Stereoelectronic e
ffects of the glycosidic linkage
on the conformational preference of
D
-sucrose
†
Thiago de Castro Rozada,aRodrigo Meneghetti Pontes,aRoberto Rittnerb
and Ernani Abicht Basso*a
The stereoelectronic effects involved in the conformations shown byD-sucrose were analysed at the
M06-2X/6-31++G(d,p) level, both under vacuum and in water with the continuum solvation model IEF-PCM, and employing the natural bond orbital theory (NBO) and non-covalent interactions (NCI). Different groups of conformations forD-sucrose in relation to the glycosidic linkage were evaluated and the results showed that
not only were hydrogen bonds important to explain the relative energy observed, but it was also necessary to consider any stabilizing orbital interactions involving the glycosidic linkage. The most stable conformation observed in water had dihedral angles for the glycosidic linkage with values of 110.8and
44.9forf and j, respectively.
Introduction
Studies of carbohydrate conformations are important since interactions between carbohydrates and proteins mediate diverse biological processes such as allergic reactions, embryogenesis, tissue maturation, fertilization, metastasis, bacterial cell wall recognition, hydration and stabilisation of proteins.1,2 The processes of recognition of carbohydrates by
proteins are not fully understood.3Since the conformations of
a given molecule can play a central role in the binding mecha-nism, a comprehensive understanding of the conformational behavior of carbohydrates is needed in order to get the correct picture of its action at a particular active site.
Disaccharides are particularly interesting because they have the same rotational degree of freedom as oligo- and poly-saccharides4(a pair of dihedral angles identied as f and j),
but have a structure small enough to allow the application of sophisticated quantum mechanical methods. Different approaches have been used to determine the lower energy combinations of these dihedral angles, including classical based methods (molecular dynamics and molecular mechanics),4–8 and ab initio9,10 and density functional theory
(DFT)11methods.
A comprehensive understanding of the stereoelectronic effects involved in the different conformations of disaccharides
can bring great contributions to the understanding of how these molecules interact with proteins and can assist in the development of new force elds to describe more complex carbohydrates.
D-sucrose is a disaccharide composed of a glucose and a fructose unit connected in the sequencea-D-Glc-(1/ 2)-b-D -Fru (Fig. 1). In the crystalline structure, D-sucrose presents values of 180 and 55 for f and j.12 The conformational
behavior in water, however, has been a point of controversy. While some NMR studies indicate that only one rigid confor-mation (similar to the crystalline structure) is present,13–17 others suggest that the scenario is not so clear and that addi-tional conformations need to be considered in order to get a good correlation between the experimental and theoretical data.18–24These differences arise from the fact that interpreta-tion of the NMR data depends on the structural model applied, and the structural model, in turn, can be very problematic for aexible molecule like a disaccharide. To make the task even
Fig. 1 Definition of the numbering and dihedral angles ofD-sucrose.
a
Departamento de Qu´ımica, Universidade Estadual de Maring´a, Av. Colombo, 5790, 87020-900 Maring´a, PR, Brazil. E-mail: [email protected]; Fax: +55 44 30114125; Tel: +55 44 30114125
bInstituto de Qu´ımica, Universidade Estadual de Campinas, 13083-970 Campinas, SP,
Brazil
† Electronic supplementary information (ESI) available: Dihedral angles, detailed NBO interactions and Cartesian coordinates of the optimized conformations. See DOI: 10.1039/c6ra24413k
Cite this: RSC Adv., 2016, 6, 112806
Received 30th September 2016 Accepted 11th November 2016 DOI: 10.1039/c6ra24413k www.rsc.org/advances
PAPER
Published on 21 November 2016. Downloaded by UNIVERSIDAD ESTADUAL DE CAMPINAS on 18/10/2017 18:15:58.
View Article Online
harder, structural models are highly dependent on the force eld and solvation method applied.
Most of the studies on the conformations ofD-sucrose re-ported in the literature were based solely on classical force elds.18,25–27 While this could be admissible at a time when
computer resources were not available for a system of this size, at present the application of sophisticated electronic structure methods is indispensable. Rened DFT methods are expected to provide more reliable information about the conformational preference of D-sucrose. Also, electronic structure procedures allow the use of tools that can interpret the conformational behavior, like the natural bond orbital (NBO)28 and
non-covalent interaction (NCI)29methods. A study of these
confor-mations is essential for a posterior evaluation of the interac-tions ofD-sucrose with the aromatic residues of amino acids, since carbohydrates are recognized by proteins through inter-actions with the amino acid residues that form the proteins. Among these interactions, the C–H–p interaction stands out, where the C–H bonds of the carbohydrate interact with the p bonds of the aromatic residue of some amino acids. In this way, the conformational study of a carbohydrate is important for the comprehension of what regions of the molecule can interact with the amino acid residues for example. AlthoughD-sucrose presents a different type of glycosidic linkage between two anomeric positions, the conclusions shown in this work with respect to the stereoelectronic effects that stabilize the different conformations of the carbohydrate can contribute to the study of other disaccharides with more usual glycosidic linkages (aldoses). Thus, the main goal of this work is to unequivocally elucidate the conformational behavior ofD-sucrose, as it is not clear in the literature as evidenced by the different analyses involving NMR data. For this purpose, we employed a confor-mational search starting from the crystalline structure (using MCMM/OPLS_2005) and submitted the resulting conformer candidates to calculations using the Minessota M06-2X func-tional.30Thenal structures were then studied with a
combi-nation of NBO and NCI methods. As a result, a complete documentation of the conformational behavior ofD-sucrose is reported hereaer.
Experimental
Theoretical calculations were performed in Linux workstations using the Gaussian 0931 soware package for the electronic
structure calculations, the NBO 5.932 program for analysis
involving the natural bond orbital theory (NBO), the program NCIPlot 3.029to obtain data for the non-covalent interaction
(NCI) analysis and the PyMOL33 program to visualize the
structures and surfaces.
The different conformations of D-sucrose were optimized with the DFT method M06-2X30and the 6-31++G(d,p)34basis set,
both under vacuum and in water. The IEF-PCM solvation method was applied for optimization in water using the Bondi radii for the description of the molecular cavities. The hybrid functional M06-2X is adequate for the obtainment of thermo-dynamic and kinetic data of main group elements and for cases in which non-covalent interactions are important.35 Besides,
this method shows an excellent performance for the energy evaluation of carbohydrates36 with a favorable computational
cost. Frequency calculations at the same theory level were per-formed to characterize the optimized structures as stationary points, and also to obtain the zero point energy correction (ZPE)37 and thermal corrections. Single-point energy
calcula-tions with the MP2 method38and 6-311++G(2df,2pd) basis set
functions were also performed for selected conformations of the carbohydrate under vacuum and in water (IEF-PCM/Bondi). The NBO analysis was performed under vacuum at the M06-2X/6-31++G(d,p) level with the structures optimized in water at the same level of theory. The wave functions utilized for the non-covalent interaction analysis (NCI) were obtained at the M06-2X/6-31++G(d,p) level in water (IEF-PCM/Bondi).
Results and discussion
The work is presented in two subsections. The rst one describes the structures obtained in our study and the next one discusses the stereoelectronic effects involved in the confor-mational preference of such structures.
Structural features
Table 1 shows the observed relative energies for the different conformations ofD-sucrose studied both under vacuum and in water with the implicit solvation model. The structures were grouped according to the dihedral angles f and j of the glycosidic linkage in seven different groups (S1–S7) and were also identied regarding the adopted orientation of dihedral anglesu1(O5–C5–C6–O6), u2(O8–C8–C7–O7) and u3(O8–C11–
C12–O12), as shown in Fig. 1, as gauche–gauche (gg, with respect
Table 1 Relative energy (kcal mol 1) for the conformations of
D
-sucrose (with ZPE correction) at the M06-2X/6-31++G(d,p) level under vacuum and in water (IEF-PCM/Bondi)
Entry Conformer DEvac. DEwater
1 S1-gg-tg-gg 0.38 0.08 2 S1-gt-tg-gg 0.58 0.00 3 S1-tg-tg-gg 0.00 1.01 4 S1-gt-tg-ggccw 2.27 0.75 5 S2-gg-gt-tg 10.09 6.95 6 S2-gg-gt-gg 5.67 2.07 7 S2-gg-tg-gg 7.51 5.11 8 S2-gt-gt-gg 7.16 1.79 9 S2-tg-gt-gg 9.74 7.58 10 S2-tg-gt-gg 5.73 3.10 11 S3-gt-tg-gt 7.73 3.21 12 S3-tg-tg-tg 8.21 4.49 13 S4-gg-gt-tg 10.92 7.67 14 S4-gg-gt-tg 9.55 8.34 15 S4-gg-gt-gt 10.38 6.95 16 S4-gt-gg-gt 9.20 5.74 17 S4-gt-gt-tg 11.21 7.57 18 S4-tg-gt-tg 11.46 8.50 19 S4-tg-gt-gt 7.84 5.39 20 S5-gg-tg-gg 7.90 4.15 21 S6-gg-tg-tg 7.72 8.13 22 S7-gg-tg-gg 8.19 4.89
to C5–O5 and C4–C5, respectively), gauche–trans (gt, with respect to C8–O8 and C8–O1, respectively) and trans–gauche (tg, with respect to C11–O8 and C10–C11, respectively). The specic dihedral angle values calculated both under vacuum and in water are present in the ESI.†
The S1 group of conformations obtained were based on the dihedral anglesf and j of the glycosidic linkage of the X-ray structure (108and 55, respectively) and they also correlate with the dihedral angles of the most stable conformation found by Case18(105and 60forf and j, respectively). The average
dihedral angle of 111.5off for the conformations of the group S1 in water was only 3.5larger than the same dihedral angle of the crystalline structure, while on the structure M1 obtained by Case this dihedral angle was 3 smaller than the crystalline structure. For the dihedral anglej, the average dihedral angle of the conformations of the group S1 was 5below the crystal-line structure and around 10less than M1. The dihedral angles f and j of the S3 group conformations are also close to the crystalline structure and to the M1 structure. Nevertheless, the average dihedral anglef of 99.3for the group S3 conforma-tions is about 9smaller than the crystalline structure, while for the conformations of the group S1 this dihedral angle is larger than the crystalline structure. However, the average dihedral anglej of 53.3for the conformations of the group S3 in water differs by only 0.7 from the dihedral angle in the crystalline structure. The conformations of the group S2 in turn have the dihedral anglesf and j of the glycosidic structure (94.1and 164.3, respectively) close to the structure M3 obtained by Case (85and 165forf and j, respectively).
Under vacuum, only the conformations of the group S1 have a relevant contribution to the equilibrium (entries 1–4, Table 1). The other groups showed a pronounced reduction in the rela-tive energy compared to the group S1 with an inclusion of the continuous solvation model, with the exception of the group S6. However the group S1 still was the predominant conformation in the equilibrium.
In relation to the dihedral angleu1of the group S1
confor-mations, it was observed that the conformation trans–gauche was the most stable under vacuum, but it became the least stable of the three conformations in water. The orientation of the exocyclic groups can also contribute to the stability of one conformation allowing interactions like hydrogen bonds to form between the hydroxyl groups of the pyranosidic and fur-anosidic portions of the disaccharide.
Regarding the hydroxyl group orientation, the clockwise arrangement (S1-gt-tg-gg) was more stable than the counter-clockwise arrangement (S1-gt-tg-ggccw) both under vacuum and in water. These hydroxyl orientations are an outcome of the destabilizing steric effects and the attractive interactions of hydrogen bonds. The QTAIM and NCI analysis for D-glucose showed that the hydrogen bonds formingve membered rings are weak or non-existent and the hydroxyl arrangements are directed by the lone pair repulsion between the endocyclic oxygen and the oxygen bonded to the anomeric carbon.39
To evaluate the stereoelectronic effects involved in the conformational preference of D-sucrose, the most stable conformations of the groups S1–S3 in water were selected for
the NBO and NCI analysis. The different conformations for the group S1 regarding the dihedral angleu1were also analysed to
investigate the inuences on the glycosidic portion of the molecule. The relative energies for these conformations calcu-lated at different theory levels are shown in Table 2 and the optimized structures are presented in Fig. 2.
The range of the dihedral anglesf observed for the more stable conformations of the groups S1–S3 in water was below 20. For the most stable conformation of the group S1 this dihedral angle was 110.8, while for the conformations of the groups S2 and S3 the dihedral angles were close, with values of 93.8 and 95.5, respectively. However, the dihedral angle j showed greater variations between the different groups of conformations. The S1 conformation had a dihedral anglej of 44.9, while for the conformation of the group S2 this dihedral angle was 160.1. For the conformation of the group S3 it was 61.9. Based on these dihedral angles and on the structures a– c presented in Fig. 2 it can be seen that the main difference between the conformation S1 and S2 is related to the orienta-tion of the furanosidic part of D-sucrose, while the main difference between S1 and S3 was the observed hydrogen bond interactions.
Forces underlying the conformational preference
Intramolecular hydrogen bonds are responsible for the conformation adopted in the crystalline structure ofD-sucrose and these kinds of interactions were a characteristic that was observed for all conformations. The crystalline structure has an interaction between O2 and the hydroxyl O7–H (distance of 1.85 ˚A) and a hydrogen bond interaction between O5 and O12–H (distance of 1.89 ˚A).12The hydrogen bond interactions can be
observed in Fig. 3, which shows the non-covalent interaction surface (NCI), where the blue colour surface represents the strong attractive non-covalent interactions of the hydrogen bonds, the green colour represents the van der Waals interac-tions and the red colour represents the steric interacinterac-tions. Fig. 4 shows the reduced density gradient versus the electronic density multiplied by the signal of the second Hessian eigenvalue for
Table 2 Relative energies (kcal mol 1) for the main conformations of
D-sucrose and different conformations of S1 regarding the dihedral angleu1at different theory levels
Entry Conformer
M06-2Xa MP2b
DEvac. DEwat. DEvac. DEwat.
1 S1-gt-tg-gg 0.58 0.00 0.25 0.00 2 S2-gt-gt-gg 7.16 1.79 8.14 2.29 3 S3-gt-tg-gt 7.73 3.21 9.32 3.21 4 S1-gg-tg-gg 0.38 0.08 0.00 0.44 5 S1-tg-tg-gg 0.00 1.01 0.31 1.44 6 S1-gt-tg-ggccw 2.27 0.75 2.45 0.66
aOptimization with the 6-31++G(d,p) basis set function, ZPE correction
and IEF-PCM/Bondi solvation model when in water. bEnergy
calculation with the 6-311++G(2df,2pd) basis set function and IEF-PCM/Bondi solvation model when in water.
the three conformations of the groups S1–3 ofD-sucrose used for obtainment of the NCI surfaces.
It was observed that there were three interaction points which were characterized as hydrogen bonds by the NCI anal-ysis for the conformation of the group S1. The rst one is between O5 and the hydroxyl O12–H (1.97 ˚A), the second one is between O12 and the hydroxyl O6–H (1.82 ˚A) and the third one is between O2 and the hydroxyl O7–H (1.97 ˚A). For the confor-mation of the group S2 only one hydrogen bond interaction was observed, between O2 and the hydroxyl O9–H (1.94 ˚A), and for the conformation of the group S3 three interactions were observed, one between O1 and the hydroxyl O9–H (2.01 ˚A), one between O2 and the hydroxyl O7–H (1.93 ˚A) and one between O6 and the hydroxyl O12–H (1.84 ˚A).
To investigate the importance of the hyperconjugative interactions for the greater stability of the conformation of the group S1 over the conformations of the groups S2 and S3, energy calculations were performed where electron transfer from a donor orbital to an acceptor orbital was prevented. That is, the bonding orbitals contained the maximum occupancy possible (two electrons), similar to the Lewis description. Then this energy was compared with the energy obtained before the removal of the hyperconjugative interactions and the difference in energy indicates the importance of the hyperconjugative interactions for each conformer. The energy variation obtained in this analysis is presented in Table 3. The conformation S1-gt-tg-gg presents the biggest stabilizing effects due to the hyper-conjugative interactions. The preference for this conformation Fig. 2 Optimized structures at the M06-2X/6-31++G(d,p) level in water (IEF-PCM/Bondi) for the conformations ofD-sucrose. (a) S1-gt-tg-gg; (b)
S2-gt-gt-gg; (c) S3-gt-tg-gt; (d) S1-gg-tg-gg; (e) S1-tg-tg-gg; (f) S1-gt-tg-ggccw.
Fig. 3 Surfaces of the non-covalent interactions for the conformations ofD-sucrose. (a) S1-gt-tg-gg; (b) S2-gt-gt-gg; (c) S3-gt-tg-gt. Isosurface
of 0.5 au. Surfaces are coloured on a blue-green-red scale ( 0.04 to 0.02 au) according to the values of sign (l2)r.
over the other conformations of the group S1 was also corre-lated with its larger hyperconjugative effect. However, the most stable conformation of the group S1 also presents the biggest destabilizing energy due to repulsion between the occupied orbitals. One reason for this greater destabilizing effect is the greater proximity between the hydroxyl groups provided by the hydrogen bonding interactions.
A detailed investigation of the effects involved in the conformational preference of D-sucrose could be obtained by the NBO analysis of the orbital interaction.† Interactions were observed like hydrogen bonds where the oxygen lone pairs act as the donor orbital and thes* of the O–H bond acts as the acceptor orbital, interactions involving the orbitals of the glycosidic bonds C1–O1 and O1–C8, through-space interactions different to hydrogen bonds between the pyranosidic and fur-anosidic ring and interactions involving the dihedral angleu1.
The hydrogen bond interactions favor the conformation of the group S1 (37.56 kcal mol 1), followed by the conformations of the groups S3 and S2 (34.04 and 27.29 kcal mol 1, respec-tively). The conformation of the group S2 has the largest stabilizing hyperconjugative effect involving the orbitals of the bonds C1–O1 and O1–C8 (110.02 kcal mol 1), but with a small
difference compared to the conformation of the group S1 (109.50 kcal mol 1). For the conformation of the group S3 this interaction has an energy of 104.90 kcal mol 1. Through-space
interactions, other than hydrogen bonds, were only observed for the conformations of the groups S2 and S3 (1.26 and 2.40 kcal mol 1, respectively).
Altogether, a great contribution of the hydrogen bond interactions and hyperconjugative interactions involving the orbitals of the glycosidic linkage to the stabilization of the conformations of the group S1 was observed and that overrides the biggest repulsive steric interactions observed for this group. The conformation of the group S2 presents a stabilization energy only slightly smaller than the conformation of the group S3, but with repulsive interactions that favoured this confor-mation over the conforconfor-mation of the group S3. Although the stabilizing energies of the conformations of the groups S2 and S3 are close to each other, they differ in the type of interactions. For the conformation of the group S3 it is the hydrogen bonds and other through-space interactions that stand out over the conformation of the group S2, while for this last conformation it is the interactions involving the glycosidic linkage and the dihedral angle u1 that stand out in the conformation of the
group S3.
Table 4 presents the occupancy of some of the acceptor orbitals for the different conformations of D-sucrose. Higher occupancy values for acceptor orbitals indicate higher electron delocalization to these orbitals.
The rst four orbitals shown in Table 4 are the acceptor orbitals of the hydrogen bond interactions. The interaction involving the orbitals*O7 H is relevant for the three groups of conformations. The interactions involving the orbitals*O12 Hare more pronounced for the conformations of the groups S1 and S3, while the interactions involving the orbitals*O9 Hhave more relevance for the conformation of the group S2. The occupancy also highlights the importance of the delocalization involving the orbitals*O6 Hto the greater stabilization of conformation S1-gt-tg-gg.
Fig. 4 Plot of the reduced density gradient versus the electron density multiplied by the sign of (l2)r for the conformations ofD-sucrose. (a) S1-gt-tg-gg; (b) S2-gt-gt-gg; (c) S3-gt-tg-gt.
Table 3 Energy changes due to hyperconjugation (kcal mol 1) and steric energy (kcal mol 1) for the conformations ofD-sucrose calcu-lated at the M06-2X/6-31++G(d,p) level
Entry Conformer DEhyperconj. Steric energy Vacuum Water 1 S1-gt-tg-gg 1005.850 991.662 835.34 2 S2-gt-gt-gg 997.713 981.088 827.59 3 S3-gt-tg-gt 996.652 981.135 832.25 4 S1-gg-tg-gg 993.202 980.545 829.01 5 S1-tg-tg-gg 994.186 981.725 832.76 6 S1-gt-tg-ggccw 1011.711 995.378 835.74
Table 4 Orbital occupancies for the conformations of D-sucrose calculated at the M06-2X/6-31++G(d,p) level
Conformer s*O7H s*O12H sO6H* s*O9H s*C1O1 s*C8O1 S1-gt-tg-gg 0.02316 0.02883 0.03103 0.00977 0.05448 0.07749 S2-gt-gt-gg 0.02641 0.01881 0.00504 0.02864 0.05748 0.08299 S3-gt-tg-gt 0.02572 0.03049 0.00670 0.01476 0.05926 0.07330 S1-gg-tg-gg 0.02570 0.02860 0.00726 0.01148 0.05464 0.07873 S1-tg-tg-gg 0.02649 0.02823 0.00476 0.01127 0.05458 0.07859 S1-gt-tg-ggccw 0.00953 0.02966 0.03091 0.00465 0.05689 0.07655
Regarding the dihedral angleu1for the conformations of the
group S1, it was observed that the conformation S1-gt-tg-gg (with a conformation gauche–trans for the referred dihedral angle) presents the largest energy variation with deletion of the hyperconjugative interactions both under vacuum and in water. This conformation showed the largest destabilizing interactions due to repulsion between the occupied orbitals (835.34 kcal mol 1), followed by conformations S1-tg-tg-gg and S1-gg-tg-gg (832.76 and 829.01 kcal mol 1, respectively).
The higher stability of the conformation gauche–trans is directly related to the interaction involving the lone pairs of oxygen O12 with the orbitals*O6 H (4.71 and 12.36 kcal mol 1). This interaction is not possible for the conformations gauche– gauche and trans–gauche of the dihedral angle u1. If the
inter-action hO12/s*O6 H was not considered, the observed hyper-conjugative energy related to the dihedral angleu1would be
larger for the conformation gauche–gauche (19.30 kcal mol 1),
followed by the conformations gauche–trans (18.65 kcal mol 1)
and trans–gauche (13.97 kcal mol 1).
To summarize, the dihedral angles of 110.8and 44.9for f and j, respectively, observed for the most stable conforma-tion of the group S1 allowed better hydrogen bond interacconforma-tions and good stabilizing orbital interaction involving the glycosidic linkage. For the conformation of the group S2 the dihedral angle of 93.8forf and 160.1forj led to a good stabilization energy due to the interactions between the orbitals involved in the glycosidic linkage, but with this spatial arrangement only one hydrogen bond was observed. The dihedral angles of 95.5 and 61.9 (entry 11, Table S2†) for f and j, respectively, observed for conformation S3 led to three hydrogen bond interactions, which are smaller than the observed dihedral angles for the conformation of the group S1 and the orbital interactions involving the glycosidic linkage were the smallest of the three conformations analysed by NBO.
Conclusions
The theoretical study performed for D-sucrose showed that employing a continuum solvation model in water decreases the difference of the relative energy between the different groups of conformations. The NBO analysis assisted in the comprehen-sion of the stereoelectronic effects involved in the conforma-tional preference observed and the NCI analysis provided an excellent visualization of the non-covalent interactions. One predominant conformation in the equilibrium (group S1) was observed for D-sucrose that is stabilized by three different hydrogen bond and orbital interactions involving the glycosidic linkage. The other conformations ofD-sucrose (groups S2 and S3) studied presented smaller stabilizing orbital interactions than the conformation of the group S1, but revealed the importance of orbital interactions other than the hydrogen bond to stabilize the conformations ofD-sucrose.
Acknowledgements
The authors would like to thank the Brazilian Council for Scientic and Technological Development (CNPq) for the
fellowship for E. A. B. and R. R. and for the scholarship for T. C. R. Thanks also goes to Fundaç˜ao Arauc´aria (Grant 211-14-20133971) and FAPESP (Grant 2014/25903-6) fornancial support.
