PTRwid: a new widget-tool for processing

PTR-TOF-MS data

R. Holzinger

Institute for Marine and Atmospheric Research, Utrecht, IMAU, Utrecht University, Utrecht, the Netherlands

Received: 5 December 2014 – Accepted: 11 January 2015 – Published: 5 February 2015

Correspondence to: R. Holzinger ([email protected])

(2)

AMTD

8, 1629–1669, 2015

R. Holzinger

Title Page

Tables Figures

◭ ◮

Back Close

Full Screen / Esc

Discussion

P

a

per

|

Discussion

P

a

per

|

Discussion

P

a

per

|

Discussion

P

a

per

|

Abstract
