New baseflow separation and recession

analysis approaches for streamflow

M. K. Stewart

Aquifer Dynamics & GNS Science, P.O. Box 30368, 5010 Lower Hutt, New Zealand

Received: 24 May 2014 – Accepted: 16 June 2014 – Published: 27 June 2014

Correspondence to: M. K. Stewart ([email protected])
