Evaluation of the ECHAM family radiation

codes performance in the representation

of the solar signal

T. Sukhodolov1,2, E. Rozanov1,2, A. I. Shapiro1, J. Anet2, C. Cagnazzo3, T. Peter2, and W. Schmutz1

1

Physical-Meteorological Observatory/World Radiation Center, Davos, Switzerland

2

Institute for Atmospheric and Climate Science, ETH Zurich, Zurich, Switzerland

3

Institute of Atmospheric Sciences and Climate of the Italian National Research Council, Rome, Italy

Received: 16 December 2013 – Accepted: 22 January 2014 – Published: 10 February 2014

Correspondence to: T. Sukhodolov (timofei.sukhodolov@pmodwrc.ch)
