This discussion paper is/has been under review for the journal Climate of the Past (CP). Please refer to the corresponding final paper in CP if available.

High-resolution glacial and deglacial

record of atmospheric methane by

continuous-flow and laser spectrometer

analysis along the NEEM ice core

J. Chappellaz1,***, C. Stowasser2,***, T. Blunier2, D. Baslev-Clausen2, E.J. Brook3, R. Dallmayr1,*, X. Fa¨ın1, J.E. Lee3, L.E. Mitchell3, O. Pascual1, D. Romanini4,
