Two independent methods for mapping
the grounding line of an outlet glacier –
example from the Astrolabe Glacier, Terre
Ad ´elie, Antarctica
E. Le Meur1,2, M. Sacchettini1,2, S. Garambois3, E. Berthier4, A. S. Drouet1,2, G. Durand1,2, D. Young5, J. S. Greenbaum5, D. D. Blankenship5, J. W. Holt5, E. Rignot6,7, J. Mouginot6, Y. Gim7, D. Kirchner8, B. de Fleurian1,2,
O. Gagliardini1,2,9, and F. Gillet-Chaulet1,2
