Smart Farming
Designing a Sensor Device for
Agricultural Environment
Adriane Wassmansdorf Mattos
Final Project Work developed for the attribution of the degree of Master in Product Design
Final document
Trabalho Final de Projecto elaborado para a obtenção do grau de Mestre em Design de Produto
Documento definitivo
Panel/Júri: Carlos Oliveira Santos, Ph.D (Mentor/Orientador) Paulo Alexandre dos Santos Dinis, Ph.D (Panel head/Presidente do júri) António José Morais, Ph.D (Member/Vogal)
Smart Farming
Designing a Sensor Device for
Agricultural Environment
Adriane Wassmansdorf Mattos
Final Project Work developed for the attribution of the degree of Master in Product Design
Final document
Trabalho Final de Projecto elaborado para a obtenção do grau de Mestre em Design de Produto
Documento definitivo
Panel/Júri: Carlos Oliveira Santos, Ph.D (Mentor/Orientador) Paulo Alexandre dos Santos Dinis, Ph.D (Panel head/Presidente do júri) António José Morais, Ph.D (Member/Vogal) December/Dezembro 2016
“I would rather lose money than trust”
ROBERT BOSCH
CONTENTS
