Influence of anisotropy on velocity and

age distribution at Schar

_ff

enbergbotnen

blue ice area

T. Zwinger1, M. Schäfer2, C. Martín3, and J. C. Moore2,4,5

1

CSC-IT Center for Science Ltd., Espoo, Finland 2

Arctic Centre, University of Lapland, Rovaniemi, Finland 3

British Antarctic Survey, Cambridge, UK 4

College of Global Change and Earth System Science, Beijing Normal University, Beijing, China

5

Department of Earth Sciences, Program for Air, Water and Landscape Sciences, Uppsala University, Uppsala, Sweden

Received: 29 April 2013 – Accepted: 21 May 2013 – Published: 25 June 2013
