manual Grip 120,000 (533) 120,000 (533) 14 to 32.5 (35.6 to 82.6) 6 dia x 28.9 height (15.3 dia x 73.3 height)

Rebar Tester up to 1.4in (35mm) Manual Grip 200,000 (900) 400,000 (1,800) 3 x 1 x 22 (7.6 x 2.5 x 55.9) 12 x 18 x 18.5 (30.5 x 45.7 x 47)

Rebar Tester up to 1.4in (35mm) Hydraulic Grip 200,000 (900) 400,000 (1,800) 3 x 1 x 22 (7.6 x 2.5 x 55.9) 12 x 18 x 18.5 (30.5 x 45.7 x 47)

Civil Engineering Applications Hydraulic Grip 400,000 (1,800) 400,000 (1,800) 4 x 1 x 21 (10.2 x 2.5 x 53.3) 12 x 18 x 18.375 (30.5 x 45.7 x 46.7) Metallurgical Applications Hydraulic Grip 400,000 (1,800) 400,000 (1,800) 4 x 1 x 23 (10.2 x 2.5 x 58.4) 12 x 18 x 21.5 (30.5 x 45.7 x 54.5) Metallurgical Applications Hydraulic Grip 600,000 (2,700) 600,000 (2,700) 4 x 2 x 28 (10.2 x 5.1 x 71.1) 12 x 18 x 21.5 (30.5 x 45.7 x 54.5)

Civil Engineering Applications Hydraulic Grip 600,000 (2,700) 600,000 (2,700) 4 x 2 x 27 (10.2 x 5.1 x 68.6) 12 x 18 x 27 (30.5 x 45.7 x 68.6)

(29)

27 724 346 7400 • 800 367 6397 Rebar Horiz. Opening Values in inches (cm) Lower Platen Values in inches2_(cm2₎ Crosshead Adjustment

Values in in/min (cm/min)

Frame Dimensions Values in inches (cm) Remarks Product Number Optional 12.5 (31.8) 33.2 (214.2) Manual 41.6 x 28 x 68.5 (106 x 71 x 174) A, C LT-31 No. 3 - 6 10 - 20mm 15 (38.1) 33.2 (214.2) Elect. 7.5 (Elect. 19.1) 28.3 x 22 x 68 (72 x 56 x 173) A, B LT-60 No. 3 - 10 10 - 32mm 21 (53.3) 33.2 (214.2) Elect. 5.25 (Elect. 13.3) 36 x 26 x 94 (91.4 x 66.0 x 238.8) B LT-120 No. 3 - 11 10 - 35mm 13 (33) 248.6 (1,604) Hyd. 8 (Hyd. 20.3) 34.5 x 18 x 95 (88 x 46 x 241) B, D, E LT-900 No. 3 - 11 10 - 35mm 13 (33) 248.6 (1,604) Hyd. 8 (Hyd. 20.3) 34.5 x 18 x 95 (88 x 46 x 241) B, D, E LT-920 No. 3 - 14 10 - 45mm 13.25 (33.7) 243.8 (1,573) Hyd. 8 (Hyd. 20.3) 44 x 26 x 113 (112 x 66 x 287) B LT-950 No. 3 - 11 10 - 35mm 13.25 (33.7) 243.8 (1,573) Hyd. 8 (Hyd. 20.3) 44 x 26 x 120 (112 x 66 x 305) B, D, E LT-951 No. 3 - 18 10 - 55mm 13 (33) 243.8 (1,573) Hyd. 8 (Hyd. 20.3) 40 x 30 x 125 (119 x 76 x 318) B, D, E LT-1000 No. 3 - 18 10 - 55mm 13 (33) 243.8 (1,573) Hyd. 8 (Hyd. 20.3) 40 x 30 x 136 (119 x 76 x 345) B LT-1000 Notes:

A Daylight without optional upper platen B Two piece testing machine

console is 45.5 x 46.5 x 62" (116 x 118 x 157 cm) 1,900 lbs (862 kg)

C One piece testing machine D Lower platen optional

(30)

Pipe Tester Kits

Capacity Product 300 – 30,000 lbf PT-0015 600 – 60,000 lbf PT-0030 1000 – 100,000 lbf PT-0050 1500 – 150,000 lbf PT-0100 2000 – 200,000 lbf PT-0150 3000 – 300,000 lbf PT-0200 4000 – 400,000 lbf PT-0250 5000 – 500,000 lbf PT-00715

The FORNEY Pipe Tester Kit is the control unit for a test frame.

The Kit, plus a Frame which is often constructed by the customer

himself, becomes a complete Tester.

Pipe

Testers

PIPE TESTER FRAME

FORNEY manufactures a Pipe Tester frame to any requirement and customers often make their own.

PIPE TESTER KIT

The Pipe Tester Kit consists of a steel weatherproof cabinet which houses the digital indicator, ¾ hp pump and 5-gallon reservoir. Included with all kits are hydraulic ram and hoses and mounting cylinders. Lower capacity machines typically use a single ram, but a double ram is generally used for capacities of 200,000 lbf and higher. This pipe tester kit is easy to retroﬁ t.

30,000 to 500,000 lbf

(31)

29

724 346 7400 • 800 367 6397

The FORNEY High Capacity Series was speciﬁ cally designed for

research and production testing of high-strength materials. Available

in two frame types, both have the highest level of rigidity which will

virtually eliminate frame elongation as a test parameter. They are ideal

for research labs.

HIGH CAPACITY TESTER LT-704

The four post design allows a variety of sample sizes and shapes to be tested and has the ﬂ exibility to test blocks in prism as well as specimens of unusual height. The posts are made of High Grade Steel. It is designed for ﬂ oor level installation, eliminating the need for costly pit foundations. The four-post frame is open on all sides for specimen inspection and easy cleanup. The compression platen is positioned waist high to make loading of heavy specimens easier for a single operator.

High Capacity

Testers

HIGH CAPACITY TESTER LT-806

This machine features a distortion-resistant load frame which has solid steel crossheads welded to solid steel side members, forming a massive one-piece load frame. All the load frames in this series are open front and rear for quick loading and unloading of test specimens. The platen is conveniently positioned waist high and safety metal mesh doors ensure operator safety.

1,500,000 lbf

(32)

CREEP TESTER

This custom designed 100,000 lbf capacity tester was designed to hold ﬁ ve 6x12 inch cylinders stacked longitudinally. The FORNEY design, with a range of 22,500 to 100,000 lbf, closely simulates the anticipated loading age conditions so that accurate long-term measurements can be recorded. Deformation of the cylinders is monitored throughout the test via a mechanical bourdon type gauge.

Tie Tester for prestressed concrete railroad ties. Note the separate loading mechanism.

SPEEDLOADER – ROTARY

For production-line speediness, the Rotary Speedloader allows the operator to load a specimen while the current specimen is being tested. Designed to be used with the FX Series and the unique FORNEY Beer Mug (See page 76)

HIGH PRODUCTION TEST CELL

This FORNEY innovation facilitates speedy testing of samples and automated removal of debris—perfect for the facility where high productivity is a primary focus.

(33)

31

724 346 7400 • 800 367 6397

Special

Testers

FORNEY engineers will adapt any machine to meet a speciﬁ c need.

Working with professionals in Civil Engineering, DOTs, Univeristies,

Manufacturing Sectors and Government Agencies, creative yet practical

and cost effective solutions to complex problems happen every day.

REBAR WITH T-CAP TESTER

This custom designed machine was adapted from a FORNEY Universal Tester with Extended Frame in order to test Rebar with T-Caps in tension. Working with a customer, the FORNEY engineers knew from the start that maintaining frame rigidity would be extremely important. Taking a normal frame and doubling its overall height requires more than simply stretching the drawings—a host of calculations goes into creation of a custom-designed machine.

R-VALUE (STABILOMETER) TESTER

This custom designed 60,000 lbf capacity tester was speciﬁ cally designed with larger-than-standard opening to accommodate a Stabilometer. It is an economical solution to a common need.

(34)

DR500

Automatic Systems

Analog Gauges

EN 12390-3 679 12390-5 1340:4 12390-6

DR500

The DR500 has a six-digit display and one channel. A tough and sturdy unit, easy to learn.

ANALOG GAUGE

For site conditions too harsh for electricity.

AUTOMATIC CONTROLLER

This Tester is shown with the FORNEY Automat-ic mounted directly to the machine frame. It runs automatically from the beginning of the test until specimen failure. Results are viewed on screen or they can be downloaded via RS232.

Automatic Systems

FORNEY Automatic Systems allow true “one touch” operation. Settings are entered on the keypad or on a PC. The testing machine takes over and runs the test, automatically calculating the results at the end. Each test is the same. Automatic repeatability really does give MORE accurate testing and data management than a human operator.

DR500

• Easy to Use • Economical

The DR500 is famous for its stable, drift-free readout and accurate calibration. The single-channel, 6-digit display offers a 16-point calibration feature. Accurate: ±0.5% from 1% to full capacity. The DR500 will display live load with peak load captured at the end of each test.

Analog Gauges

Many test sites are too harsh for electric digitals. FORNEY has analog gauges in single and dual-gauge versions with capacities to match the Testers.

Remember that older compression frames can be

retroﬁ tted with any new, up-to-date digital indicator.

(35)

33

724 346 7400 • 800 367 6397

FORNEY has a digital indicator for every application and price range.

Options range from simple function, easy-to-use “black box” types to

sophisticated PC-based digital systems.

Digitals

TESTPILOT

FORNEY’s most versatile. Four channels allow two machine frames to be run with one digital. It’s ideal for retroﬁ tting to your existing frame or when using a combo.

CO-PILOT

Two channels and easy operation. Great for a lab that needs precision, but wants to keep an eye on budget.

PLUG & PLAY

FORNEY’s Co-Pilot and TestPilot are sophisticated instruments, yet easy to use. The Power Connector, Computer Connector (RS232), LVDT and Transducer are all conveniently located.

TestPilot

• Two Load Channels and Two Strain Channels • Multiple Language Options

• Download to a printer or to any PC

The TestPilot is a four-channel system that includes two selectable load channels to capture load data from one or two load frames; and two additional channels to capture data for strain and/or displacement commonly used when collecting data from compressometers or extensometers or other LVDTs.

Co-Pilot

• Two Load Channels • English and Spanish

• Download to a printer or to any PC

The Co-Pilot has the same look and feel as the TestPilot and it is a good choice for those who prefer to keep it simple. It has all the features needed for everyday testing.

(36)

Test Pilot Co-Pilot DR500 Analog Gauge Part Number TA-1253 TA-1252 TA-1248 —

No. of Load Channels 2 2 1 —

No. of Encoder Channels 0 0 0 —

No. of Strain Channel 2 0 0 —

Load Units lb kN kg Yes Yes Yes Yes Yes Yes Yes — — — — —

Load Rate Units

Numerical and Rate Deviation

Graphical Display Yes - Lb/min — Kg/sec Lb/sec Kn/sec Yes Yes Yes Yes Yes Yes — — — — — — Stress Units psi (Lb/in2₎ MPa (N/mm2₎ Ksc (Kg/cm2₎ Yes Yes Yes — — — — — — — — —

Stress Rate Units

Numerical and Rate Deviation Graphical Display — — — psi/sec Kg/cm2_/sec MPa/sec Yes Yes Yes — — — — — — — — —

Display Peak Load Yes Yes Yes Yes

Display Peak Stress Yes — — —

Display Load Resolution Selectable Selectable

Selectable at

Calibration —

Printer (Serial or Parallel) Download or Print Download or Print — — Display X-Y Graph Yes - Download — — —

Auto Store Yes Yes — —

Tests Stored in Memory 500 500 None — Specimen I.D. Yes - 0-999,999 Yes - 0-999,999 None — Auto-Increment Specimen I.D. Yes - Numeric Yes - Numeric — — Does calculations and has

extra data storage for the

following specimen types —

Cylinder Cube

Beam (center point) Beam (3rd point) Rebar Block Cross-sectional Area Yes Yes Yes Yes Yes Yes Yes — — — — — — — — — — — — — — — — — — — — —

(37)

35

724 346 7400 • 800 367 6397

Test Pilot Co-Pilot DR500 Analog Gauge

Specimen Weight Yes — — —

Specimen Age Yes — — —

Sample Break/Peak Sensitivity

Preset to 50% of Peak Load

Preset to 50%

of Peak Load Fixed —

Print Options Current test Stored tests Selected test X-Y Graph

Send stored tests (RS232)

Yes Yes Yes Yes Yes — — — — Yes — — — — — — — — — —

Print Date/Time Yes Yes — —

Tension Yes — — Yes

Correction Factor (ASTM C39) Yes — — —

Perform Specimen Analysis Yes — — —

Negative Load Display Yes Yes Yes —

Capacity Range 7 Digits 7 Digits

0 - 99,999+0

placeholder Range speciﬁ c

Accuracy 1% - Full Scale +/-.5% 1% - Full Scale +/-.5% 1%-Full Scale +/-.5% 10%-Full Scale+/-1% Linear Correction 5 5 16 — A/D Counts 128,000 128,000 65,000 —

Calibration Units All Available All Available Pounds — Languages English + Spanish English + Spanish English —

Auto Test Reset Yes Yes — —

Function Indicator Lights Yes - 6 Yes - 4 — —

Password Protection Yes Yes — —

Water/dust Resistant Case Yes Yes Yes Yes Simple Operation/Calibration Yes Yes Yes Yes Channel Selection - Easy Yes Yes — — Software Upload Capable Yes Yes — — Numeric Keypad Calibration Yes Yes Yes — Instruction and Calibration Manual

Included Yes Yes Yes Yes

Warranty Period Variable Variable Variable Variable

Power Requirements 100-240 VAC, 47/63Hz (9VDC A 2.0Amps) 100-240 VAC, 47/63Hz (9VDC A 2.0Amps) 85-250VAC, 50/60 Hz, 15VA —

(38)

(39)

(40)

Digital Scale

with Case

ASTM C94 C138 C29 EN 933-8

This fi eld scale incorporates great performance, usability, and reliability in one rugged unit—a heavy-duty unit at a lightweight price! The 110 pound (50kg) capacity and outstanding high resolution—0.01 oz/0.005 lbs/2 g make it fl exible enough for small unit weight measures, concrete cylinder weights and numerous other fi eld uses.

• ASTM C94 requires a ﬁ eld weight measurement with every set of concrete test cylinders. The LA-0467-10 digital ﬁ eld scale meets and/or exceed this standard

• ASTM C138 speciﬁ es concrete unit weight. The LA-0467-10 Digital Field Scale meets and/or exceed this standard

• ASTM C29 speciﬁ es concrete unit weight for aggregates. The LA-0467-10 Digital Field Scale meets and/or exceed this standard.

The LA-0467-10 is completely portable, featuring a compact design, only 2.5 inches thick (6.35 cm). The scale has a tough ABS plastic case with integrated carrying case. It is battery powered with charging and recovering capabilities. It uses a 9V battery (not supplied ) and has a battery life of approx 20 hours. The removable control box has touch key controls with three display modes – lbs/oz.; decimal lbs and kilograms. The control box has a prop to stand it upright and has a hanging hook.

Dimensions: 10.6 in x 15.2 in x 2.2 in (26.9 x 38.6 x 5.6) cm Weight: 7 lb (3.18 kg) Safety: CE ap-proved The manufacturer offers a 90 day replacement and 2 year limited warranty.

Model

Shipping Weight

Product Number

(41)

39

724 346 7400 • 800 367 6397

Fresh Concrete Test Set

ASTM C138 C143 C192 C231 C470 AASHTO T23 T119 T121 T126 T152 BS 1881:107

EN 12350-6 1097-3

Everybody likes to save a little money. Saving time is good, too. This convenient set does both. FORNEY has bundled the apparatus used most frequently for performing tests on fresh concrete together into one set. The set includes: Air Meter, Slump Cone, Slump Cone Funnel, Portable Slump Test Base, Bench Scale (220 lb x 0.1 lb readability), Steel Unit Weight Bucket (.5 ft³/14.1 L), Plastic Cylinder Molds (6 x 12 in, 20 per carton) Tamping Rod, Rubber Hammer, Round Mouth Scoop, Aluminum Straight Edge, Thermometer, (25 °F to 125°F).

Model

Shipping Weight

Product Number

Fresh Concrete Test Set 134 lb (60.9kg) LAG-0050

Parts and Accessories

Product Number

Cyl Mold, 6 x 12 in, Plastic - 20 per case, no lid LA-0211-01

Straight Edge, Aluminum LA-0267

Slump Cone LA-0275

Slump Cone Funnel LA-0275-10

Tamping Rod, 23-1/4 in (59.1 cm) with 5/8 in (15.9 mm) rounded tip LA-0280

Slump Test Base, Portable LA-0286

Hammer, Rubber, 16 oz LA-0291

Scoop, Round Mouth, 38 oz LA-0294

FORNEY Press-Aire™ Meter Kit (Air Meter Kit) LA-0316

ES Scale, 220 lb/100kg, .1 lb/0.5kg LA-0466-10

Steel Unit Weight Bucket, .5 cu ft LA-0505

Thermometer, 25° to 125° F, 5 in (12.7 cm) stem, 1 in dial LA-0535

HTO T23 T119 T121 T126 T152 881:107

(42)

Slump Test Set

Portable

ASTM C143 C192 AASHTO T23 T119 T126 BS 1881:102 EN 12350-2

FORNEY’s Portable Slump Test Set is used to conduct slump test on fresh concrete at the job site. The compact base unit has an integrted handle with drilled hole to hold the tamping rod in transit. The set includes Slump Cone, Tamping Rod, Slump Test Base and Round Mouth Scoop. Slump Cone Funnel may be ordered separately. Looking for other items that test slump? Slump Cone Funnel may be ordered separately.

Model

Shipping Weight

Product Number

Slump Test Set 22 lb (10.0kg) LAG-0035

Product Number

Slump Cone LA-0275

Slump Test Base, Portable LA-0286

Scoop, Round Mouth, 38 oz LA-0294

Slump Cone

ASTM C143 C192 AASHTO T23 T119 T126 BS 1881:102

EN 12350-2

The Slump Test measures slump of freshly-mixed concrete to determine workability. The FOR-NEY Slump Cone’s spun metal construction is seamless and plated to resist rust with handles and feet welded to the body.

Model

Shipping Weight

Product Number

Slump Cone 6 lb (2.7kg) LA-0275

(43)

41

724 346 7400 • 800 367 6397

Slump Test Set

Laboratory

ASTM C143 C192 AASHTO T23 T119 T126 BS 1881:102

EN 12350-2

If you work with concrete, you know the slump test is used more than any other test. This set includes all the essential pieces you need to conduct slump tests on fresh concrete in the lab. The 22 in x 23 in x 3 in inch galvanized material pan is sturdy and resists corrosion. The set includes: Slump Cone, Tamping Rod, Material Pan, Brush and Trowel.

Model Name

Shipping Weight

Product Number

Slump Test Set – Laboratory 23 lb (10.5kg) LAG-0030

Product Number

Trowel, 5 in (12.7 cm) LA-0272

Slump Cone LA-0275

Slump Cone Funnel LA-0275-10

Tamping Rod, 23-1/4 in (59.1 cm) with 5/8 in (15.9 mm) rounded tip LA-0280 Material Pan, 22 x 23 x 3 in, galvanized LA-0285

Stiff Wire Brush LA-0290

Kelly Ball Apparatus

ASTM C360 AASHTO T183 EN 933-8

Used to determine the penetration of a metal ball into freshly mixed concrete as a means of determining the workability. Unit consists of a metal frame, 30 lb (13.6 kg) spherical weight with handle graduated in 1/4 in (6.4 mm) increments.

Model

Shipping Weight

Product Number

(44)

SCC J-Ring Test Set

ASTM C1621 C1621M-06 EN 12350-12

Meets ASTM specifi cation C 1621 and C 1621M-06. The Forney J-Ring Test Set contains every-thing you need to determine the ability of SCC mixtures to fl ow around rebar and other reinforc-ing structure. The test can be used in the laboratory or in the fi eld for QC testreinforc-ing. The set features a heavy-duty steel J-Ring and a large, rigid plastic base plate with centering ring decal, a slump cone and straightedge. The base plate is 36 in x 36 in x 3/8 in thick (914 x 914 x 9.5) mm.

Model

Product Number

J-Ring Test Set LAG-3770

Product Number

Slump Cone LA-0275

SCC J-Ring LA-4260

Base plate for SCC spread test LA-4261

Decal for SCC Base Plate LA-4261-01

SCC Segregation Test Set

ASTM C1610 C1610M-06 EN 933-8

The FORNEY Segregation Test Set contains everything needed to determine the potential segregation of coarse aggregate in SCC mixtures. The unit consists of three plastic pipe sections, clamps and collector plate. The weights of the aggregates in the top, middle and bottom thirds are compared, weight difference indicates segregation in the concrete. Dimensions: 12 in x 12 in x 26 in LWH (305 x 305 x 660) mm.

Model

Product Number

SCC Segregation Test Set LAG-3771

Product Number

Digital Scale, 66 lb/ 30 kg x .02 lb/10 g LA-0466-01-01

Screen Tray LA-1090

Segregation Tester Assembly LA-4262

Collector Plate LA-4262-02

(45)

43

724 346 7400 • 800 367 6397

SCC Spread Test

ASTM C1611 C1611M-05 EN 12350-2

The SCC Spread Test Set includes everything you need to determine the fl owability of SCC mixtures according to ASTM C 1611. The slump cone is placed in the center of the base and fi lled with concrete. The cone is then raised, allowing the concrete to spread and the lateral fl ow is measured. The Set includes a slump cone, straightedge and a rigid plastic base plate on which to perform the test. The base plate is 36 in x 36 in x 0.375 in LWH (914 x 914 x 9.5) mm.

Model

Product Number

SCC Spread Test Set LAG-3772

Product Number

Slump Cone LA-0275

SCC L-Box

The SCC L-Box determines the ﬂ ow rates and passability of self compacting concrete in conﬁ ned spaces. The test box is comprised of concrete reservoir, slide gate, three obstacles and test basin. The dimensions of the L-Box are 31.5 in x 23.6 in x 35.4 in LWH (80 x 60 x 90) cm.

Model

Product Number

(46)

SCC Complete

Test Set

ASTM C1611 C1611M-05 C1621 C1621M-06 C1610 C1610M-06 EN 12350-2 12350-12

This test set includes all the equipment to perform three SCC test procedures: the Spread Test, the J-Ring test, and the Column Segregation Test. The Base Plate and Slump Cone conform to ASTM C 1611. The J-Ring meets ASTM C 1621 and C 1621M-06. Included are: Segregation Test Set, Collector Plate, Slump Cone, J-Ring, SCC Plastic Base, and Straightedge. Included are: Base Plate with decal, Slump Cone, Straightedge, Column Segregation Tester Assembly, Collector Plate, J-Ring.

Model

Product Number

SCC Complete Test Set LAG-3774

Product Number

Slump Cone LA-0275

Digital Scale, 66 lb/ 30 kg x .02 lb/10 g LA-0466-01-01

Screen Tray LA-1090

Shovel, Square End LA-1225

SCC J-Ring LA-4260

Segregation Tester Assembly LA-4262

Collector Plate LA-4262-02

Rubber and Latex Gloves See pages 239 www.FORNEYonline.com 724 346 7400 800 367 6397

(47)

45 724 346 7400 • 800 367 6397

Acme Penetrometer

ASTM C403 AASHTO T197 EN 933-8

The Acme Penetrometer is used to determine the time of setting of concrete with slump greater than zero by means of penetration resistance on mortar sieved from a concrete mixture. Also used to determine the effects of variables upon the setting and hardening of concrete. Unit includes a cast aluminum base, gear rack mounted force cylinder, 200 lbf (890 N) dial gauge graduated in 2 lbf divisions and a set of six (6) penetration needles in a storage rack allowing multiplication to a maximum 8000 lbf reading. Model Shipping Weight Product Number

Acme Penetrometer 60 lb (27.3kg) LA-4110

Product Number

Penetration Needle set of 6 LA-4133-01

1 in² (645 mm²) end area needle LA-4133-02

1/2 in² (323 mm²) end area needle LA-4133-03

1/4 in.² (161 mm²) end area needle LA-4133-04

Concrete Pocket

Penetrometer

ASTM C403 C780 EN 933-8

Used to test the initial set of concrete mortar in accordance with ASTM C403. Plunger tip area is 1/20 in². Push the plunger into the mortar 1 inch periodically. Resistance in psi is indicated on the scale. Scale range is 0-700 psi. The point of initial set is reached when the penetration value is 500 psi. Penetrometer Foot is a stainless steel disk, 2.70 inch (68.58 mm) diameter.

Model

Shipping Weight

Product Number

Concrete Pocket Penetrometer, Dial Type 2 lb (0.9kg) LA-3301 Concrete Pocket Penetrometer 2 lb (0.9kg) LA-3302 Foot for Pocket Penetrometer 2 lb (0.9kg) LA-3302-01

(48)

Press-Aire

™

_Meter

(49)

47

724 346 7400 • 800 367 6397

The Press-Aire

™

_{Meter is the industry’s most popular kit for testing entrained air.}

Whether going into the Ready Mix truck or coming down the chute, it gives fast

results. Always accurate. The kit contains everything needed to perform the test

and — very importantly — to keep the unit in calibration.

It measures the air content in fresh mix concrete. The test procedure equalizes a

known volume of air in the pressure chamber, with the unknown value of entrained

air in the concrete-ﬁ lled base. The amount of air entrained is then read on the

meter’s gauge as the direct percentage (to the nearest 0.1%) of air entrained in the

concrete. The test is based on Boyle’s law. Also known as “Type B”. See Full

Instruc-tions or refer to ASTM.

The air meter unit consists of 2 main parts: the base (measuring chamber) and the

cover assembly. The cast aluminum base has machine-ﬂ anged rims. The interior

surfaces of the base and surfaces of rims, ﬂ anges and other component parts are

machined to facilitate frequent water clean-up. The unit is designed for easy

disas-sembly in order to replace worn or damaged parts in the ﬁ eld.

(50)

Repair Program

The FORNEY Repair Program includes cleaning the vessel by sand-blasting,

re-calibrating the gauge and general cleaning of all parts - for a ﬂ at-rate labor

charge. (Replacement parts are charged at list price.) In fact, the Repair Program

is available for all brands of Air Meter. FORNEY also rebuilds compression

test-ing machines, concrete test hammers, recordtest-ing thermometers, hydraulic pumps,

valves and digital readouts.

The FORNEY Repair Department has a full-time staff of professional repair

per-sonnel with a large inventory of repair parts. Turn-around time is very fast.

Some-times customers prefer to do their own repairs and maintenance. FORNEY has all

the Air Meter Parts you need in stock, ready to ship. Keeping a spare Super Pump

or an extra set of O-rings can save down-time.

Call for shipping instructions or simply ship to the Hermitage, PA or Denver CO

factory. See Page 7 for full details.

(51)

Super Pump

The Super Pump is an important part of the Air Meter. It must be properly

maintained to prevent air leakage. O-rings on the top of the pump and on the

inside seal the unit. When the O-rings deteriorate, air can leak into the chamber

and or debris can enter the pump. Some customers prefer the time-saving

conve-nience of simply replacing the Super Pump, but FORNEY also sells a handy

Gasket Repair Kit.

The Super Pump (LA-0316-22) adds air to the sealed air chamber. Once the initial

pressure is reached, the air is released into the vessel containing the concrete and

the percentage of entrained air can be determined.

(52)

Press-Aire

™

_{Meter Unit}

36 46 45 44 61 62 63 32 33 22 21 20 29 16 19 18 15 14 13 12 6 7 5 8 1 4 4 2 3 9 11

(53)

51 724 346 7400 • 800 367 6397 Model Shipping Weight Part Number

FORNEY Press-Aire™ Meter Kit (Air Meter Kit) 39 lb (17.7kg) LA-0316

Components of the Air Meter Kit Part Number

FORNEY Press-Aire™ Meter Kit (Air Meter Kit), unit only LA-0316-S Carrying Case for FORNEY Press-Aire™ Meter (Air Meter) LA-0316-38

Super Pump LA-0316-22

Calibration Vessel, Brass LA-0316-31-B

Calibration Tube, Outside Bent LA-0316-32

Calibration Tube, Inside Straight LA-0316-33

Strike Off Bar, Aluminum LA-0316-34

Parts List LA-0316-27

Parts and Accessories Part Number

Roller Meter - Syringe, 3 oz LA-0305-28

Tamping Rod, 12 in (30.5 cm) with 5/8 in (15.9 mm) rounded tip LA-0306-05 FORNEY Press-Aire™ Meter Kit (Air Meter Kit), Top assembly only, without case or base LA-0316-T

1 Pressure Chamber LA-0316-01

2 Pressure Chamber Cap LA-0316-02

3 Chamber Elbow LA-0316-03

4 Chamber Gasket, two required (top & bottom) LA-0316-04

5 Air Bleeder Valve Assembly LA-0316-05

6 Air Bleeder Valve Cap LA-0316-06

7 Gauge for Press-Aire Meter LA-0316-07

8 Air Bleeder Valve Stem LA-0316-08

9 Air Bleeder Gasket LA-0316-09

11 Needle Valve Stem LA-0316-11

12 Needle Valve Nut LA-0316-12

13 Needle Valve Lever LA-0316-13

14 Needle Valve Spacer LA-0316-14

15 Needle Valve O-Ring LA-0316-15

16 Needle Valve Spring LA-0316-16

18 Needle Valve Seat LA-0316-18

19 Lid LA-0316-19

21 Lid Petcock LA-0316-21

Instruction Label LA-0316-23

29 Aluminum Unit Weight Bucket - Base- .25 cu ft (7.1 L) LA-0316-29

36 Needle Valve Stem O-ring LA-0316-36

Gauge Glass LA-0316-41

Latch Stud LA-0316-43

44 Latch Clamp Tab LA-0316-44

45 Latch Assembly for Lid LA-0316-45

46 Pan Hd Screw, HD #10 x 1/2 in LA-0316-46

61 5/16 in WB Nut LA-0316-61

62 5/15 in x 1/8 in Adapter LA-0316-62

63 O-ring, Needle Valve LA-0316-63

O-ring, Super Pump Seal LA-0316-80

O-ring, Super Pump Piston Seal LA-0316-81

Super Pump Check Valve LA-0316-82

(54)

Calibration Vessels

ASTM C231 AASHTO T152 EN 12350-7

Calibration vessels represent 5% of air by volume and are used to calibrate air meters with 1/4 ft³ (0.007 m³) capacity. Model Shipping Weight Product Number

Econo-Cal Calibration Vessel 3 lb (1.4kg) LA-0316-94 Accu-Cal Calibration Vessel 3 lb (1.4kg) LA-0316-95

Universal Gasket Kit

EN 12350-7

The Universal Gasket Kit contains the necessary components to replace all the soft washers and O-rings in all FORNEY air meters, as well as all other brands.

Model

Shipping Weight

Product Number

Universal Gasket Repair Kit 1 lb (.5kg) LA-0316-60

Mortar Air Content Measure

ASTM C185 C780 AASHTO T137 EN 933-8

Used to determine the air content of fresh mix mortar. Steel container is 3 inch in diameter x 3.54 inch deep (7.6 x 9.0) cm, calibrated to contain 400 mL ± 1 mL of water at 73 °F (23 °C).

Model

Shipping Weight

Product Number

(55)

53

724 346 7400 • 800 367 6397

K-Slump Tester

ASTM C1362 EN 933-8

Used for rapid assessment of the ﬂ ow and consistency of freshly mixed concrete.

Model

Shipping Weight

Product Number

K-Slump Tester 2 lb (0.9kg) LA-0278

Vebe Consistometer

ASTM C1170 BS 1881 1881:104 EN 12350-3

This test method is a variation of the slump test and subjects the concrete to vibration after removal from the slump cone. The time taken for the concrete to be re-compacted is taken as a measure of workability. Model Shipping Weight Product Number

Vebe Consistometer , 110 V/60 198 lb (90.0kg) LA-0325 Vebe Consistometer, 220V/50 198 lb (90.0kg) LA-0325-01

Tamping Rods See page 231 www.FORNEYonline.com 724 346 7400 800 367 6397

(56)

Volumetair (Plastic)

ASTM C173 EN 933-8

The Volumetair utilizes the rolling method to measure entrained air in fresh mix concrete. Lightweight and easy to use, the Volumetair is made from PVC and reinforced plastic. The Volumetair is supplied with funnel, syringe, tamper, strike-off bar, calibrated cup, mallet and plastic carrying case.

Model

Shipping Weight

Product Number

Volumetair™ – Plastic 15 lb (6.8kg) LA-0306-P

Product Number

Top (Expansion Plug) LA-0306-P-01

Chace Air Indicator Kit

AASHTO T199 EN 933-8

Measures entrained air in fresh concrete. Kit includes alcohol bottle, Chace air indicator stopper, cleaning brush and carrying case.

Model

Shipping Weight

Product Number

Chace Air Indicator Kit 3 lb (1.4kg) LA-0345

Product Number

Glass Indicator & Stopper LA-0340

Stopper, only LA-0340-01

Glass Indicator, only LA-0340-02

Squeeze Bottle, Plastic, 125 ml LA-0345-01

(57)

55

724 346 7400 • 800 367 6397

Lightweight Roller

®

_Meter

ASTM C173 AASHTO T196

Determines entrained air content of fresh mix concrete, ﬂ y ash and other lightweight aggregates. Constructed from cast aluminum with window graduated from 0% to 10% in 0.25% subgradua-tions. Dual clamping system with O Ring seal for upper and lower chambers. Set includes syringe, tamping rod, measuring vessel, bafﬂ e funnel and carrying case.

Model

Shipping Weight

Product Number

Lightweight Roller Meter 29 lb (13.2kg) LA-0306

Product Number

Roller Meter - Plastic Sight Tube LA-0305-04

Spanner Wrench LA-0305-22

Roller Meter - Syringe, 3 oz LA-0305-28

Roller Meter - Graduated Tube LA-0306-02

Roller Meter - Upper Chamber LA-0306-03

Roller Meter - Base 130 cu in LA-0306-04

Tamping Rod, 12 in (30.5 cm) with 5/8 in (15.9 mm) rounded tip LA-0306-05

Measuring Vessel LA-0306-07

Roller Meter - O-Ring, Tube LA-0306-09

Roller Meter - Tube Clamp LA-0306-14

Roller Meter - O-Ring, Lid LA-0306-16

Pan Head Screws - 6 LA-0306-17

Carrying Case LA-0306-19-P

Roller Meter - Cap LA-0306-25

Strike-Off Bar LA-0306-29

Latch Assembly for Lid LA-0316-45

htweight Roller

®

_Meter

C173 O T196

(58)

Freeze-Thaw Cabinet

ASTM C666 AASHTO T161 EN 196-1 1367-1

Used to determine the resistance of concrete samples to rapidly repeated cycles of freezing and thawing in a speciﬁ ed procedure. Consists of a stainless steel cabinet, 3/4 hp (0.55 kW) refrigera-tion unit producing temperatures to 0 °F (-17.8 °C), electric resistance heaters, 7 day recording thermometer and automatic controls for up to 9 freeze-thaw cycles in a 24 hour period. Unit capacity up to 18 samples. Unit dimensions: 84 in x 34 in x 11 in (213.4 x 86.4 x 27.9) cm.

Model

Shipping Weight

Product Number

Freeze-Thaw Cabinet, 110 V/60, 30 amp 950 lb (431.8kg) LA-0490 Freeze-Thaw Cabinet, 220 V/50, 15 amp 950 lb (431.8kg) LA-0490-01

Product Number

Mold, Freeze/Thaw, 3 x 4 x 16 inches LA-0490-03

Sonometer

ASTM C215 C666 AASHTO T161 BS 1881:209

Used to perform freeze-thaw tests, dynamic testing of concrete specimens, assess uniformity of in-place concrete and evaluate expansion, bending and twisting of wood, metal, plastic, ceramic and other materials by measuring changes in resonant frequency. The unit consists of a 30 W portable driver, pick-up circuit with a cartridge mounted on an adjustable metal stand and control unit with 3 in (76.2 mm) oscilloscope, voltmeter, counter and ampliﬁ er. Amplitude and frequency of vibra-tions can be controlled in ranges of 0 W to 25 W, 400 cps to 12,000 cps, frequency displayed to ±2%. Counter displays to ± one digit. Overall box dimensions: 17 in x 14 in x 11 in (43.2 x 35.6 x 27.9) cm. Model Shipping Weight Product Number Sonometer, 115 V/60 51 lb (23.2kg) LA-0518 Sonometer, 230 V/50 51 lb (23.2kg) LA-0518-01

(59)

57 724 346 7400 • 800 367 6397

Test Hammers

Low Impact

BS 1881:202 EN 12504:Part 2

Used for low impact of softer materials such as mortar joints, low strength concrete, plaster, ma-sonry mortar and paper rolls. Test hammer works on a rebound principle recording the rebound value of the hammer upon release from a known stress. Set includes hammer, rubbing stone, cali-bration curves and plastic carrying case with handle.

Model

Shipping Weight

Product Number

Type L Schmidt Hammer, Paper 5 lb (2.3kg) LA-0360 Type L Schmidt Recording Hammer 8 lb (3.6kg) LA-0365 Type PM Schmidt Hammer - Masonry 8 lb (3.6kg) LA-0376

Product Number

Impact Plunger-Mortar Joints LA-0350-01

Schmidt Hammer Carrying Case (Type L/N) LA-0350-26

Test Hammer Calibration Anvil LA-0385

Pressure Sens. Chart Paper (all recording hammers) - 5 Roll Box LA-0390

Rubbing Stone LA-0395

s

Thermometers

See pages 247 thru 249 www.FORNEYonline.com

724 346 7400 800 367 6397

(60)

Concrete Test Hammers

ASTM C805 BS 1881:202 EN 12504:Part 2

Test hammers are used to assess the uniformity of in-place concrete to determine regions of poor quality or deterioration and to estimate strength. They provide quick results and are non-destructive. The newer model and more economical FORNEY test hammer works on a rebound principle recording the rebound value of the hammer upon release from a known stress. The older model Schmidt test hammer works on the same principle.

The Digi-Schmidt is the classic original concrete test hammer equipped with a micro-processor sensor. Model Shipping Weight Product Number

Concrete Test Hammer - FORNEY Type N 5 lb (2.3kg) LA-0350 Concrete Test Hammer - Schmidt Type N 6 lb (2.7kg) LA-0352 Recording Test Hammer - Type N Schmidt 8 lb (3.6kg) LA-0355 Concrete Test Hammer - Digi-Schmidt 13 lb (5.9kg) LA-0371

Test Hammer

Calibration Anvil

ASTM C805 EN 12504:2

Used to calibrate Concrete Test Hammers. Test platen made of high carbon tool steel hardened to 65-67 Rockwell C with ground test surface and hammer guide lined with a felt strip. For Type N and L hammers. Model Shipping Weight Product Number

(61)

59

724 346 7400 • 800 367 6397

Rebar Locator

Covermeter

BS 1881:204

Covermeters are used to determine the depth and placement direction of No. 2 to No. 14 (5 mm to 50 mm) reinforcement bar inside in-place concrete. Covermaster uses the pulse detection eddy-current detection principle to accurately locate in-concrete reinforcement bars. Cover Master con-sists of a Ni-Cd battery powered control unit with digital display reading depth to two decimal places. A loud audio signal indicates rebar location and direction. The hand-held detection head connects to the control unit by coaxial cable. Units come standard with search head connecting cable, rechargeable battery pack and battery charger, earphone, shoulder strap, plastic carrying case and operating instructions. Units are powered by 110 V current. Operating temperature range is 50 °F to 90 °F (10 °C to 32 °C). Accuracy after calibration: ±0.1 in (±2.5 mm). LA-0803-10 has a standard head. It has a depth range of 1/4 in to 4 in (6.3 mm to LA-0803-101.6 mm) LA-0803-09 has midget head for areas of low cover, precast units and reinforced concrete pipes. LA-0803-15 has a deep cover search head. It can measure up to 8 in (205 mm). It contains state-of-the-art microprocessor technology with a full menu-driven LCD display.

Model

Shipping Weight

Product Number

Narrow Pitch Head Only 10 lb (4.5kg) LA-0803-09

Standard Head Only 10 lb (4.5kg) LA-0803-10

Cover Master for Rebar Only w/o Head 10 lb (4.5kg) LA-0803-15

Large Head 10 lb (4.5kg) LA-0830-15-01

Rebar Locator

Plus and IMP

BS 1881:204

Used to determine the location and direction of No 3 to No 14 (10 mm to 50 mm) reinforcement bar inside in-place concrete. The IMP is a single range unit, the Rebar Plus is dual range with an indication of depth of cover. Both use the pulse detection eddy-current detection principle to accurately locate in-concrete reinforcement bars. Units consist of a battery powered control unit with color coded controls. The hand held search head contains the sealed search coils used for the location and orientation of rebar. An audio signal indicates rebar location and direction. The kit includes carrying case.

Model

Shipping Weight

Product Number

Rebar Plus Rebar Locator 3 lb (1.4kg) LA-0803

(62)

Rebar Locator

Zircon MT6

BS 1881:204

The MT6 metal locator ﬁ nds both ferrous and non-ferrous metal and indicates depth up to 6 inches (152 mm) deep. Features a large LCD screen and made to withstand everyday jobsite use. Perfect for ﬁ nding rebar and other metals inside concrete, tile and marble before coring or drill-ing. Model Shipping Weight Product Number

Rebar Locator - Zircon MT6 2 lb (0.9kg) LA-0803-16

Concrete

Permeability

Tester

Used to measure the permeability of the surface of concrete using the Torrent two chamber vac-uum cell method. System consists of a 9 V battery powered display unit with graphic LCD, nine button keypad, non volatile memory, storage up to 200 objects, RS-232 C, software for printer and PC download, printer cable, PC download cable and carrying case. Control unit with pressure regulator, pressure sensor, control valve, vacuum connection and carrying case. Case dimensions: 20.5 in x 14.6 in x 4.9 in (52 x 37 x 12.5) cm. Two chamber vacuum cell with sealing rings. Note: System operated by optional commercial vacuum pump, 3 ft³/min (85 L/min).

Model Shipping Weight Product Number
