Evaluation of OMI operational standard
NO
2
column retrievals using in situ and
surface-based NO
2
observations
L. N. Lamsal1,2, N. A. Krotkov2, E. A. Celarier1,2, W. H. Swartz3,2, K. E. Pickering2, E. J. Bucsela4, R. V. Martin5,6, S. Philip5, H. Irie7, A. Cede8,2, J. Herman9,2,
A. Weinheimer10, J. J. Szykman11, and T. N. Knepp12,13 1
