O Futuro da Observação dos Oceanos
João Tasso de Figueiredo Borges de Sousa
Laboratório de Sistemas e Tecnologias Subaquáticas Faculdade de Engenharia
Universidade do Porto Portugal
Outline
Laboratory overview
Vehicle systems
Software tool chain
Operations
PITVANT
PITVANT
PITVANT
Extension of the continental shelf (Portugal)
4
Workshop: Ocean's challenges and technological developments. July 06 - 07, 2009 - APDL, Leça da Palmeira, Courtesy of Manuel Pinto de Abreu
Vision
Moored sensors
Autonomous surface vehicle Surface buoy Navigation beacon Oceanographic sensors Moored sensors Drifters AUV AUV
UAV UAV
AUV Localization links Coms. links Sensing links UAV Vehicles come and go
Control station
Control station
Control station
Operators come and go
Data provisioning intervention AUV Data mules DTN Mixed-initiative Concurrent operations Intermittent communications
Dynamic interactions and structure
System properties are a function of structure and interactions
Strategy
Strong experimental component (operations @ sea) • Conops / Operational know-how / Reliable vehicle systems
Strategic partnerships
• Portuguese Navy / Air Force / Extension of the Continental Shelf
Systems engineering
• Methodological framework to develop systems and their life cycles
• Design vehicles for interactions
Networkings for S&T development
• Controls, communication, computation, autonomy, etc…
Connecting the dots – user-inspired basic research • Pasteur’s quadrant
Cooperation
Portugal
• Marinha Portuguesa
• Força Aérea Portuguesa
• Instituto Hidrográfico
• Estrutura de Missão para a Extensão da Plataforma Continental
• Porto de Douro e Leixões
• Oceanscan MST (spin-off)
USA
• MBARI
• UC Berkeley
• Naval Postgraduate School
• US Coast Guard
• University of Michigan
• Naval Undersea Warfare center
Europe
• Naval Undersea Research Center (NATO)
• National Oceanography Center (UK)
• NTNU (Norway)
• Plocan (Spain)
• Universidade de Delft (NL)
• Swedish Defence Agency (SE)
• Royal Institute of Technology (SE)
• EU/NATO project partners
On-going projects
Noptilus (www.noptilus-fp7.eu) – FP7 project (2011-2015)
Netmar (http://project-netmar.eu) – Interreg project
(2012-2014)
SafePort – NATO funded project (2011-2014)
Necsave – European Defense Agency project (2013-2015)
Pitvant – unmanned air vehicles program (2008-2015)
SeaconII – unmanned underwater vehicles program (2013-2015)
SUNRISE– FP7 project (2013-2017)
Persist – FCT project (2011 – 2014)
Ocean vehicles
Low cost vehicles
Light AUV (LAUV)
5th generation
Designed for interactions (networked behavior)
CTD GPS/GSM/Wi-Fi Antennas
Trimming Power Connector
Side-scan sonar Micro-modem
Emmergency pinger
DVL
PC-104 Stack(s) IMU
Manta gateway
Battery powered portable communications hub • 802.11gn 2.4GHz and 5Ghz
• Freewave
• Acoustic Modem
• Delay Tolerant Networking (DTN)
• LBL Tracking
• GSM
• Iridium
• Deployed from ship, RHIBs and buoys
Coms gateways,
data loggers, drifters, fish tags
Communications gateway High performance data logger Light data logger
Drifters
Drifter
Fish tags
Aerial vehicles
–cooperation with Air Force
PITVANT project (MDN 2009-15)
• Unmanned vehicle systems
- 3 ANTEX01 (6.5 m wingspan) - 3 ANTEX02E (3.6m wingspan) - 8 ANTEX02 (2.4m wingspan) - 10 small wingspans
• Stats
- > 1000 autonomous flights - Day / night operations
• Priority: flights over the ocean
Unmanned air vehicles
Picollo autopilot PC-104 stack
Gimbaled camera Electric or combustion
engines
Software tool chain
Off-board command, control and communications
Communication protocols for command and control of heterogneous systems
Onboard software (vehicles, buoys, data loggers)
Field tested in thousands of operations with air and ocean vehicles
• Interoperability for autonomous vehicles
• Ranges from the
component-to-component communication to system-to-system • Delay-Tolerant Networking • implementation of a convergence layer for Micromodems • Interoperability for UAVs • Partially compliant
• Participation in development list
Layered communications architecture
Neptus DUNE
Message Protocol
Transport
Low Level Transport STANAG 4586
DTN JAUS
Janus
• Unified layer for acoustic
Neptus Console
IMC / DTN
unified command and control
Supports all phases of the mission life cycle
Planning, Execution, Review and Analysis
Modular architecture through plug-ins
Supports all phases of the mission life cycle
Supports all phases of the mission life cycle
Supports all phases of the mission life cycle
IMC protocol
API is described using XML file/generate code automatically
Plan interface Vehicle command interface Maneuver interface Guidance interface Hardware interface Plan supervisor Vehicle supervisor Goto controller StationKeeping controller Teleoperation controller Formation controller
VehicleCommand VehicleState
ManeuverCommand ManeuverState
DesiredGuidance EstimatedState
Actuator commands Sensor readings
Navigation Guidance
Motor driver Servo driver CTD sensor
driver
Depth sensor driver
PlanCommand PlanState
Plan interface Vehicle command interface Maneuver interface Guidance interface Hardware interface Plan supervisor Vehicle supervisor Goto controller StationKeeping controller Teleoperation controller Formation controller
VehicleCommand VehicleState
ManeuverCommand ManeuverState
DesiredGuidance EstimatedState
Actuator commands Sensor readings Navigation Guidance
Motor driver Servo driver CTD sensor driver
Depth sensor driver
PlanCommand PlanState
Intermittent IMC communications
Mission Planner Neptus Console IMC Comms Tree of variables STANAG Comms Logging
Tool chain interactions
LSTS/TREX architecture
Neptus
TREX plugin
IMC
TrexGoal / TrexCommand
DUNE
TREX taskTREX
Platform Reactor UDP Transport Deliberative ReactorMessage bus TREX timelines Deliberative
Reactor IMC (localhost)
mbari
Operations
Autonomous underwater rendezvous
Oct 06
Monterey, California, 2006
Cooperation with Naval Postgraduate School
Estuary surveys with UC-Berkeley
Oct 07
Drifters deployed to collect GPS data along the way Estimate of currents is generated
HMS Roebuck
Iver 2v Seacon
Swordfish
Gavia
REP10 exercise
July 2010
Cooperation
• Portuguese Navy (PO)
• NUWC (USA)
• Porto University (PO)
• NURC (NATO)
HMS Roebuck
Iver 2v Seacon
Swordfish
Gavia
REP12 exercise
July 2012
Bacamarte & Swordfish
Portuguese Navy (PO) Portuguese Air Force (PO) MBARI (USA)
Porto University (PO) NURC (NATO)
Mini UAV
Extended Alfa X06
Land-based UAS operations
• Search for targets
• Surveillance of maritime traffic in shipping lanes • Hand-over of control from shore to Navy vessel • Video feed to shore and to Navy vessels
Ship-based UAS operations
• Short range surveillance
CommsNet12 DTN
–
CRME
2012
• LAUV Xtreme 2 (Sidescan, Camera, CTD, WHOI micromodem)
Networked systems for situational awareness and intervention in
maritime incidents
Mine warfare and Harbour Protection:
Bottom search and detect;
Interact with submarines and divers;
Command and control integrated in a Harbour Protection module.
Recognized Environmental Picture - REP 13
• Mine Warfare
• Harbour Protection
• Expeditionary Hidrography
• Search and Rescue
• Maritime Law Enforcement
Mine warfare and Harbour Protection:
Bottom search and detect;
Interact with submarines and divers;
Command and control integrated in a Harbour Protection module.
Organized by
• U Porto
• PO Navy
Partners
• PO Air Force
• MBARI
• UC BERKELEY
• NTNU
• EVOLOGICS
5 N M Mar
in h a Alfa
Ext end ed Pet
Search and Rescue and Maritime Law Enforcement:
• Search, detect, classify and ID of
contacts; where divers do not dare (or should not); SeaCon
• Patrol areas too big for diver teams;
SeaCon;
• Extend the patrol areas of a Patrol
Boat; Pitvant;
5 N M Mari
Mine warfare and Harbour Protection:
• Bottom search and detect; SeaCon;
• Interact with submarines and divers;
SeaCon;
• Detect threats in a harbour protected
Hydrography:
Expedite bathymetry charting.
(Expeditionary)
LATERAL SONAR KLEIN 3900
Towards system of systems
\ ASV (OBA)
UAV (OBA)
Comms gateway
NAUV (OBA)
NAUV (OBA)
UAV (OBA)
Comms gateway
Seacon (OBA)
Seacon (OBA)
Seacon (OBA)
Acoustic comms
Wireless comms
Ground Station
Mobile Station
Decision support system
[scirob]$ “buoy: trigger”
[scirob]$ “buoy: trigger”
[scirob]$ find _front
[scirob]$ “buoy: trigger”
[scirob]$ find _front
[scirob]$ “vehicles: found _front”
[scirob]$ “buoy: trigger”
[scirob]$ find _front
[scirob]$ “vehicles: found _front” [scirob]$ “vehicles: lost front”
[scirob]$ “buoy: trigger”
[scirob]$ find _front
[scirob]$ “vehicles: found _front” [scirob]$ “vehicles: lost front”
[scirob]$ run model_test_h1
[scirob]$ “buoy: trigger”
[scirob]$ find _front
[scirob]$ “vehicles: found _front” [scirob]$ “vehicles: lost front”
[scirob]$ run model_test_h1 [scirob]$ track(location)
[scirob]$ “buoy: trigger”
[scirob]$ find _front
[scirob]$ “vehicles: found _front” [scirob]$ “vehicles: lost front”
[scirob]$ run model_test_h1 [scirob]$ track(location) [scirob]$ sample_in_out
[scirob]$ “buoy: trigger”
[scirob]$ find _front
[scirob]$ “vehicles: found _front” [scirob]$ “vehicles: lost front”
[scirob]$ run model_test_h1 [scirob]$ track(location) [scirob]$ sample_in_out
[scirob]$ “buoy: trigger”
[scirob]$ “buoy: trigger”
[scirob]$ find _front
[scirob]$ “vehicles: found _front” [scirob]$ “vehicles: lost front”
[scirob]$ run model_test_h1 [scirob]$ track(location) [scirob]$ sample_in_out
[scirob]$ “buoy: trigger”
[scirob]$ sample_area
Conclusions
Networked vehicle systems provide new capabilities
Developments at the intersection of computation and control Inter-operability is key to networked operations
