Carla Maria Moreira Machado
Mestre em Engenharia MecânicaEmpirical Models for Quantification of
Machining Damage in Composite Materials
Dissertação para obtenção do Grau de Doutor em Engenharia Mecânica
Orientador: Professor Doutor Jorge Joaquim Pamies Teixeira,
Professor Catedrático, Universidade Nova de Lisboa
Júri:
Presidente: Prof. Doutor António Manuel Flores Romão de Azevedo Gonçalves Coelho
Arguentes: Prof. Doutor António Torres Marques Prof. Doutor Luís Miguel Pereira Durão Vogais: Prof. Doutora Maria Teresa Freire Vieira
Empirical Models for Quantification of Machining Damage in Composite Materials
Copyright 2012 by Carla Maria Moreira Machado
Faculdade de Ciências e Tecnologia and Universidade Nova de Lisboa
A Faculdade de Ciências e Tecnologia e a Universidade Nova de Lisboa têm o direito,
perpétuo e sem limites geográficos de arquivar e publicar esta dissertação através de exemplares
Acknowledgments
It's almost impossible to mention all the people who have been important during the
preparation of this work. My acknowledgments are addressed to all those who directly or indirectly
contributed to the completion of this work.
First I would like to thank my supervisor, Professor Pamies Teixeira, who has been
instrumental in guiding me towards the successful completion of this thesis. I also thank for the
patience shown and for teaching me throughout these years the importance of values such as
honesty and scientific rigor. I doubt that I will ever be able to convey my appreciation fully, so I
express him my gratitude and deepest admiration.
My thanks are also address to Eng. Mário Almeida Santos and Eng. José Levezinho from
OGMA for the willingness shown and the composite material provided.
For the readiness in carrying out SEM observations, my sincere thanks to Dr. Nuno Leal
from the Department of Earth Sciences (DCT) FCT-UNL.
A special reference should be made to Professor Luis Durão from ISEP for the information
provided regarding the radiography equipment and X-ray technique.
I extend my gratitude to my colleagues in the Section of Industrial Technology, Professor
Rosa Miranda, Professor Telmo Santos and Professor Caiado Ferreira, for their constant
encouragement and support, especially in the difficult moment I had to go through in elapsing of
this work.
My sincere thanks also go to António Campos, Paulo Magalhães and Maria da Conceição
Pereira for always being present and available to help.
To my friends and colleagues Alberto Martinho, Ana Sofia Matos, Daniel Vaz and Raquel Almeida, I don’t have words to express my gratefulness. They demonstrate, throughout these years, what is the true value of friendship and were always there, helping and incentivizing. I cannot
forget Helena Navas that always shown her readiness to assist, and always had a word of
encouragement.
Finally, I wish to thank my friends and family, especially my mother, for instilling in me
Abstract
The tremendous growth which occurs at a global level of demand and use of composite
materials brings with the need to develop new manufacturing tools and methodologies. One of the
major uses of such materials, in particular plastics reinforced with carbon fibres, is their application
in structural components for the aircraft industry with low weight and high stiffness. These
components are produced in near-final form but the so-called secondary processes such as
machining are often unavoidable. In this type of industry, drilling is the most frequent operation
due to the need to obtain holes for riveting and fastening bolt assembly of structures. However, the
problems arising from drilling, particularly the damage caused during the operation, may lead to
rejection of components because it is an origin of lack of resistance. The delamination is the most
important damage, as it causes a decrease of the mechanical properties of the components of an
assembly and, irrefutably, a reduction of its reliability in use. It can also raise problems with regard
to the tolerances of the assemblies. Moreover, the high speed machining is increasingly recognized
to be a manufacturing technology that promotes productivity by reducing production times.
However, the investigation whose focus is in high speed drilling is quite limited, and few studies on
this subject have been found in the literature review. Thus, this thesis aims to investigate the effects
of process variables in high speed drilling on the damage produced. The empirical models that
relate the delamination damage, the thrust force and the torque with the process parameters were
established using Response Surface Methodology. The process parameters considered as input
factors were the spindle speed, the feed per tooth, the tool diameter and the workpiece thickness. A
new method for fixing the workpiece was developed and tested. The results proved to be very
promising since in the same cutting conditions and with this new methodology, it was observed a
significant reduction of the delamination damage. Finally, it has been found that is possible to use
high speed drilling, using conventional twist drills, to produce holes with good quality, minimizing
the damage.
Keywords: High Speed Drilling; Carbon Fibre Reinforced Plastics; Composite Laminate;
Resumo
O enorme crescimento, a nível global, da procura e utilização de materiais compósitos traz
consigo a necessidade de desenvolvimento de novas ferramentas e metodologias para os processar.
Uma das principais utilizações deste tipo de materiais e em particular dos plásticos reforçados com
fibra de carbono, é a construção de componentes estruturais para a indústria aeronáutica, de baixo
peso e grande rigidez. Estes componentes são produzidos em formas quase-finais mas os processos
secundários, como a maquinagem, podem ser inevitáveis. Neste tipo de indústria, a operação mais
utilizada é a furação, devido à necessidade de obtenção de furos para a rebitagem e fixação
aparafusada das montagens de estruturas. No entanto, os problemas decorrentes da furação,
nomeadamente o dano causado durante a operação, podem levar à rejeição de componentes, por ser
uma origem de falta de resistência. A delaminação é o dano com maior importância, dado causar
uma diminuição das propriedades mecânicas dos componentes e, concludentemente, uma redução
da sua fiabilidade quando em utilização. Por outro lado, a maquinagem de alta velocidade é cada
vez mais reconhecida como tecnologia de fabrico que promove a produtividade, reduzindo os
tempos de produção. No entanto, a investigação realizada cujo enfoque é a furação com alta
velocidade é bastante limitada, tendo sido encontrados na literatura poucos trabalhos acerca deste
tema. Assim, nesta dissertação pretende-se investigar os efeitos das variáveis do processo de
furação a alta velocidade sobre o dano produzido. Utilizando a Metodologia de Resposta em
Superfície, foram estabelecidos modelos empíricos que relacionam o dano de delaminação, a força
axial e o torque com os parâmetros do processo, designadamente a velocidade de rotação, o avanço
por dente, o diâmetro da ferramenta e a espessura da peça. Foi ainda desenvolvido um novo sistema
de fixação da peça e os resultados mostraram-se promissores, uma vez que, nas mesmas condições
de corte, se conseguiu reduzir significativamente o dano. Em termos globais, verificou-se ser
possível utilizar a furação de alta velocidade para produzir furos com minimização do dano, com a
utilização de brocas helicoidais convencionais.
Termos Chave: Furação a Alta Velocidade; Plásticos Reforçados com Fibra de Carbono;
Table of Contents
1
Objectives, Structure of the Thesis and Literature Review
………..
1
1.1 Motivation and Objectives ... 1
1.2 Structure of the Thesis ... 2
1.3 Literature Review ... 4
Materials ... 4
1.3.1 1.3.1.1 Reinforcement fibres ……….11
1.3.1.2 Matrix……….14
1.3.1.3 Prepreg and laminates……….………15
Drilling of Composite Materials ... 18
1.3.2 1.3.2.1 High Speed Drilling……….19
1.3.2.2 Cutting Tool……….22
1.3.2.3 Cutting Parameters..……….………28
1.3.2.4 Damage…………...……….………30
1.3.2.3 Thrust Force, Torque and Tool Wear..……….………34
Concluding Remarks ... 40
1.3.3
2 Methodologies and Techniques ... 41
2.1 Design of Experiments and Response Surface Methodology ... 41
Introduction ... 41
2.1.1 Response Functions for RSM ... 43
2.1.2 Experimental Design for Fitting Second-order Models ... 44
2.1.3 2.1.3.1 Second-order Model……….47
2.1.3.2 Analysis of Variance, Hypothesis Testing and Confidence Intervals.………….49
2.2 Radiographic Analysis ... 52
3 Experimental Procedure ... 55
3.1 Introduction ... 55
4 Discussion of Experimental Results ... 69
4.1 Introduction ... 69
4.2 Experimental Results for Thrust Force ... 70
4.3 Experimental Results for Torque ... 87
4.4 Experimental Results for Delamination Factor ... 96
4.5 New Clamping Method Proposed ... 115
4.6 Concluding Remarks ... 119
5 Conclusions and Future Work ... 121
5.1 Conclusions and contributions ... 121
5.2 Suggestions for Future Work ... 124
References
……….…...127Appendix A - Development of a Torque Sensor
……….
………..…137Appendix B -
LabVIEW
Block Diagram Program
….
.
……….
………141Appendix C - Response Surface Models
……….……….
