Comprehensive analysis of gene expression and DNA methylation data identifies potential biomarkers and functional epigenetic modules for lung adenocarcinoma

Comprehensive analysis of gene expression and DNA methylation data

identifies potential biomarkers and functional epigenetic modules for lung

adenocarcinoma

XiaoCong Wang

, YanMei Li

, HuiHua Hu

, FangZheng Zhou

, Jie Chen

and DongSheng Zhang

Hubei University of Medicine, Department of Oncology, Suizhou Hospital, Suizhou, Hubei, China.

Hubei University of Medicine, Department of ICU, Suizhou Hospital, Suizhou, Hubei, China.

Abstract

Lung cancer has one of the highest mortality rates of malignant neoplasms. Lung adenocarcinoma (LUAD) is one of the most common types of lung cancer. DNA methylation is more stable than gene expression and could be used as a biomarker for early tumor diagnosis. This study is aimed to screen potential DNA methylation signatures to facilitate the diagnosis and prognosis of LUAD and integrate gene expression and DNA methylation data of LUAD to identify functional epigenetic modules. We systematically integrated gene expression and DNA methylation data from The Cancer Genome Atlas (TCGA) and Gene Expression Omnibus (GEO), bioinformatic models and algorithms were implemented to identify signatures and functional modules for LUAD. Three promising diagnostic and five potential prognostic signatures for LUAD were screened by rigorous filtration, and our tumor-normal classifier and prognostic model were validated in two separate data sets. Additionally, we identified functional epigenetic modules in the TCGA LUAD dataset and GEO independent validation data set. Interestingly, the MUC1 module was identified in both datasets. The potential biomarkers for the diagnosis and prognosis of LUAD are expected to be further verified in clinical practice to aid in the diagnosis and treatment of LUAD.

Keywords: DNA methylation, biomarkers, lung adenocarcinoma, cancer diagnosis, prognosis.

Received: May 25, 2019; Accepted: January 30, 2020.

Introduction

Lung cancer has one of the highest incidence and mor-tality rates of neoplasms and can be classified into small cell lung cancer and non-small cell lung cancer (NSCLC), NSCLC consists of adenocarcinoma, squamous cell carci-noma, large cell carcinoma and other types (Travis, 2011). Among them, adenocarcinoma is the most common subtype (Liu et al., 2000). Despite treatment with surgery followed by radiotherapy or chemotherapy, many patients still have poor clinical outcomes (Perez et al., 2014; Ramnath et al., 2013; Verdecchia et al., 2007). Hence, early diagnosis and treatment are the key to reducing the mortality of lung can-cer. To date, no widely used DNA methylation markers have been identified for the early diagnosis and prognosis of lung adenocarcinoma (LUAD).

According to a previous study, alterations in DNA methylation (DNAm) appear to mark preneoplastic normal cells that later transform and become enriched in tumors (Teschendorff et al., 2016), which indicates that DNAm could act as biomarkers for the diagnosis of early cancer.

Studies on DNAm in lung cancer strongly suggest that the analyses of DNA methylation profiles will be of great utility both for understanding the molecular basis of lung cancer development (Toyooka et al., 2001, 2003, 2004; Virmani et al., 2002), and for developing epigenetic signatures for lung cancer (Shi et al., 2017; Walter et al., 2018). Recently, some studies have developed new biomarker screening algorithms for cancer diagnosis and prognosis (Wei et al., 2015; Hao et al., 2017), and algorithms to integrate DNA methylation and gene expression data to better understand tumor biology (Jiao et al., 2014).

In this study, the gene expression and DNA methyl-ation data of LUAD patients were systematically integrated and analyzed. We screened three potential DNA methylation signatures for early diagnosis and five prognostic gene ex-pression signatures for LUAD. The tumor-normal classifica-tion model and prognostic model were validated in two separate data-sets. In addition, we also identified functional epigenetic modules (FEMs) in The Cancer Genome Atlas (TCGA) LUAD data set and Gene Expression Omnibus (GEO) independent validation data set. The MUC1 module was identified in both data-sets. The potential biomarkers identified in this study are expected to be further validated and may aid decision for diagnosis and treatment of LUAD.

DOI: https://doi.org/10.1590/1678-4685-GMB-2019-0164

Send correspondence to DongSheng Zhang. Hubei University of Medicine, Department of Oncology, Suizhou Hospital, Suizhou, Hubei, China. E-mail: [email protected]. *These authors con-tributed equally to this work.

Original Article

Material and Methods

Dataset

Gene expression data analysis

We downloaded the RNA-seqV2 sequencing data (le-vel 3, normalized count) and the corresponding clinical data of LUAD patients from the UCSC Xena database (http://xena.ucsc.edu), including 553 gene expression sam-ples (tumor: 495, normal: 58). The screening criteria for sig-nificantly differentially expressed genes were as follows: 1.5-fold change and corrected P-value < 0.05 (independent t-test and p-value was adjusted by Benjamini/Hochberg cor-rection method.

DNA methylation data analysis

We downloaded the methylation data (level 3, Methyl-ation 450K) and the corresponding clinical data of LUAD patients from Xena (http://xena.ucsc.edu), including 492 samples (tumor: 460, normal 32) for methylation data analy-sis. The methylation level of each gene was calculated by de-fining the average methylation level of probes within gene promoter area (TSS1500, 1stExon, TSS200, 5` UTR), as the methylation level of the gene (TSS 1500 and TSS 200 repre-sents 1500 bp and 200 bp downstream from the transcription start site, 1stExon represents the first exon). The screening criteria for significantly differentially methylated genes were as follows: delta Beta > 0.2 and corrected P-value < 0.05(independent t-test plus Benjamini/Hochberg method). Validation dataset

DNA methylation 450K chip data (series_matrix.txt) and gene expression data were downloaded from the NCBI-GEO database (http: // www. ncbi. nlm. Nih. Gov/geo/), in-cluding GSE39279 (Sandoval et al., 2013), GSE52401 (Shi et al., 2014), GSE66836 (Bjaanaes et al., 2016), GSE75037 (Girard et al., 2016), GSE56044 (Karlsson et al., 2014), GSE50081 (Der et al., 2014) and GSE42127 (Tang et al., 2013).

Construction of diagnostic classifier

First, the recursive features elimination method was used to screen diagnostic probes from those 24,116 differen-tially methylated CpG sites. Then, probes were used to build the logistic regression function in the Python Sklearn pack-age (version 0.19, http://scikit-learn.org/stable/index.html). The parameters were all default parameters, and the model was trained with the TCGA data. Cox proportional hazards model was built based on the screened genes and survival analysis was performed for all patients (Python lifeline 0.11.1 (http:/ /lifelines.readthedocs.io/en/latest/in-dex.html)), and validated in a separate data-set.

Construction of prognostic model

We first preprocessed the GSE50081 and GSE42127 datasets downloaded from GEO. The expression of each gene was the average expression level of the corresponding

probes. Then genes from the 469 differentially expressed genes were selected with cox regression analysis and log-rank test (the criterion was as follows: false discovery rate (FDR) of cox regression£ 0.05 and FDR of log-rank test £ 0.05). Then, the cox proportional hazards model was con-structed with five selected genes, and survival analysis was performed for all patients.

Gene enrichment analysis

Gene Ontology (GO) and Kyoto Encyclopedia of Genes and Genomes (KEGG) pathway enrichment analyses were performed using a web-based gene annotation tool, DAVID (Huang et al., 2009ab).

FEMs analysis

The FEM algorithm (Jiao et al., 2014) is a functional supervised algorithm that uses a network of relations be-tween genes (in our case a protein-protein interaction (PPI) network) to identify subnetworks where a significant num-ber of genes are differentially methylated and differentially expressed. The association is measured at both the DNA methylation and gene expression levels. The algorithm thus consists of two main parts: (i) construction of an integrated network in which the associations with the phenotype are en-capsulated as weights on the network edges, and (ii) infer-ence of the FEMs as heavy subgraphs on this weighted network.

We first constructed a PPI network by integrating the InBio (Li et al., 2017) and BioPlex (Huttlin et al., 2015) da-tabases. Then, we conducted FEM with the FEM algorithm by integrating the gene expression and DNA methylated data from both the TCGA and GEO datasets.

Ethical Approval

This article does not contain any studies with human participants or animals performed by any of the authors.

Results

Analysis of differentially expressed genes and differentially methylated genes

A total of 2469 differentially expressed genes were ob-tained, including 1457 upregulated and 1012 downregulated genes (Figure 1a). Principal component analysis (PCA) (Fig-ure 1b) indicated that 1324 differentially expressed genes could effectively distinguish tumor samples from normal samples. A total of 24,116 differentially methylated CpGs retained, mapping to 981 genes, including 472 hyper-methylated genes and 509 hypohyper-methylated genes (Figure 1c). PCA indicated that the 981 differentially methylated genes could significantly separate the normal samples from the tumor samples (Figure 1d).

Diagnostic classifier effectively distinguishes tumor samples

After feature selection with recursive feature elimina-tion (see Material and Methods), three probes (cg20568402,

cg11302791 and cg01302240, see Table 1) remained. The logistic regression model constructed with these three probes performed well in the TCGA training dataset (Figure 2a, area under the curve (AUC) > 0.99). The unsupervised cluster map of the DNA methylation level of these 3 probes could clearly distinguish tumor samples from normal sam-ples (Figure 2b), indicating that the selected three probes can be used as potential biomarkers for the diagnosis of LUAD.

To further verify the repeatability of our feature selec-tion method and classifier, we verified our model with GEO datasets (GSE39279, GSE52401 and GSE66836). As shown

in Figure 2c and d, the results from the independent valida-tion datasets are also very good (AUC > 0.92), which further indicated the reliability and accuracy of our method and model. In conclusion, our identified potential signatures may be helpful in distinguishing LUAD samples from normal samples, although further verification is needed.

Prognostic model significantly predicts the outcome of LUAD

We first screened five genes from all of the differen-tially expressed genes (see Material and Methods). A cox proportional hazards model was constructed with the five se-lected genes (COL6A6, WFIKKN2, PLA2G1B, UMODL1 and CNGA3, see Table S1) from the TCGA LUAD dataset. Of these genes, PLA2G1B was reported to be associated with smoking-related lung adenocarcinoma (Liu et al., 2016), and UMODL1 may drive lung adenocarcinoma me-tastasis by involving the G-protein coupled receptor protein signaling pathway (Tan et al., 2016). Then, survival analysis was performed for all patients. Finally, the tumor patients were divided into high-risk and low-risk groups, which were

Figure 1 - Differential expression and differential methylation analyses. (a) Volcano plot of differentially expressed genes. (b) PCA of differentially

ex-pressed genes. (c) Volcano plot of differentially methylated genes. (d) PCA of differentially methylated genes.

Table 1 - Detailed information of three methylation markers (probes) for

LUAD diagnosis.

Probe GeneID Gene Symbol Relation To Island Group cg20568402 55208 DCUN1D2 OpenSea Body cg11302791 54984 PINX1 OpenSea Body cg01302240 5998 RGS3 OpenSea TSS200;

verified in the independent data-sets GSE50081 and GSE42127. A summary of the patients in the training and validation datasets for the five-gene-based classifier is listed in Table 2.

As shown in Figure 3, whether in the TCGA training dataset (Figure 3a) or independent validation datasets (Fig-ure 3b-d), the five genes can significantly divide patients into high-risk and low-risk groups (P-value < 0.05), and the prognosis of patients in the high-risk group is significantly worse than that of patients in the low-risk group. In addition, the five potential prognostic markers screened from the LUAD can also significantly divide all NSCLC samples (in-cluding lung squamous carcinoma) into high- and low-risk

groups (P-value < 0.01, Figure 3d), which further illustrates the repeatability of our classifier. We further performed sur-vival analysis with regard to the five-gene-based classifier in subsets of patients with different clinical variables in the TCGA LUAD dataset. When stratified by clinical variables (sex, age, and pathologic stage), the five-gene-based classi-fier was still a statistically significant prognostic model (Fig-ure S1).

The FEM MUC1 was identified in LUAD

We implemented the FEM algorithm (Jiao et al., 2014) to integrate gene expression and DNA methylation data to perform FEM analysis, and four different functional

mod-4 Wang et al.

Figure 2 - Screening of methylation markers for lung adenocarcinoma and the construction and validation of the diagnostic classifier. (a) The ROC curve

of the logistic regression model. (b) Unsupervised clustering map of the methylation profile for the three DNA methylation markers. (c, d) ROC curves in the independent validation datasets.

Table 2 - Characteristics of patients by the five-gene-based classifier assessment set. TCGA LUAD (N=574) GSE50081 (Adenocarcinoma N=127) GSE42127 (Adenocarcinoma N=133) GSE42127 (Squamous N=43) Age (Years, mean± std) 65.52± 9.91 68.73± 9.71 65.76± 10.29 68.11± 7.76 Gender MALE 238 62 65 18 FEMALE 272 65 68 25 Stage I 5 0 0 0 IA 132 36 32 10 IB 134 56 57 13 II 1 0 0 0 IIA 50 7 6 3 IIB 70 28 16 7 IIIA 73 0 7 6 IIIB 11 0 13 4 IV 26 0 1 0 Survival status Alive 317 76 90 22 Dead 181 51 43 21

Survival time (Months, mean± std) 30.41± 30.04 42.39± 27.66 49.67± 31.70 53.53± 34.45 N indicates the number of tumor samples.

Figure 3 - Screening of the prognostic markers for lung adenocarcinoma and the construction of the prognostic classifier. (a) K-M curve in the TCGA

ules were identified in the TCGA dataset: (MUC1) (Figure 4a), ADCY8, CAOLEC10 and WNT3A (Figure S2). Then, in the validation data set (GSE75037 and GSE56044), three modules were identified: MUC1 (Figure 4b), GSTMS and OTX1 (Figure S2), of which, the MUC1 module was identi-fied in both of the datasets. The MUC1 modules identiidenti-fied in the two datasets were significantly overlapping (45 overlap-ping genes, P-value < 0.01, hypergeometric test) (Figure 4 and Table S2).

The genes in the MUC1 module were enriched in the ricin lectin domain structure and participated in biological processes such as O polysaccharide processing, protein

gly-cosylation, keratin sulfate biosynthesis, mucin O polysac-charide biosynthesis, and sheath sugar lipid biosynthesis as well as metabolic signaling pathways (Figure 4). Pro-oncogenic mucin MUC1 was reported to contribute to smoking-induced lung cancers that are driven by inflamma-tory signals from macrophages (Xu et al., 2014). A previous study showed that overexpression of MUC1 induces epithe-lial-mesenchymal transition and promotes the metastasis of lung cancer cells (Xue et al., 2017). In addition, MUC1 was reported to be useful in predicting prognosis in NSCLC pa-tients (Zhu et al., 2014) and may contribute to the treatment of patients with NSCLC resistant to EGFR kinase inhibitors

6 Wang et al.

Figure 4 - Functional epigenetic modules of lung adenocarcinoma. (a) MUC1 module identified in TCGA (left) and enrichment analysis results (right).

(b) MUC1 module identified in the GEO validation set (left) and enrichment analysis (right). The node color indicates the DNA methylation difference (blue indicates high methylation, and yellow indicates low methylation), and the edge color indicates differentially expressed genes (red represents genes with high expression level in tumors and green represents genes with low expression in tumors).

(Kharbanda et al., 2014), indicating that our identified func-tional epigenetic module MUC1 may play an important role in the development and prognosis of LUAD.

Discussion

LUAD is one of the most common neoplasms, and the early diagnosis of LUAD has always been challenging. DNA methylation changes have been reported to occur early in carcinogenesis (Teschendorff et al., 2016), and DNA methylation analysis seems to be a promising strategy in cancer diagnosis. This study used the data of the TCGA LUAD and GEO public datasets, performed an integrative analysis of gene expression and DNA methylation data, and selected three potential DNA methylation biomarkers for the diagnosis of LUAD. All three CpGs are differentially vari-able and differentially methylated CpGs (DVMCs) in the TCGA LUAD dataset (Figure S3). DVMC was defined by Teschendorff et al. (2016) and could be useful to identify field defects. In addition, five potential prognostic gene ex-pression signatures selected from the differentially expres-sed genes could be uexpres-sed to predict the outcome of LUAD patients. We also performed stratification analysis, in which, different clinical variables (sex, age and stage) were evalu-ated separately and our prognostic model could also divide tumor patients into high-risk and low-risk groups with sig-nificantly different outcomes. Finally, we identified the fun-ctional epigenetic module MUC1, which plays a certain role in LUAD, in both the TCGA and GEO datasets. The poten-tial DNA methylation biomarkers identified in this study may be used to design appropriate methylation targeted ther-apies.

Conflict of Interest

The authors report no conflicts of interest and have no relevant disclosures.

Author Contributions

DZ, X.W and YL designed the study and wrote the manuscript. XW and HH conducted the data analysis. FZ, JC and DZ revised and finalized the manuscript. All authors read and approved the final manuscript.

References

Bjaanaes MM, Fleischer T, Halvorsen AR, Daunay A, Busato F, Solberg S, Jorgensen L, Kure E, Edvardsen H, Borresen-Dale AL et al. (2016) Genome-wide DNA methylation analyses in lung adenocarcinomas: Association with EGFR, KRAS and TP53 mutation status, gene expression and prognosis. Mol Oncol 10:330-43.

Der SD, Sykes J, Pintilie M, Zhu CQ, Strumpf D, Liu N, Jurisica I, Shepherd FA and Tsao MS (2014) Validation of a histol-ogy-independent prognostic gene signature for early-stage, non-small-cell lung cancer including stage IA patients. J Thorac Oncol 9:59-64.

Girard L, Rodriguez-Canales J, Behrens C, Thompson DM, Botros IW, Tang H, Xie Y, Rekhtman N, Travis WD, Wistuba II et

al. (2016) An expression signature as an aid to the histologic

classification of non-small cell lung cancer. Clin Cancer Res 22:4880-4889.

Hao X, Luo H, Krawczyk M, Wei W, Wang W, Wang J, Flagg K, Hou J, Zhang H, Yi S et al. (2017) DNA methylation markers for diagnosis and prognosis of common cancers. Proc Natl Acad Sci U S A 114:7414-7419.

Huang da W, Sherman BT and Lempicki RA (2009a) Bioinfor-matics enrichment tools: paths toward the comprehensive functional analysis of large gene lists. Nucleic Acids Res 37:1-13.

Huang da W, Sherman BT and Lempicki RA (2009b) Systematic and integrative analysis of large gene lists using DAVID bioinformatics resources. Nat Protoc 4:44-57.

Huttlin EL, Ting L, Bruckner RJ, Gebreab F, Gygi MP, Szpyt J, Tam S, Zarraga G, Colby G, Baltier K et al. (2015) The BioPlex Network: A systematic exploration of the human interactome. Cell 162:425-40.

Jiao Y, Widschwendter M and Teschendorff AE (2014) A sys-tems-level integrative framework for genowide DNA me-thylation and gene expression data identifies differential gene expression modules under epigenetic control. Bioinformatics 30:2360-6.

Karlsson A, Jonsson M, Lauss M, Brunnstrom H, Jonsson P, Borg A, Jonsson G, Ringner M, Planck M and Staaf J (2014) Ge-nome-wide DNA methylation analysis of lung carcinoma re-veals one neuroendocrine and four adenocarcinoma epitypes

associated with patient outcome. Clin Cancer Res

20:6127-40.

Kharbanda A, Rajabi H, Jin C, Tchaicha J, Kikuchi E, Wong KK and Kufe D (2014) Targeting the oncogenic MUC1-C protein inhibits mutant EGFR-mediated signaling and survival in non-small cell lung cancer cells. Clin Cancer Res 20:5423-34. Li T, Wernersson R, Hansen RB, Horn H, Mercer J, Slodkowicz G, Workman CT, Rigina O, Rapacki K, Staerfeldt HH et al. (2017) A scored human protein-protein interaction network to catalyze genomic interpretation. Nat Methods 14:61-64. Liu NS, Spitz MR, Kemp BL, Cooksley C, Fossella FV, Lee JS,

Hong WK and Khuri FR (2000) Adenocarcinoma of the lung in young patients: the M. D. Anderson experience. Cancer 88:1837-41.

Liu Y, Ni R, Zhang H, Miao L, Wang J, Jia W and Wang Y (2016) Identification of feature genes for smoking-related lung ade-nocarcinoma based on gene expression profile data. Onco Targets Ther 9:7397-7407.

Perez EA (2014) Highlights in breast cancer from the 2014 amer-ican society of clinical oncology annual meeting. Clin Adv Hematol Oncol 12:7-16.

Ramnath N, Dilling TJ, Harris LJ, Kim AW, Michaud GC, Bale-kian AA, Diekemper R, Detterbeck FC and Arenberg DA (2013) Treatment of stage III non-small cell lung cancer: Di-agnosis and management of lung cancer, 3rd ed: American College of Chest Physicians evidence-based clinical practice guidelines. Chest 143:e314S-e340S.

Sandoval J, Mendez-Gonzalez J, Nadal E, Chen G, Carmona FJ, Sayols S, Moran S, Heyn H, Vizoso M, Gomez A et al. (2013) A prognostic DNA methylation signature for stage I non-small-cell lung cancer. J Clin Oncol 31:4140-7.

Shi J, Marconett CN, Duan J, Hyland PL, Li P, Wang Z, Wheeler W, Zhou B, Campan M, Lee DS et al. (2014) Characterizing the genetic basis of methylome diversity in histologically nor-mal human lung tissue. Nat Commun 5:3365.

Shi YX, Wang Y, Li X, Zhang W, Zhou HH, Yin JY and Liu ZQ (2017) Genome-wide DNA methylation profiling reveals

no-vel epigenetic signatures in squamous cell lung cancer. BMC Genomics 18:901.

Tan Q, Cui J, Huang J, Ding Z, Lin H, Niu X, Li Z, Wang G, Luo Q and Lu S (2016) Genomic alteration during metastasis of lung adenocarcinoma. Cell Physiol Biochem 38:469-86.

Tang H, Xiao G, Behrens C, Schiller J, Allen J, Chow CW, Surao-kar M, Corvalan A, Mao J, White MA et al. (2013) A 12-gene set predicts survival benefits from adjuvant chemotherapy in non-small cell lung cancer patients. Clin Cancer Res 19:1577-86.

Teschendorff AE, Gao Y, Jones A, Ruebner M, Beckmann MW, Wachter DL, Fasching PA and Widschwendter M (2016) DNA methylation outliers in normal breast tissue identify field defects that are enriched in cancer. Nat Commun 7:10478.

Toyooka S, Toyooka KO, Maruyama R, Virmani AK, Girard L, Miyajima K, Harada K, Ariyoshi Y, Takahashi T, Sugio K et

al. (2001) DNA methylation profiles of lung tumors. Mol

Cancer Ther 1:61-7.

Toyooka S, Maruyama R, Toyooka KO, McLerran D, Feng Z, Fukuyama Y, Virmani AK, Zochbauer-Muller S, Tsukuda K, Sugio K et al. (2003) Smoke exposure, histologic type and ge-ography-related differences in the methylation profiles of non-small cell lung cancer. Int J Cancer 103:153-60. Toyooka S, Suzuki M, Tsuda T, Toyooka KO, Maruyama R,

Tsukuda K, Fukuyama Y, Iizasa T, Fujisawa T, Shimizu N et

al. (2004) Dose effect of smoking on aberrant methylation in

non-small cell lung cancers. Int J Cancer 110:462-4. Travis WD (2011) Pathology of lung cancer. Clin Chest Med

32:669-92.

Verdecchia A, Francisci S, Brenner H, Gatta G, Micheli A, Man-gone L, Kunkler I and EUROCARE-4 Working Group (2007) Recent cancer survival in Europe: a 2000-02 period analysis of EUROCARE-4 data. Lancet Oncol 8:784-96.

Virmani AK, Tsou JA, Siegmund KD, Shen LY, Long TI, Laird PW, Gazdar AF and Laird-Offringa IA (2002) Hierarchical clustering of lung cancer cell lines using DNA methylation markers. Cancer Epidemiol Biomarkers Prev 11:291-7. Walter RFH, Rozynek P, Casjens S, Werner R, Mairinger FD,

Speel EJM, Zur Hausen A, Meier S, Wohlschlaeger J, Thee-garten D et al. (2018) Methylation of L1RE1, RARB, and

RASSF1 function as possible biomarkers for the differential diagnosis of lung cancer. PLoS One 13:e0195716.

Wei JH, Haddad A, Wu KJ, Zhao HW, Kapur P, Zhang ZL, Zhao LY, Chen ZH, Zhou YY, Zhou JC et al. (2015) A CpG-methylation-based assay to predict survival in clear cell renal cell carcinoma. Nat Commun 6:8699.

Xu X, Padilla MT, Li B, Wells A, Kato K, Tellez C, Belinsky SA, Kim KCn and Lin Y (2014) MUC1 in macrophage: contribu-tions to cigarette smoke-induced lung cancer. Cancer Res 74:460-70.

Xue M and Tao W (2017) Upregulation of MUC1 by its novel acti-vator 14-3-3zeta promotes tumor invasion and indicates poor prognosis in lung adenocarcinoma. Oncol Rep 38:2637-2646. Zhu WF, Li J, Yu LC, Wu Y, Tang XP, Hu YM and Chen YC (2014) Prognostic value of EpCAM/MUC1 mRNA-positive cells in non-small cell lung cancer patients. Tumour Biol 35:1211-9.

Supplementary Material

The following online material is available for this article: Figure S1 - Kaplan Meier curves of the five-genes-based classifier between high-risk and low-risk groups stratified by clinical variables (sex, age, and pathologic stage).

Figure S2 - Other functional epigenetic modules identified in the TCGA dataset (ADCY8, CAOLEC10 and WNT3A) and the validation data set (GSTMS and OTX1).

Figure S3 - Illustration of differentially variable and differ-entially methylated CpGs (DVMCs) for the three diagnostic markers in the TCGA LUAD dataset.

Table S1 - Table of cox proportional hazards model result for the selected five genes used to construct the prognostic model.

Table S2 - Information for the members of MUC1 modules identified in the TCGA and independent validation datasets.
