Conservation of Earth Heritage: an approach for a new methodology
Copyright © Telma Filipa Ferreira Chito Ribeiro, Faculdade de Ciências e Tecnologia, Universidade Nova de Lisboa
A Faculdade de Ciências e Tecnologia e a Universidade Nova de Lisboa têm o direito, perpétuo e sem limites geográficos, de arquivar e publicar esta dissertação através de exemplares impressos reproduzidos em papel ou de forma digital, ou por qualquer outro meio conhecido ou que venha a ser inventado, e de a divulgar através de repositórios científicos e de admitir a sua cópia e distribuição com objectivos educacionais ou de investigação, não comerciais, desde que seja dado crédito ao autor e editor.
i After four years of an intense journey around the marvelous world of earthen heritage, where I was able to learn so much, there is a lot of people to thank for it.
My first thought is undoubted to my supervisor – Professor Daniel Oliveira – to whom just expressing my gratitude does not seem enough after all the support, enthusiasm, and energy he gave to this project. I feel so fortunate to have had this opportunity to work not just with one of the best professionals in the field, but with one of the best professors that any student can have. His positive attitude and constant encouragement, and most of all, the fact that he believed in me from day one, is something that I will never forget.
To my co-supervisors – Dra. Susanna Bracci and Professor Márcia Vilarigues – for all the valuable help and guidance through the several stages of this project. The professional approach and care for the students’ work are an inspiration for me.
I would like to thank my tutor and director of the CORES Doctoral Program – Professor Maria João Melo – for helping me to start this work and for giving me this extraordinary opportunity to cross the border of departments and universities.
In my Department of Conservation and Restoration, I am very grateful to Ana Maria, for all the support.
If I can present this work today, I owe it to one person – Professor Paulo Lourenço – who opened the doors of his department, as he can see beyond professional categorizations, and because (as me) he believes in the power of linking knowledge and working in multi-disciplinary teams. For his vision, for all our talks, and for making me feel part of his team I want to express my deep gratitude.
Consequently, I would like to thank the University of Minho in Guimarães for being my home for the last years, especially to the Civil Engineering Department, HMS group, LEST, ISISE, and I-BS. Regarding all my laboratory work, it would not have been possible without the help and precious support of Marco, Sr. Matos, Sr. Gonçalves and Cesar, who were incredibly patient with me, and with whom I learned so much. I am forever grateful to them.
Also, I would like to thank professor Conceição Paiva from the Polymers Department in the University of Minho, for her precious help in material characterization as well as Eng. Maurício and Dr. Paulo Lopes for all the support.
ii and the special bond we developed was extremely important for me. So first I want to thank my incredible Earth Team – Antonio and Claudio – we share this insane passion for earthen construction, and I do not have enough words to describe how much grateful I am for their help, patient, advice, and important discussions, that just made the work easier. Then to all my friends – Meera, Xinyu, Leslie, Alberto, Rafa, Fabio, Nicoletta, Maria Pia, Elesban, and Giorgos – for the incredible support, exchange of knowledge, and all the ludic activities we shared. And finally, a special thanks to my amazing flatmate – Chandan – for his positive energy and strong nature, and for always pushing me to do my best.
To my dear friends and colleagues from Lisbon – Inês, Eva, Joana, and Alexandra – for always being there for me, I feel very blessed for having you in my life.
To my heart-sister Sara, for being the best friend I could ever ask for, proving that true friendship overcomes borders and distances, and without whom I would be completely lost.
To my family, for their unconditional love and support, that even during more difficult moments, always had a positive and reassurance word, giving me the strength to carry on.
And finally, to my mother, to whom I also dedicate this work, for showing me that in life not always the best way is the easiest way, for pushing me to fight for what I want, and most important for being an incredible mother that is always there for me, to listen, to give me advice and to tell me what I do not want to hear. Thank you, mom, for everything.
iii To my grandfather, For showing me the beauty of Nature in all its forms and life, and for always making me look for words in the dictionary.
iv
v A arquitectura em terra constitui um importante legado respeitante à história e evolução da tecnologia da construção, bem como do desenvolvimento das competências humanas, contendo um significativo valor cultural que deve ser preservado. De acordo com a UNESCO, cerca de 10% do Património Mundial é construído em terra, sendo que 57% do mesmo se encontra em perigo. Nos últimos anos assistiu-se a um crescente interesse na preservação património em terra, no entanto existe ainda uma falta de conhecimento na caracterização do material, especialmente do ponto de vista da conservação.
No que respeita a metodologia de intervenção, os profissionais que trabalham com património em terra enfrentam dificuldades em encontrar as melhores soluções, uma vez que na maior parte das vezes não existe uma ligação entre a investigação científica e o conhecimento empírico. É necessária uma abordagem holística para melhorar a metodologia de intervenção. Os produtos disponíveis para a conservação de património imóvel foram amplamente estudados para monumentos em pedra, no entanto são aplicados nos edificados em terra, sem a mesma pesquisa de base.
Embora os produtos comerciais ou sintéticos possam representar uma possível solução para a conservação dos edifícios históricos, não devemos esquecer que o património em terra está associado a uma prática milenar de técnicas de manutenção onde eram usados (e em alguns países ainda são usados) produtos naturais e locais.
Na área da conservação, o processo de consolidação é considerado uma das acções mais sensíveis, uma vez que as opções disponíveis nem sempre oferecem as melhores soluções. Maioritariamente, os produtos aplicados, especialmente no património em terra, não obedecem a dois aspectos fundamentais: compatibilidade e reversibilidade. O mesmo acontece com os produtos hidrorrepelentes, uma vez que os mesmos devem actuar à superfície e como tal, devem estar sujeitos a um plano de manutenção.
O objectivo deste projecto encontra-se dividido em três partes: envolver as ciências da conservação no estudo do património em terra; compreender as metodologias utilizadas em trabalhos de conservação neste tipo de património; e testar em laboratório produtos consolidantes e hidrorrepelentes de origem sintética e natural de forma a avaliar a sua eficácia e possível utilização.
Palavras-chave: património em terra; conservação; metodologia; consolidação; hidrorrepelentes
vi
vii Earthen heritage represents an important legacy regarding construction history, building technology, and expertise development, with a significant cultural value that must be preserved. Moreover, according to UNESCO, about 10% of the World Heritage is built with earth, and 57% of it is in danger.
Although the interest regarding earthen heritage has grown in the last years, there is still a lack of knowledge in material characterization, especially from conservation science point-of-view.
Regarding intervention methodology, professionals working with earthen heritage struggle to find the best solutions, since most of the times, empirical methods and scientific research are not combined.
A holist approach is necessary to improve the applied methodology for conservation practices.
Additionally, products available for building heritage preservation were extensively studied for stone- based monuments, however, they are also being used in earthen ones, without the same research program.
Although synthetic products can represent a solution to restore and conserve historical buildings, one may not forget that earthen heritage is associated with ancient maintenance techniques employing natural and local products that in some countries are still used.
The act of consolidating a degraded surface is, in the conservation field, one of the most sensitive points, since the options available do not offer reliable solutions. Most of the time, the product applied, specifically in earthen heritage, do not embrace two of the most important aspects:
compatibility and reversibility. The same is applied to protective treatments against water since these types of products should work on the material top layers and should have a maintenance plan.
The aim of this project can be divided into three parts: draw the attention from conservation science to earthen heritage; understand which methodology is being used in conservation works; test products for consolidation and water protection from synthetic and natural origin to evaluate their efficiency and possible use.
Keywords: earthen heritage; conservation; methodology; consolidation; water repellent treatments
viii
ix Ribeiro, T., Oliveira, D., & Bracci, S. (2020). Protecting earthen heritage using a green strategy: a study about natural water repellents. Estudos De Conservação E Restauro, (11), 81-92.
https://doi.org/10.34632/ecr.2020.9589
Telma Ribeiro, Daniel V. Oliveira & Susanna Bracci (2020) The Use of Contact Sponge Method to Measure Water Absorption in Earthen Heritage Treated with Water Repellents, International Journal of Architectural Heritage, https://doi.org/10.1080/15583058.2020.1751344
Ribeiro T., Oliveira D.V., Lourenço P.B. (2019) Natural and Synthetic Consolidants for Earth Heritage:
A Review. In: Aguilar R., Torrealva D., Moreira S., Pando M.A., Ramos L.F. (eds) Structural Analysis of Historical Constructions. RILEM Bookseries, vol 18. Springer, Cham. https://doi.org/10.1007/978-3- 319-99441-3_215
x
xi
CHAPTER 1. INTRODUCTION 1
1.1. Introduction 2
1.2. Motivation 4
1.3. Research goals and methodology 5
1.4. Thesis structure 6
CHAPTER 2. EARTHEN CONSTRUCTION: HISTORY AND TECHNIQUE 9
2.1. Brief History of Earthen Construction 10
2.2. History of earthen construction in the Portuguese territory 20
2.3. Earthen Construction Techniques 24
2.3.1. Monolithic group 27
2.3.2. Masonry group 28
2.3.3. Structure group 29
2.4. Earth as a construction material 29
2.4.1. Nature of soil 30
2.4.2. Clay minerals – the binder 31
CHAPTER 3. EARTHEN HERITAGE – CONSERVATION & METHODOLOGY 35
3.1. Conservation of Earthen Heritage 45
3.1.1. The role of the conservator 46
3.1.2. Conservation theory applied to earthen heritage 48
3.1.3. Conservation of Earthen Heritage in Portugal 54
3.1.3.1. Studies of Conservation in Portugal 57
3.2. Methodology of Conservation 59
3.2.1. Identification: documentation and state of conservation assessment 62 3.2.2. Interpretation: diagnosis and identification of decay agents 67 3.2.3. Project: conservation and restoration practices 71
3.2.4. Maintenance: monitoring and inspection 90
3.3. Sustainability in Conservation – a green strategy 91
3.3.1. The need for a new methodology 93
3.3.2. Lessons from Earthen Architecture: using local and natural 94
xii
CHAPTER 4. EXPERIMENTAL WORK – MATERIALS AND METHODS 99
4.1. Material characterization of adobe and rammed earth 101
4.1.1. Particle size distribution 103
4.1.2. Atterberg limits 106
4.1.3. Specific gravity of soil solids 107
4.1.4. Methylene blue test 108
4.1.5. Proctor compaction test 109
4.1.6. Moisture content 109
4.1.7. Porosity 110
4.1.8. XRD 110
4.1.9. EDXRF 112
4.2. Material characterization of consolidants and water repellents 113
4.2.1. Preliminary tests 117
4.2.2. Molecular composition (FT-IR) 120
4.2.3. Density 127
4.2.4. pH 127
4.2.5. Thermal analysis (DSC) 128
4.3. Products application 130
4.4. Testing methods 133
4.4.1. Water absorption assessment – Contact Sponge Method 134 4.4.2. Water repellency assessment – Microdrops absorption time and contact angle 137
4.4.3. Water vapor permeability 138
4.4.4. Colorimetric parameters 139
4.4.5. Compatibility assessment – Scanning Electron Microscope 140
4.4.6. Material loss 141
4.5. Durability 141
4.5.1. Artificial aging test 142
4.5.2. Specimens preparation 143
4.6. Summary 144
CHAPTER 5. EXPERIMENTAL WORK – RESULTS 145
5.1. Efficiency 146
xiii
5.1.3. Water repellency - Contact angle 153
5.1.4. Water vapor permeability 154
5.1.5. Colorimetric parameters 155
5.2. Compatibility 157
5.2.1. Microscopic analysis – SEM 157
5.3. Durability 159
5.3.1. Visual inspection and material loss 159
5.3.2. Contact Sponge Method 166
5.3.3. Microdrops absorption time 168
5.3.4. Contact angle 170
5.3.5. Water vapor permeability 171
5.3.6. Colorimetric parameters 172
5.3.7. Scanning Electron Microscope 173
5.4. Summary 176
CHAPTER 6. CASE STUDY: RAMMED EARTH INSTALLATION 179
6.1. Identification 180
6.2. Interpretation: state of conservation assessment 181
6.3. Project: conservation practice 186
6.3.1. Definition of the strategy 186
6.3.2. Calculation of the sustainability factor 186
6.3.3. Implemented conservation project 187
6.4. Maintenance plan 189
6.5. In situ tests 190
6.5.1. Products application – consolidants 190
6.5.2. Products application – water repellents 191
6.5.3. Visual inspection 191
6.5.4. Cohesion assessment – scotch tape test 192
6.5.5. Water absorption assessment – contact sponge method 194
6.6. Summary 196
CHAPTER 7. FINAL REMARKS AND FUTURE WORK 199
xiv
APPENDIX I. Technical datasheet 221
APPENDIX II. Photographic record before, during, and after the artificial aging of all
specimens 251
APPENDIX III. Obtained data from the experimental campaign 267
APPENDIX IV. Rammed Earth Installation – graphic and photographic record 293
xv Chapter 1
