An improved representation of physical

permafrost dynamics in the JULES land

surface model

S. Chadburn1, E. Burke2, R. Essery3, J. Boike4, M. Langer4,5, M. Heikenfeld4,6, P. Cox1, and P. Friedlingstein1

1

Earth System Sciences, Laver Building, University of Exeter, North Park Road, Exeter EX4 4QE, UK

2

Met Office Hadley Centre, Fitzroy Road, Exeter EX1 3PB, UK

3

Grant Institute, The King’s Buildings, James Hutton Road, Edinburgh EH9 3FE, UK

4

Alfred Wegener Institute, Helmholtz Center for Polar and Marine Research (AWI), 14473 Potsdam, Germany

5

Laboratoire de Glaciologie et Géophysique de l’Environnement (LGGE) BP 96 38402 St Martin d’Hères CEDEX, France

6

Atmospheric, Oceanic and Planetary Physics, Department of Physics, University of Oxford, Parks Road, Oxford OX1 3PU, UK

Received: 19 December 2014 – Accepted: 13 January 2015 – Published: 30 January 2015 Correspondence to: S. Chadburn (s.e.chadburn@exeter.ac.uk)
