Abstract
The measurement of atmospheric concentrations by a monitoring network is poten-tially a useful tool investigated for the identification of the widespread sources of trace species. The paper addresses inversion strategies using base functions multiplicatively deduced from the concentrations adjoint to the measurements. This follows the con-5
cept of illumination: the various regions are well, poorly or not seen at all. With ordinary adjoint functions the illumination becomes excessive close to the detectors. This may be corrected by attributing each point of the space time domain a geometric weight. Af-ter stating the statistical implications, the choice of this renormalising function is shown to be constrained by an unambiguous formal criterion. The expectable values of the 10
measurements are distinguished from the measurement errors. The entropic nature of the criterion is explained; it amounts to evenly distribute the information between the points organised with their weights as a “known domain” describing the influence of the measurements. Finally the criterion is shown to coincide with the definition of the pure states of quantum statistics, and this interpretation is investigated to describe the 15
influence of the measurement uncertainties on the quality of a source estimate. The theory is illustrated by calculations performed with the experimental source ETEX1.
1. Introduction
The atmospheric transport of tracers, especially the linear ones, is an active domain (Gallardo et al.,2002;Clerbaux et al.,2003;Baklanov and Mahura,2004) with many 20
investigations about the inverse problems (Bousquet et al., 2000; R ¨odenbeck et al., 2003). The natural interpretation of a measurement goes through its adjoint function (Marchuk,1992; Robertson and Persson, 1993;Penenko and Baklanov,2001). The localisation of accidental point sources has been widely studied (Sharan et al.,1995; Pudykiewicz, 1998; Seibert, 2001; Roussel et al., 2002; Issartel and Baverel, 2003; 25
Penenko et al.,2002). The reconstruction of the widespread sources of such species
