Estimation of aerosol water and chemical composition from
AERONET Sun–sky radiometer measurements at Cabauw,
the Netherlands
A. J. van Beelen1, G. J. H. Roelofs1, O. P. Hasekamp2, J. S. Henzing3, and T. Röckmann1
1Institute for Marine and Atmospheric research Utrecht (IMAU), P.O. Box 80005, Utrecht University, Utrecht, the Netherlands
2Netherlands Institute for Space Research (SRON), Sorbonnelaan 2, 3584 CA Utrecht, the Netherlands 3Netherlands Organisation for Applied Scientific Research, TNO, P.O. Box 80015, Utrecht, the Netherlands
Correspondence to: A. J. van Beelen (a.j.vanbeelen@uu.nl)
Received: 26 March 2013 – Published in Atmos. Chem. Phys. Discuss.: 10 June 2013 Revised: 11 April 2014 – Accepted: 24 April 2014 – Published: 18 June 2014
Abstract. Remote sensing of aerosols provides important information on atmospheric aerosol abundance. However, due to the hygroscopic nature of aerosol particles observed aerosol optical properties are influenced by atmospheric hu-midity, and the measurements do not unambiguously charac-terize the aerosol dry mass and composition, which compli-cates the comparison with aerosol models. In this study we derive aerosol water and chemical composition by a mod-eling approach that combines individual measurements of remotely sensed aerosol properties (e.g., optical thickness, single-scattering albedo, refractive index and size distribu-tion) from an AERONET (Aerosol Robotic Network) Sun– sky radiometer with radiosonde measurements of relative hu-midity. The model simulates water uptake by aerosols based on the chemical composition (e.g., sulfates, ammonium, ni-trate, organic matter and black carbon) and size distribu-tion. A minimization method is used to calculate aerosol composition and concentration, which are then compared to in situ measurements from the Intensive Measurement Campaign At the Cabauw Tower (IMPACT, May 2008, the Netherlands). Computed concentrations show good agree-ment with campaign-average (i.e., 1–14 May) surface obser-vations (mean bias is 3 % for PM10 and 4–25 % for the in-dividual compounds). They follow the day-to-day (synoptic) variability in the observations and are in reasonable agree-ment for daily average concentrations (i.e., mean bias is 5 % for PM10and black carbon, 10 % for the inorganic salts and 18 % for organic matter; root-mean-squared deviations are 26 % for PM10and 35–45 % for the individual compounds).
The modeled water volume fraction is highly variable and strongly dependent on composition. During this campaign we find that it is>0.5 at approximately 80 % relative hu-midity (RH) when the aerosol composition is dominated by hygroscopic inorganic salts, and<0.1 when RH is below 40 %, especially when the composition is dominated by less hy-groscopic compounds such as organic matter. The scattering enhancement factor (f(RH), the ratio of the scattering coef-ficient at 85 % RH and its dry value at 676 nm) during 1–14 May is 2.6±0.5. The uncertainty in AERONET (real) refrac-tive index (0.025–0.05) is the largest source of uncertainty in the modeled aerosol composition and leads to an uncertainty of 0.1–0.25 (50–100 %) in aerosol water volume fraction. Our methodology performs relatively well at Cabauw, but a better performance may be expected for regions with higher aerosol loading where the uncertainties in the AERONET in-versions are smaller.
1 Introduction
forcing. Estimates of radiative forcing from models range from −0.2 to −0.9 W m−2 for the direct effect and −0.5 and−1.5 W m−2for the indirect effect (Forster et al., 2007; Quaas et al., 2009), while remote sensing estimates yield be-tween−0.9 and−1.9 W m−2for the direct effect (Bellouin et al., 2005; Quaas et al., 2008) and −0.2±0.1 W m−2for the indirect effect (Quaas et al., 2008). More recent esti-mates of the aerosol radiative effects from models and re-mote sensing tend to converge (e.g., Bellouin et al., 2008; Myhre, 2009; Lohmann et al., 2010), but the uncertainty re-mains large (Loeb and Su, 2010; Schulz et al., 2010; Kahn, 2012; Bellouin et al., 2013; Myhre et al., 2013a). The un-certainty in aerosol forcing leads to large uncertainties in the estimates of climate sensitivity and future projections of cli-mate change (Andreae et al., 2005; Myhre et al., 2013b).
A better characterization of the aerosol chemical com-position and hygroscopicity is a necessary step in reducing these uncertainties. Aerosol properties such as size distribu-tion and chemical composidistribu-tion are often measured in situ, for example during dedicated measurement campaigns (e.g., Yu et al., 2009; Kulmala et al., 2011). These measurements are relatively detailed and accurate, but they are only repre-sentative of small areas, most of which are in the Northern Hemisphere. Remotely sensed aerosol properties (e.g., from AERONET (Holben et al., 1998), MODIS (King et al., 1992) and POLDER/PARASOL (Deschamps et al., 1994; Tanré et al., 2011)) are available at larger spatial scales, but they re-flect a contribution of aerosol water. The amount of aerosol water, and thus total aerosol mass and size, is strongly depen-dent on not only the aerosol composition (hygroscopicity) but also on relative humidity (RH). Discrepancies between remotely sensed aerosol properties and aerosol–climate mod-els can thus be caused by the description of RH or aerosol processes in the model (e.g., Bian et al., 2009; Zhang et al., 2012), which complicates the validation of aerosol properties in aerosol–climate models.
In order to quantify the water contribution to AOT (aerosol optical thickness), several studies have retrieved aerosol wet growth or scattering enhancement factors due to aerosol wa-ter uptake. Schuswa-ter et al. (2009) derive the aerosol wawa-ter fraction directly from measurements of the refractive index and mass conservation, but they apply an empirical rela-tion to constrain the insoluble-to-soluble aerosol mass ra-tio. Jeong et al. (2007) derive vertical profiles of the aerosol humidification factor (the ratio of the scattering coefficient of aerosol at ambient RH and at dry (40 % RH) conditions) over the Southern Great Plains (USA) using airborne aerosol measurements of scattering and absorption under high- and low-humidity conditions, together with ambient RH, tem-perature and pressure profiles. Ganguly et al. (2009) use monthly average AERONET AOT, SSA (single-scattering albedo) and volume distribution, and MPLNET (Micro-pulse Lidar Network) extinction profiles to retrieve vertical pro-files of aerosol chemical compounds, assuming specific size distributions for each aerosol component. Finally, Wang et
al. (2013) use AERONET imaginary refractive index and SSA to retrieve columnar black carbon, brown carbon and dust in Beijing, China.
We present first results of a modeling approach that es-timates the aerosol dry mass, the masses of several aerosol species, and aerosol water based on AERONET data from Cabauw (the Netherlands). The methodology is applied to individual measurements so that the short-term variability of the concentrations is resolved. The model simulates hy-groscopic growth and optical characteristics of an aerosol population that is initialized with an a priori size distribu-tion and chemical composidistribu-tion. In an iterative procedure the modeled aerosol properties are optimized in order to min-imize the differences between observations and the model results. The resulting aerosol properties are compared with detailed measurements, with a focus on chemical composi-tion, from the measurement campaign IMPACT (Intensive Measurement Period At the Cabauw Tower; Kulmala et al., 2009; 2011; Mensah et al., 2012) during May 2008. Aerosol characteristics resulting from this method can be used for a more consistent comparison of modeled and remotely sensed aerosol properties, as well as for a better understanding of aerosol–humidity and aerosol–cloud interactions (Feingold, 2003; Jeong et al., 2007; Koren et al., 2007; Roelofs and Kamphuis, 2009). Section 2 describes the model, the mea-surements and the minimization procedure, and presents a brief literature overview of specific weights and refractive in-dices associated with aerosol chemical components. In Sect. 3 we present the resulting aerosol chemical composition and compare it with measurements from IMPACT. Section 4 presents conclusions and a discussion of the results.
2 Methodology 2.1 Model
We use a microphysical aerosol model that calculates aerosol water uptake by considering aerosol chemical composition, size distribution and relative humidity. The aerosol optical properties are computed and compared to AERONET re-trievals. Aerosol chemical composition and size distribution are found using an optimization method. This involves in-verting the following equation:
y=F (x)+Ey. (1)
Table 1. Overview of the parameters in the state vector (x). Subscripts f and c denote fine and coarse mode, respectively.
x Description Remarks
mf,mc(SO4) column-average mass mixing ratio sulfate The inorganic composition is determined from sulfate by using (fixed) ammonium-to-sulfate and nitrate-to-sulfate ratios (see text).
mf,mc(OC) mass mixing ratio organic carbon Water uptake is determined assuming 20 % wt levoglucosan, 40 % wt succinic acid and 40 % wt Suwannee River reference fulvic acid (Sven-ningsson et al., 2006).
mf,mc(BC) mass mixing ratio black carbon –
Nf,Nc column-average number concentration –
σf,σc (geometric) standard deviation Fine- and coarse-mode aerosols are assumed to be lognormally dis-tributed. Geometric standard deviation of each mode can be varied by the model.
SPH aerosol spherical fraction Only used when the (440–870 nm) Ångström exponent is<1.2 and the
AOT is>0.1, otherwise SPH = 1.
RH column-average relative humidity Initial guess is derived from sounding data.
Table 2. Overview of the parameters in the measurement vector (y) and the uncertaintiesEyinyused in this study.
y Description Ey
RRI(λ) real part of the refractive index for four ERRI=max0.005RRI /AOT440 nm,0.025
wavelengths (λ= 440, 676, 870, 1020 nm)
IRI(λ) imaginary part of the refractive index EIRI=IRI max1(1+2.5(AOT440 nm−0.05)) ,0.5
AOT(λ) aerosol optical thickness EAOT=0.01
SSA(λ) single-scattering albedo ESSA=0.07(1+3(AOT440 nm−0.05))
Vi volume distribution in 22 bins EV =0.15V∗
SPH aerosol spherical fraction ∼25 %
RHprior column-average relative humidity from soundings ∼10 %∗
∗Approximation; see text.
uncertainty estimates of the parameters in y. In an itera-tive procedure the parameters in x are adjusted so that the discrepancies between modeled and observed aerosol opti-cal properties, size distribution and RH are minimized. An overview of the model structure is presented in Fig. 1. 2.1.1 Aerosol: initialization, water uptake and optical
properties
Tables 1 and 2 present an overview of the parameters in x
andy together with their uncertainty estimates used in this study. The model describes aerosol using dry mass mixing ratios, the number concentrations and (geometric) standard deviations of lognormal fine and coarse modes, assuming in-ternally mixed randomly oriented spheroid particles. Aerosol chemical species considered by the model are sulfate (repre-sented as a mixture of H2SO4, NH4HSO4and (NH4)2SO4), ammonium nitrate (NH4NO3), sea salt (NaCl), organic mat-ter (OC), black carbon (BC), and mineral dust. We remark that sea salt and mineral dust have been omitted from this study for reasons explained in Sect. 2.2.1.
The hygroscopic growth of aerosols can be described from their chemical composition by the Köhler relation (Köhler, 1936), a combination of Raoult’s law for water activity (aw)
Figure 1. Flow diagram of the model. The state vectorxcontains the initial guess, which can be updated by the minimization routine which compares the output of the model with the measurement vec-tory. When the cost functionφhas reached a value lower than a certain threshold ftol, or when the improvement ofφin subsequent runs is smaller than rtol, a final estimate of the aerosol is obtained and compared to observations.
state until RH drops below the efflorescence (crystallization) RH. Boundary layer RH in the Netherlands is generally high enough for deliquescence. Also, for complex aerosol mix-tures, the deliquescence RH is unknown but generally lower than its pure substances (Seinfeld and Pandis, 1998). Finally, organic constituents in mixed aerosols suppress the deli-quescence behavior of inorganic salts (Marcolli and Krieger, 2006; Sjogren et al., 2007; Meyer et al., 2009).
Aerosol optical properties (i.e., AOT, SSA) are calculated using the t-matrix code described in Dubovik et al. (2006), taking into account the complex refractive index (RI) for each aerosol mode at four wavelengths (440, 676, 870 and 1020 nm) and non-sphericity of the aerosol (Mishchenko et al., 1997). The RI of the mixture of inorganic salts and wa-ter is calculated with the partial molar refraction method (Moelwyn-Hughes, 1961; Stelson, 1990; Tang and Munkel-witz, 1994). The imaginary refractive index (IRI) of inor-ganic salts is assumed to be negligible. Weakly soluble or insoluble species (e.g., OC, BC, dust) generally do not homo-geneously mix with the water–salt solution (e.g., Péré et al., 2009; Song et al., 2012). Since their mixing state and molec-ular mass is poorly known, we assume that the final RI for each mode is represented by the volume-weighted average RI of the wet inorganic salts and the other components (Lesins et al., 2002). This method can lead to an overestimation of the absorption by aged black carbon of up to 35 % (Oshima et al., 2009) and thus an underestimation of the amount of BC, but this has a smaller impact than the uncertainty in its refractive index and density (e.g., Schuster et al., 2005). Er-lick (2006) and ErEr-lick et al. (2011) show that the choice of
Table 3. Specific densities for the aerosol chemical components.
Compound Dry density Range Reference
(NH4)2SO4 1.76 – 1
NH4HSO4 1.78 – 1
H2SO4 1.841 – 2
NaCl 2.165 – 3, 4
Organic matter 1.547∗ 1.2–1.8
(6, 7, 8, 9, 10) 5
Black carbon 1.8 1.0∗∗–2.0
(10, 11)
11
Dust 2.65 2.5–2.75
(12, 13)
12
Water 0.9971 – 14
∗Weighted density from 20 % wt levoglucosan, 40 % wt succinic acid, and 40 %
Suwannee River reference fulvic acid (Svenningsson et al., 2006).
∗∗Bond and Bergstrom state that a density of 1.0 has never been observed.
1 Tang (1996), 2 Weast (1985), 3 Köpke et al. (1997), 4 Hess et al. (1998), 5 Svenningsson et al. (2006), 6 Turpin and Lim (2001), 7 Dick et al. (2000), 8 Hallquist et al. (2009), 9 Dinar et al. (2006), 10 Ganguly et al. (2009), 11 Bond and Bergstrom (2006), 12 McConnell (2009),
13 Wagner et al. (2009) and references therein, 14 Tang and Munkelwitz (1994).
mixing state for the calculation of the effective refractive in-dex of these species causes only a moderate change in RRI,
∼0.01–0.02.
Table 3 lists molecular masses and specific densities of the model species, and we notice that the specific densities for OC and BC cover a large range over different studies. Table 4 presents an overview of RI values for aerosol dry components currently found in the literature. The variation of RI with wavelength has been estimated from published values when measurements for that specific wavelength were not avail-able. Also, a wide range of RI values can be found here for OC, depending on its source: clean continental sources are associated with lower RI (e.g., Kanakidou et al., 2005), while pollution and biomass burning are associated with higher val-ues (“brown carbon”; e.g., Dinar et al., 2008). For ammo-nium nitrate, most studies list a real refractive index (RRI) between 1.56 and 1.60 (e.g., Stelson, 1990), which is used in our study (Table 4), but sometimes a much lower RRI of 1.42 is used (e.g., Weast, 1987).
2.1.2 Minimization procedure
to improve data coverage to 66 points. This effectively ap-plies the AERONET L2.0 criteria to all parameters, except AOT>0.4 for SSA and RI. In this study, we refer to this data set as L2*. In addition, we consider a data set of all L1.5 inversions in Cabauw in May 2008, amounting to 132 data points. We note that the L1.5 data set also includes retrievals from measurements containing fewer scattering angles – for example, when a portion of the angular scan is affected by cloud contamination or when the solar zenith angle is rela-tively low, e.g., between 40 and 50◦. For a complete overview of the differences between L1.5 and L2.0, the reader is re-ferred to Holben et al. (2006). The results of our study en-able a comparison of the quality and consistency of both data sets, L2∗and L1.5, required for an accurate optimization of aerosol physical and chemical properties.
Parameters used in our study are AOT, SSA and com-plex refractive index data at four wavelengths (λ= 440, 676, 870 and 1020 nm), the volume size distribution resolved in 22 size bins between 0.05 and 15 µm, and the aerosol spherical fraction (Table 2). The model size distribution is rebinned to the AERONET resolution before comparison. The AERONET retrieval assumes that aerosols are homoge-neous, internally mixed particles with a single wavelength-dependent RI. However, aerosol RI is often size wavelength-dependent (e.g., Benko et al., 2009), and our method assumes a bimodal lognormal size distribution with homogeneous composition (and thus a single RI) in each individual mode. In the present study the median absolute difference of RRI between both modes is generally very small (0.01), but it can occasionally be significant.
The uncertainties (Ey) used in our model can be found in
Table 2. The uncertainty in AERONET AOT is 0.01 (Eck et al., 1999). The uncertainties in the inversion parameters are derived from Dubovik et al. (2000) and pertain to the general AERONET performance. The uncertainties in RI and SSA are larger for low AOT (<0.2) and low solar zenith angles (Holben et al., 2006; Torres et al., 2014). We remark that the expressions for uncertainties in Table 2 may lead to underes-timation when applied to conditions with very low AOT and solar zenith angles, as well as to dust events. The uncertainty estimates presented here from Dubovik et al. (2000) are for weakly absorbing aerosols. The uncertainty in RRI may be larger under strongly absorbing conditions. For fine-mode-dominated aerosols, the AOT strongly decreases with wave-length, leading to larger uncertainties at longer wavelengths, especially for SSA. Finally, we note that the AERONET re-trieval algorithm places constraints on the spectral variability of the complex refractive index, which may lead to additional uncertainty. Dubovik et al. (2000) state that the uncertainty in the AERONET volume distribution is 15 % between 0.1 and 7 µm, increasing up to 100 % at the distribution edges. We have set the uncertainties of the three outlying bins be-low 0.1 and above 7 µm to 30, 60 and 100 %, respectively. Further, because the uncertainty in the aerosol spherical frac-tion is not known, we arbitrarily assumed this to be 25 %.
The AERONET spherical fraction is used when the (440– 870 nm) Ångström exponent is<1.2 and the AOT is>0.1 (Holben et al., 2006); otherwise the particles are assumed to be spherical. We note that the optimization does not appear to be sensitive to the magnitude of the uncertainties of the smallest and largest size bins and of the aerosol spherical fraction. The column effective RH is used both as an initial guess (x) to calculate aerosol water uptake, as well as a pa-rameter (RHprior, iny) that is used in the optimization. It can be adjusted by the model if this leads to a better fit with the AERONET aerosol parameters, but this will contribute to the cost function. The variance of the RH in the column is used as an uncertainty estimate, and is generally on the order of 0.1 (i.e., 10 %).
A cost function φ(x) quantifies the total difference be-tween modeled (F(x)) and observed (y) aerosol parameters:
φ (x)=
N
X
i=1
F (x)−y
wEy
2
. (2)
The difference between modeled and observed aerosol pa-rameters is weighted by the uncertainties inytogether with a weighting factor,w, that considers interdependency of the variables, and then summed overN, the number of parame-ters iny.
The routine searching for the minimum of the cost func-tion is known as “amoeba” (Nelder and Mead, 1965). It uses a simplex based on the logarithm of the model parameters (i.e., mass concentrations of the components in each mode, the number concentration and standard deviation of the log-normal distribution of each mode and the RH; Table 1). Amoeba finds a minimum on nearly all parameter spaces, but convergence does not always result in the absolute mini-mum. The probability of finding the latter is greatly improved by restarting amoeba on a previously found minimum until the cost function converges.
2.2 IMPACT observations
Table 4. Refractive indices for four different wavelengths (440, 676, 870 and 1020 nm) presented with a range found in the literature. When no imaginary part (italic) is listed, it is assumed to be zero.
Compound 440 nm 676 nm 870 nm 1020 nm Range Reference
(NH4)2SO4 1.535 1.525 1.52 1.52 – 1
NH4HSO4 1.48 1.47 1.465 1.465 - 2
H2SO4(97 % wt) 1.43 1.42 1.415 1.41 1.41–1.43 (2, 3, 4) 3
NaCl 1.56 1.546 1.534 1.532 1.49–1.55 (5, 6, 1) 1
NH4NO3 1.56 1.545 1.54 1.535 1.41–1.60 (7, 8, 9, 10) 6
Organics 1.57−1.5e−2 i 1.55−5e−3 i 1.54−3e−3 i 1.535−3e−3 i 1.43–1.65 2e−3–0.1 i (11, 12, 13) 13 Black carbon 1.85−0.71 i 1.85−0.71 i 1.85−0.71 i 1.85−0.71 i 1.50–2.0 0.44∗–1.0 i (14, 16, 17, 18, 19) 15 Dust 1.54−8e−3 i 1.52−5e−3 i 1.51−3e−3 i 1.51−3e−3 i 1.52–1.58 1e−3–1e−2 i (20, 21, 22, 23) 20, 21
Water 1.344 1.331 1.324 1.321 – 24
∗Bond and Bergstrom argue that the low IRI (0.44) value for BC (from the OPAC database) should be discarded.
1 Toon et al. (1976), 2 Stelson (1990), 3 Benko et al. (2009), 4 Hess et al. (1998), 5 Shettle and Fenn (1979), 6 Tang (1996), 7 Weast (1987) from Benko et al. (2009) (550–589 nm), 8 Richardson and Hightower (1987) (633 nm), 9 Tang (1996), 10 Weast (1985), 11 Köpke et al. (1997), 12 Dinar et al. (2008), 13 Hoffer et al. (2006), 14 Horvath (1998), 15 Stier et al. (2007), 16 Bond and Bergstrom (2006), 17 Chang and Charalampopoulos (1990), 18 Janzen (1979), 19 Schuster et al. (2005), 20 Kinne et al. (2003), 21 Sokolik et al. (1993), 22 Wagner et al. (2012), 23 Kandler et al. (2011) (532 nm, Cape Verde), 24 Segelstein (1981).
the optimized size distribution with surface measurements is not possible due to technical problems with the scanning mobility particle sizer (SMPS, a modified TSI Inc. model 3034) and the CPC (TSI Inc. model 3762). We note that aerosol hygroscopicity measurements (90 % RH growth fac-tors) from a hygroscopicity tandem differential mobility ana-lyzer (H-TDMA) are available for particle radii Dp≤165 nm (http://ebas.nilu.no/), but their quality is unknown as the data are as yet unpublished.
2.2.1 Specific model assumptions for Cabauw during May 2008
The first two weeks of May 2008 were characterized by high-pressure, relatively fair weather and a steady easterly wind in the lower atmosphere throughout most of the period. During the second half of the month the weather was more unset-tled, with cloudy and rainy periods (e.g., Roelofs et al., 2010; Hamburger et al., 2011), and as a result AERONET observa-tions are relatively sparse. Therefore we focus our analysis on 1–14 May. We assume that the aerosol is homogeneously distributed in a layer of 2 km depth at the surface. The “ef-fective” RH in this layer is derived from radiosonde measure-ments by means of averaging water vapor pressure and tem-perature in this layer. Radiosonde measurements are avail-able three times a day during the campaign, around 05:00, 10:00 and 16:00 UTC. The columnar RH is time-interpolated to the AERONET data available.
We remark that sea salt and dust have been omitted from this study. Cabauw is located only 50 km from the coast, but the first half of May is dominated by easterly winds and therefore a strong continental influence. Further, observed Cl−concentrations are very low (≪1 µg m−3). Traces of Sa-hara dust were present over the Cabauw region only on 4 May (Roelofs et al., 2010). To reduce the number of pa-rameters in the optimization we assumed specific ammo-nium : sulfate and nitrate : sulfate ratios, based on Gysel et al. (2007). The ammonium to sulfate mass ratio that corre-sponds best to surface measurements is 1.8. Surface
observa-tions of ammonium nitrate during May 2008 correlate well (R2= 0.71) with that of sulfate; the mass ratio of ammonium nitrate to sulfate is 1.3.
2.2.2 AERONET
The optimization procedure uses AERONET retrievals for Cabauw. Figure 2 shows AERONET AOT, the Ångström ex-ponent, boundary layer RH, RRI, SSA and IRI for the first half of May 2008. Between 6 and 12 May, dry continental air was advected from the east. Figure 2a shows that AOT (676 nm) is generally between 0.05 and 0.25 (the mean and standard deviation are 0.13±0.05 and 0.13±0.04 for L1.5 and L2∗ AERONET data, respectively). The Ångström ex-ponent generally exceeds 1 (1.48±0.26 and 1.51±0.24 for level 1.5 and 2∗, respectively), indicating that the fine-mode
fraction dominates the aerosol optical properties. During daytime a well-mixed boundary layer was formed between 0 and 2 km altitude above the surface. The atmosphere is rela-tively dry, with RH between 30 and 70 % (48±10 %) except for the first three days (Fig. 2b), and the variability during a day is on the order of 10–20 %. AOT displays a distinct daily variability with a minimum around noon on days when RH is relatively high (e.g., 6–8 May). On the driest days, e.g., 9–11 May, AOT strongly increases during the day. The RRI ranges between the AERONET lower and upper bounds of 1.33 and 1.60 (the mean and standard deviation for RRI (676 nm) are 1.46±0.06 and 1.47±0.05 for level 1.5 and 2∗, respectively). It is highly variable, even during a single day (e.g., 9 and 10 May) and appears to be only weakly related to RH. Single-scattering albedo (676 nm) varies from 0.8 to near 1.00 (0.88±0.04 and 0.88±0.03 for L1.5 and L2∗,
2.2.3 Aerosol chemical composition
Surface concentrations of inorganic aerosol species NO−3, SO24−, NH+4, Na+and Cl− were measured with a MARGA
instrument (Monitor for Aerosols and Gases, Applikon Ana-lytical BV; ten Brink et al., 2007; Thomas et al., 2009), with an hourly resolution and a measurement error smaller than 10 % (Schaap et al., 2011, and references therein). Black car-bon mass concentrations are measured with a multi-angle absorption photometer (MAAP; Thermo Scientific model 5012; Petzold et al., 2005) with a resolution of 5 min and un-certainty of 12 % (Petzold and Schönlinner, 2004). Aerosol organic concentrations were measured with an Aerodyne aerosol mass spectrometer (HR-ToF-AMS) (Jülich ICG-2; Canagaratna et al., 2007) with a 5 min time resolution from an inlet at 60 m altitude (Mensah et al., 2012). Measured AMS PM1 mass concentrations for inorganic and organic ambient aerosol species are reproducibly accurate to approx-imately±25 % (Canagaratna et al., 2007).
We note that measured organic masses are effectively PM1 (100 % transmission in range 70–500 nm and 50 % for parti-cles with 1 µm diameter). To compare these with the opti-mized organic mass, which is essentially PM10, we scaled the AMS measurements to PM10based on the observed sul-fate masses from MARGA and the AMS. This implies that sulfate and organics are distributed similarly over aerosol size, which is a reasonable assumption because a significant fraction of secondary organic as well as inorganic (sulfate) aerosol matter formed in the gas phase deposits onto the fine mode (Kulmala et al., 2004; Kanakidou et al., 2005; Hal-lquist et al., 2009).
3 Results
The refractive index is a crucial parameter in the optimiza-tion of the aerosol chemical composioptimiza-tion. Figure 3 shows a comparison between the optimized RRI and the AERONET retrieved values. Between the values 1.40 and 1.56 the dis-crepancies between our results and AERONET are generally within the uncertainty range (i.e., 0.025–0.05, Table 2). In several cases, however, especially for the level 1.5 data, the AERONET RRI is less than 1.40. As can be seen in Fig. 4, which compares RRI and RH, the corresponding columnar RH is relatively low, ranging between 38 and 65 %. The AERONET RRI has a very low correlation with the colum-nar RH (R2= 0.14, 0.14 and 0.36 for the L1.5, L2∗ and
non-suspect data, respectively), suggesting large variations in aerosol composition or relatively large uncertainties in the AERONET RRI. Our model cannot simulate the lowest RRI values at the observed columnar RH with the current choice of aerosol compounds. These low RRI values also cannot di-rectly be attributed to cloud contamination of the AERONET retrievals (e.g., de Meij et al., 2007; Schaap et al., 2009), be-cause close inspection of the CAELI (CESAR Water Vapour,
Figure 2. AERONET almucantar retrieval data (level 1.5: squares; L2*: dots) during the first 14 days of May 2008 at the Cabauw Tower. (a) Aerosol optical thickness (AOT) color-coded with val-ues of the Ångström exponent (440–870 nm), (b) the columnar rel-ative humidity from balloon soundings between 0 and 2 km color-coded with the AERONET real part of the refractive index, and (c) AERONET single-scattering albedo (SSA) color-coded with the (base 10 logarithm) imaginary part of the refractive index.
Aerosol and Cloud Lidar; Apituley et al., 2009) data showed that low RRI values seem to occur both on clear days (e.g., 7 and 8 May) as well as on days with a slight lidar backscat-ter signal between 8 and 12 km altitude (most other days). Most of the discrepancies relate to L1.5 data and not to the L2∗data, which may reflect the difference in accuracy. Some discrepancies remain in the L2∗data, while several L1.5 data
Table 5. Squared Pearson correlation coefficients (R2) between model computed (optimized) values and AERONET inversions of the real and imaginary part of the refractive index (RRI and IRI), aerosol optical thickness (AOT), single-scattering albedo (SSA) at four wavelengths, the sum of the binned AERONET volume distribution (VOL), AERONET spherical fraction (SPH) and columnar relative humidity (RH) derived from radiosonde measurements for the non-suspect data, L1.5 and L2∗data (latter two between parentheses) during the first 14 days of May.
Correlation (R2) 440 nm 676 nm 870 nm 1020 nm
RRI 0.80 (0.78, 0.82) 0.94 (0.81, 0.89) 0.90 (0.84, 0.91) 0.84 (0.83, 0.89) IRI 0.79 (0.79, 0.71) 0.98 (0.98, 0.98) 0.98 (0.98, 0.98) 0.97 (0.96, 0.96) AOT 1.00 (0.99, 1.00) 1.00 (0.99, 1.00) 0.99 (0.99, 0.99) 0.99 (0.99, 0.99) SSA 0.93 (0.84, 0.85) 0.98 (0.98, 0.98) 0.98 (0.97, 0.96) 0.98 (0.97, 0.96)
VOL 0.99 (0.85, 0.93)
SPH 1.00 (1.00, 1.00)
RH 1.00 (0.99, 0.99)
Figure 3. Scatterplot of model computed (optimized) and AERONET level 1.5 (squares) and L2∗(diamonds) real refractive index (RRI) data averaged over four wavelengths. Model results have been marked “suspect” (red) when the AERONET refractive index is outside the range that our model can simulate and/or when the cost function is larger than 10. The blue line shows the 1:1 ratio.
Figure 4. Scatterplot of the column effective relative humidity (RH) and the AERONET real refractive index (RRI) for level 1.5 data (squares) and L2∗data (diamonds). The AERONET data that have been labeled “suspect” are presented in red.
is found for most parameters. It should be noted that in our model, the RI tends to show a stronger increase near smaller wavelengths (due to our choice of RI of the individual com-pounds), leading to larger discrepancies for RI and SSA at 440 nm than at longer wavelengths. The correlation between
Figure 5. Scatterplot of model computed (optimized) and AERONET total volume (level 1.5: squares, L2*: diamonds). AERONET data that have been classified as suspect have been marked in red. The blue line shows the 1:1 ratio.
AERONET RRI and RH is smaller at 440 nm than at longer wavelengths, suggesting larger uncertainties at the shorter wavelengths. This is consistent with the results of Torres et al. (2012) for urban aerosol. We also note that we did not find a significant correlation between the AERONET SSA and the fine-mode volume median radius.
Figure 5 shows a comparison of the optimized and AERONET total aerosol volume. The agreement is very good for non-suspect data, but for suspect data the model cal-culates substantially smaller aerosol volumes, mostly associ-ated with discrepancies between modeled and observed RRI. The average AERONET (non-suspect) and modeled (opti-mized) volume size distributions during 1–14 May are shown in Fig. 6. It can be seen that the AERONET coarse mode con-tains two weak maxima, and is therefore generally wider than the optimized (single) coarse mode.
Table 6. Mean (column-average) modeled (µmod) and mean observed (µobs) (near-surface) mass concentration (µg m−3) together with corresponding standard deviations (σ), modeled and observed medians (medmodand medobs) and mean absolute gross error (MAGE) for the non-suspect (N-S) data, L1.5 and the L2∗data during the first half of May 2008. NB: NA is given when there are no observational data available.
Conc [µg m−3] µmod±σmod µobs±σobs medmod medobs MAGE
Dry mass N-S 30.3±8.40 31.3±11.0 27.8 30.1 9.99
L1.5 36.1±28.2 30.2±11.2 30.4 28.5 13.6
L2∗ 32.3±9.66 28.6±12.2 29.4 28.4 12.1
SO42− N-S 5.51±3.11 4.42±1.38 4.92 4.84 2.87
L1.5 7.11±4.57 4.37±1.38 6.67 4.69 4.37
L2∗ 6.99±4.21 4.24±1.64 6.62 4.44 4.01
NH4+ N-S 4.03±2.27 3.34±1.55 3.59 3.05 2.19
L1.5 5.20±3.34 3.35±1.57 4.87 3.23 2.94
L2∗ 5.11±3.08 3.11±1.66 4.84 3.03 2.92
NO3− N-S 7.44±4.20 7.76±3.64 6.63 7.71 3.73
L1.5 9.60±6.17 7.48±4.35 9.00 7.04 4.75
L2∗ 9.44±5.68 7.00±4.07 8.94 5.02 4.79
OC N-S 12.6±7.43 14.8±5.35 13.4 14.6 6.77
L1.5 13.3±27.5 13.9±5.37 10.4 14.1 13.0
L2∗ 9.98±9.68 13.0±6.22 8.92 14.0 9.09
BC N-S 0.73±0.32 0.88±0.46 0.69 0.75 0.41
L1.5 0.75±0.34 0.89±0.49 0.72 0.74 0.48
L2∗ 0.71±0.24 0.83±0.49 0.70 0.70 0.46
H2O N-S 6.09±4.98 NA 4.60 NA NA
L1.5 8.55±7.84 NA 7.45 NA NA
L2∗ 7.79±6.86 NA 6.26 NA NA
Figure 6. Average AERONET (black dots) and optimized (turquoise dots) volume distribution for the non-suspect data dur-ing 1–14 May. The bars indicate the standard deviation of the data in each bin.
magnitude as observed during aircraft measurements in the boundary layer around Cabauw: approximately 1500 cm−3 on 6 May (FAAM BAe-146, Dp= 0.1–0.8 µm), 2500 cm−3 on 8 May (DLR Falcon 20, CCN>10 nm), 800 on 12 May and 1200 cm−3on 13 May (FAAM BAe-146) (Hamburger et al., 2011, their Fig. 9).
Figure 7 shows computed column-average dry aerosol mass concentration and the total observed dry mass con-centration at the surface, i.e., the sum of scaled organic mass concentrations from the AMS instrument, all aerosol
Figure 7. Time series of total (PM10 equivalent) dry mass con-centration from surface measurements (black dots), and our model results (turquoise squares and diamonds for results based on non-suspect AERONET L1.5 data and L2∗ data, respectively) during the first half of May 2008 at the Cabauw Tower. Results based on AERONET data that have been labeled “suspect” are presented in red.
Figure 8. Time series of black carbon concentration from surface observations (multi-angle absorption photometer, black dots) with 3 h centered moving average (black line), and our model results (L1.5: turquoise squares; L2∗: turquoise diamonds; suspect: red).
and 14 May. Measurements from the CAELI and radiosonde observations indicated that most of the aerosol and high-est RH were located in a (reasonably) well-mixed bound-ary layer of approximately 2 km depth, consistent with our assumptions. Including the suspect values, the computed values and associated standard deviation are significantly larger (36.1±28.2 µg m−3) than observed (30.2±11.2). Note, however, that this is predominately caused by a few outliers, and that the modeled and observed medians are still reasonably close (30.4 versus 28.5 µg m−3).
Although the daily averages of computed dry mass and the observations appear to be in reasonable agreement, for some days (e.g., 8–11 May) the daily cycle of the computed aerosol concentration is opposite to that of the surface ob-servations, with the former showing an increase and the lat-ter a decrease during the day. The increase in modeled dry aerosol concentration during the afternoon is associated with a large, approximately two-fold increase in AERONET AOT (e.g., 8 and 9 May), while RRI slightly increases or remains approximately equal. The discrepancy between modeled and observed variability is partly due to the different effects of boundary layer meteorology on columnar mass and on sur-face concentration. During the early morning hours, aerosols are trapped in a thin, stable layer near the surface. This layer will rapidly mix with the atmosphere above when heated by the sun, leading to a reduction in the aerosol concentration near the surface without changing the total column aerosol burden. Additionally, rapidly rising temperatures near the surface during the day shift the partitioning of semi-volatile gases such as ammonium nitrate and volatile organic com-pounds to the gas phase (Schaap et al., 2011; Aan de Brugh et al., 2012). More abundant road traffic and photochemi-cal production of secondary aerosol during daytime may be the reason why the computed (column-average) dry mass increases in the afternoon, reflecting the strong increase of AERONET AOT.
Table 6 lists modeled (total column-average) and ob-served (surface) mass concentrations. The agreement be-tween both is reasonable for the non-suspect data, i.e., within the computed standard deviations, with computed BC (bias is
−17 %), OC (−15 %) and nitrate (−4 %) somewhat smaller, and sulfate (+25 %) and ammonium (+21 %) significantly larger than observed.
A comparison between optimized and measured concen-trations for individual aerosol species is presented in Fig. 8 for black carbon, and in Fig. 9 for the inorganic salt ions (SO24−, NH+4 and NO−3) and organic matter. Optimized BC concentrations (Fig. 8) fall within the same range as observed concentrations. On some days the observed hourly variabil-ity, represented by the black line, appears to be captured by the model (6, 13 May). A significant overestimation occurs on 4 May (to a lesser extent also on 2 May and during one measurement in the afternoon of 12 May; however these are already marked as “suspect”), when traces of Sahara dust were present over the Cabauw region (Roelofs et al., 2010). Since mineral dust is not taken into account in this study, the associated scattering and absorption is now attributed to the other compounds in our model. Nevertheless, we conclude that the optimization performs relatively well for BC, espe-cially considering the uncertainties in AERONET SSA and IRI. For other species the comparison for the individual op-timizations is less favorable. Optimization results display a relatively large variability compared to measured concentra-tions. As will be discussed later, RRI is a dominant parame-ter in the optimization, and errors in RRI lead to compensat-ing solutions between the more hygroscopic inorganic salts and the less hygroscopic OC. Figure 10 shows daily aver-ages of modeled and observed aerosol species. The day-to-day variability and the daily averaged concentrations, espe-cially for the inorganic salts (sulfate, ammonium and nitrate), are captured reasonably well (i.e., mean bias is 5 % for PM10 and black carbon, 10 % for the inorganic salts and 18 % for organic matter, and root-mean-squared deviations are 26 % for PM10 and 35–45 % for the individual compounds; Ta-ble 7). Concentrations are relatively low on 1–2, 5–7 and 11–12 May, while higher concentrations are observed and modeled between 7 and 10 and between 13 and 14 May. We note that on 11–12 May a brief period with northeast-erly winds occurred, advecting relatively clean air character-ized by small AOT (∼0.1), low RH and high refractive index (RRI>1.48, Fig. 2). Our model calculates concentrations of inorganic salts that are considerably smaller than those of the surrounding days, in good agreement with the observations.
Figure 9. Inorganic salt ion concentrations, SO24− (upper left), NH+4 (upper right), NO−3 (lower left) from surface observations of the MARGA (small grey dots), and organic matter (OC) from Jülich ICG-2 AMS (scaled to PM10, lower right), interpolated to AERONET times (bold black dots) and compared to the column-average model results (turquoise squares and diamonds for data based on AERONET L1.5 and L2∗data, respectively). Results based on suspect AERONET data have been left out.
Table 7. Daily average mean (column-average) modeled (µmod) and observed (µobs) (near-surface) mass concentration (µg m−3) together with corresponding standard deviations (σ ), mean and standard deviation errors in model and observations (µer±σer), regression slope and offset, correlation coefficient (R), and root-mean-squared deviations (RMS) for non-suspect data during the first half of May 2008. Inorganic salts (“Salts”) is the sum of the mass concentrations of SO4, NH4and NO3ions.
Conc [µg m−3] µmod±σmod µobs±σobs µer±σer(model) µer±σer(obs) regression R RMS
Dry mass 29.2±6.31 27.9±11.0 7.8±1.7 2.0±1.4 y=1.37x−12.1 0.78 7.4
BC 0.87±0.33 0.92±0.39 0.38±0.15 0.04±0.03 y=0.45x+0.53 0.37 0.41
Salts 16.7±5.85 14.1±5.53 5.6±1.9 0.36±0.27 y=0.55x+4.81 0.59 5.83
OC 11.6±3.64 13.0±5.89 6.7±2.2 1.9±1.4 y=1.05x+0.86 0.65 4.70
We note that the RRI of the mixture of inorganic salts is only slightly lower than that of OC (approx. 1.53, Table 4) while the assumed hygroscopicity of OC is much smaller than that of inorganic salts. Therefore, when both RRI and RH are rel-atively large the model computes a predominantly organic composition.
The resulting aerosol water volume fraction (fVwater, the water volume divided by total volume) is displayed in Fig. 11. We find that at high RH (e.g., 80 %), more than half of the total aerosol volume, and therefore approximately
Figure 10. Modeled (turquoise squares) and observed (black dots) daily average concentrations of dry mass (PM10, upper left), black carbon (BC, upper right), inorganic salts (lower left) and organic matter (OC, lower right). Only the results of non-suspect AERONET data have been used in the averaging. The error bars show the uncertainty in modeled (turquoise) and observed (black) data.
Figure 11. Calculated water volume fraction, optimized real refrac-tive index (RRI, color-filled squares for L1.5 and dots for L2*) and columnar relative humidity (RH). Results from suspect AERONET data are opaque.
nephelometer measurements above northwestern and central Europe, with a monthly range off(RH = 85 %, 550 nm) be-tween 1.23 and 1.63 (Highwood et al., 2012), but it is in relatively good agreement with surface nephelometer mea-surements at Cabauw for continental air in the period June– October 2009, where f(RH = 85 %, 550 nm) is 2.25±0.16 (Zieger et al., 2013). Discrepancies between the studies are
Figure 12. Volume fraction of the modeled aerosol components as a function of the optimized real refractive index during May 2008. Here, the sum of (ammonium) sulfates and ammonium nitrate has been taken into inorganic “salts”, because their ratio is held constant throughout the retrieval.
likely associated with measurement inaccuracies and with different model assumptions regarding the absorption and hygroscopicity of the relatively abundant organic matter.
inorganic and water volume fractions and increasing organic fractions for increasing RRI. In general the aerosol compo-sition appears to be predominantly defined by RRI; other factors, specifically RH, may also exert significant influence (e.g., at RRI = 1.41 in Fig. 12). The uncertainty associated with the optimized aerosol chemical composition strongly depends on the uncertainty of AERONET RI, the description of aerosol RI as a complex mixture of components and the optical model of scattering and absorption. Another uncer-tainty is associated with the depth and homogeneity of the boundary layer. Based on the model results and sensitivity tests, we tentatively estimate the uncertainties in computed volume fractions to be approximately 50 % for inorganic salts, black carbon and water, and 100 % for organic mat-ter. We estimate that the uncertainty caused by the discrep-ancy between column-average and surface concentrations is on the order of 25 % for this study. Combined, this corre-sponds to uncertainties of approximately 50, 100, 50, 30 and 65 %, for inorganic salts, OC, BC, dry mass and water in the total column aerosol mass, respectively. We expect that these uncertainties can be reduced by considering the vertical dis-tribution of aerosols in the optimization (e.g., from a lidar) and applying our methodology to regions with higher AOT.
4 Conclusions and discussion
We have presented an optimization technique that derives aerosol chemical composition from remotely sensed aerosol optical thickness, single-scattering albedo, refractive index, size distribution and measurements of relative humidity. The model calculates aerosol water uptake and optical proper-ties of a mixture of sulfate, ammonium, nitrate, black carbon and organic matter, assuming a single homogeneous layer of air, aerosol and RH. Aerosol composition and concentration are determined by minimizing the difference between mod-eled and AERONET aerosol properties and effective RH. The method is applied to individual measurements so that the short-term variability of the concentrations is resolved. This potentially enables study and aerosol–climate model valida-tion of the effects of temporal variavalida-tions in, for example, pho-tochemistry, humidity and emissions on the aerosol concen-tration and chemical composition (Derksen et al., 2011; Aan de Brugh et al., 2012). The technique is compared to sur-face concentrations observed during the IMPACT measure-ment campaign carried out at Cabauw (the Netherlands, May 2008).
On most days the optimized column-averaged dry mass concentration agrees relatively well with surface observa-tions from MARGA and from the Jülich ICG-2 aerosol mass spectrometer, especially during a series of dry and sunny days between 6 and 12 May. During this time most water vapor and aerosols were confined to a boundary layer of ap-proximately 2 km deep, consistent with our assumptions. For the individual aerosol species, sulfate, nitrate, ammonium,
BC and OC the resulting concentrations compare relatively well with observations and reflect realistic day-to-day vari-ability.
Nevertheless, discrepancies occur for several reasons, mainly associated with boundary layer characteristics and with RI.
1. Model results reflect columnar aerosol concentrations, while observations (e.g., MARGA, AMS) reflect sur-face concentrations. The daily cycle in boundary layer height affects both concentrations in different ways. In addition, the neglect of altitudinal variability of RH, aerosol concentration and chemical composition within the boundary layer leads to further inaccuracies, espe-cially for aerosol water uptake (e.g., Yeong et al., 2007; Bian et al., 2009; Zieger et al., 2011) and the gas– particle partitioning of ammonium nitrate (Morgan et al., 2010; Aan de Brugh et al., 2012). These discrep-ancies may be reduced by including information on the vertical distribution of aerosol, e.g., from lidar extinc-tion profiles.
2. The most important parameter in the optimization of the aerosol chemical composition is the RRI. Uncertainties in modeled RRI are primarily associated with uncertain-ties of the RI of individual components. We found that the overall agreement between optimized and observed surface concentration of OC can only be improved by applying a somewhat larger value for RRI for OC (e.g., 1.60) in combination with an unrealistically small value for RRI for ammonium nitrate (1.42). On the other hand, the choice of the RI of individual compounds and the mixing rule used to calculated RI for internally mixed aerosol appears not to have a major influence on the op-timized total dry aerosol mass and the amount of aerosol water, because the effect of water uptake on the aerosol RI dominates.
3. Uncertainties in AERONET RRI (0.025–0.05) lead to 10–25 % (absolute) difference in water volume fraction. AERONET RRI shows very large variations, including during the course of a single day. The correlation be-tween RH and AERONET RRI is relatively low (R2∼
but on several occasions AERONET RI increases with wavelength, which leads to discrepancies between mod-eled and observed aerosol optical properties, especially at 440 nm. Since IRI strongly increases towards the ul-traviolet wavelengths for OC, contrary to that of BC (Ja-cobson, 1999; Kirchstetter et al., 2004; Sun et al., 2007; and Chen and Bond, 2010), this hampers the method’s ability to distinguish black carbon from absorbing or-ganic matter (“brown carbon”) (e.g., Bergstrom et al., 2007; Russell et al., 2010; Arola et al., 2011).
We conclude that the remotely sensed aerosol optical mea-surements from AERONET allow for a fairly accurate anal-ysis of the daily averaged atmospheric aerosol composition, separated into the most common aerosol species (inorganic salts, BC, OC, water). The uncertainties appear too large for an accurate optimization of individual measurements, but the day-to-day variability is captured reasonably well. The study indicates that RRI has the largest information con-tent with regard to aerosol water, while RH is of secondary importance. The results from level 2∗ data (including L1.5 SSA and RI when AOT is <0.4) are generally more accu-rate than those from L1.5, although part of the L1.5 data also yields reasonable results. Therefore we conclude that despite relatively low AOT, our model performs relatively well at Cabauw, but a better performance is expected in re-gions with higher aerosol loading where uncertainties in SSA and RI are smaller. Our technique may be extended to global scales by using satellite remote sensing of aerosol proper-ties (e.g., from the Polarization and Directionality of Earth Reflectances (POLDER) instrument onboard the PARASOL satellite (Hasekamp et al., 2011; Tanré et al., 2011). Accurate retrieval of the refractive index is vital for determination of column aerosol composition; in light of this, the loss of the Aerosol Polarimetry Sensor (APS) with the Glory satellite is extremely unfortunate.
Acknowledgements. We thank AERONET and Gerrit de Leeuw for
their effort in establishing and maintaining the Cabauw site. We also thank the researchers conducting the measurements during the IM-PACT 2008 campaign, made possible through financial support of the Sixth Framework European Integrated project on Aerosol Cloud Climate and Air Quality Interactions (EUCAARI), specifically Harry ten Brink and René Otjes (ECN) for providing the MARGA data, Th. F. Mentel and A. Kiendler-Scharr (Forschungszentrum Jülich GmbH, Germany) for the ICG-2 AMS data, Richard Rothe (KNMI) for the radiosonde data, Dave Donovan (KNMI) for the UV lidar data, and Arnoud Apituley (RIVM) for the CAELI data. We thank O. Dubovik, A. Sinyuk and B. Holben for input on the AERONET uncertainty estimates, and the anonymous reviewers for their valuable comments. We acknowledge the project and support of the European Community-Research Infrastructure Action under the FP7 “Capacities” specific program for integrating activities, AC-TRIS grant agreement no. 262254.
Edited by: N. Riemer
References
Aan de Brugh, J. M. J., Henzing, J. S., Schaap, M., Morgan, W. T., van Heerwaarden, C. C., Weijers, E. P., Coe, H., and Krol, M. C.: Modelling the partitioning of ammonium nitrate in the convective boundary layer, Atmos. Chem. Phys., 12, 3005–3023, doi:10.5194/acp-12-3005-2012, 2012.
Andreae, M. O., Jones, C. D., and Cox, P. M.: Strong present day cooling implies a hot future, Nature, 435, 1187–1190, doi:10.1038/nature03671, 2005.
Apituley, A.,Wilson, K.M., Potma, C., Volten, H., and de Graaf, M.: Performance Assessment and Application of Caeli – A high performance Raman lidar for diurnal profiling of Water Vapour, Aerosols and Clouds, Proceedings of the 8th International Sym-posium on Tropospheric Profiling, 19–23 October 2009, Delft, The Netherlands, 2009.
Arola, A., Schuster, G., Myhre, G., Kazadzis, S., Dey, S., and Tripathi, S. N.: Inferring absorbing organic carbon content from AERONET data, Atmos. Chem. Phys., 11, 215-225, doi:10.5194/acp-11-215-2011,2011.
Bellouin, N., Boucher, O., Haywood, J., and Reddy, M. S.: Global estimate of aerosol direct radiative forcing from satellite mea-surements, Nature, 438, 1138–1141, doi:10.1038/nature04348, 2005.
Bellouin, N., Jones, A., Haywood, J., and Christopher, S. A.: Updated estimate of aerosol direct radiative forcing from satellite observations and comparison against the Hadley Centre climate model, J. Geophys. Res., 113, D10205, doi:10.1029/2007JD009385, 2008.
Bellouin, N., Quaas, J., Morcrette, J.-J., and Boucher, O.: Esti-mates of aerosol radiative forcing from the MACC re-analysis, Atmos. Chem. Phys., 13, 2045–2062, doi:10.5194/acp-13-2045-2013, 2013.
Benko, D., Molnár, A., and Imre, K.: Study on the size dependence of complex refractive index of atmospheric aerosol particles over Central Europe, Id ˝Ujárás, 113, 157–175, 2009.
Bergstrom, R. W., Pilewskie, P., Russell, P. B., Redemann, J., Bond, T. C., Quinn, P. K., and Sierau, B.: Spectral absorption proper-ties of atmospheric aerosols, Atmos. Chem. Phys., 7, 5937–5943, doi:10.5194/acp-7-5937-2007, 2007.
Bian, H., Chin, M., Rodriguez, J. M., Yu, H., Penner, J. E., and Strahan, S.: Sensitivity of aerosol optical thickness and aerosol direct radiative effect to relative humidity, Atmos. Chem. Phys., 9, 2375–2386, doi:10.5194/acp-9-2375-2009, 2009.
Bond, T. C. and Bergstrom, R. W.: Light absorption by carbona-ceous particles: An investigative review, Aerosol Sci. Technol., 40, 27–67, doi:10.1080/02786820500421521, 2006.
Canagaratna, M. R., Jayne, J. T., Jimenez, J. L., Allan, J. D., Al-farra, M. R., Zhang, Q., Onasch, T. B., Drewnick, F., Coe, H., Middlebrook, A., Delia, A., Williams, L. R., Trimborn, A. M., Northway, M. J., DeCarlo, P. F., Kolb, C. E., Davidovits, P., and Worsnop, D. R.: Chemical and microphysical characterization of ambient aerosols with the aerodyne aerosol mass spectrometer, Mass Spectrom. Rev., 26, 185–222, 2007.
Chen, Y. and Bond, T. C.: Light absorption by organic carbon from wood combustion, Atmos. Chem. Phys., 10, 1773–1787, doi:10.5194/acp-10-1773-2010, 2010.
Derksen, J. W. B., Roelofs, G. J., Otjes, R., de Leeuw, G., and Röck-mann, T.: Impact of ammonium nitrate chemistry on the AOT in Cabauw, the Netherlands, Atmos. Environ., 45, 5640–5646, 2011.
Deschamps, P. Y., Bréon, F. M., Leroy, M., Podaire, A., Bricaud, A., Buriez, J. C., and Seze, G.: The POLDER mission: Instrument characteristics and scientific objectives, Geosci. Remote Sens., 32, 598–615, doi:10.1109/36.297978, 1994.
Dick, W. D., Saxena, P., and McMurry, H. P.: Estimation of water uptake by organic compounds in submicron aerosols measured during the Southeastern Aerosol and Visibility Study, J. Geo-phys. Res., 105, 1471–1479, 2000.
Dinar, E., Mentel, T. F., and Rudich, Y.: The density of humic acids and humic like substances (HULIS) from fresh and aged wood burning and pollution aerosol particles, Atmos. Chem. Phys., 6, 5213–5224, doi:10.5194/acp-6-5213-2006, 2006.
Dinar, E., Riziq, A. A., Spindler, C., Erlick, C., Kiss, G., and Rudich, Y.: The complex refractive index of atmospheric and model humic-like substances (HULIS) retrieved by a cavity ring down aerosol spectrometer (CRD-AS), Faraday Discuss., 137, 279–295, 2008.
Dubovik, O. and King, M. D.: A flexible inversion algorithm for retrieval of aerosol optical properties from Sun and sky radiance measurements, J. Geophys. Res., 105, 20673–20696, 2000. Dubovik, O., Smirnov, A., Holben, B. N., King, M. D.,
Kauf-man, Y. J., Eck, T. F., and Slutsker, I.: Accuracy assessments of aerosol optical properties retrieved from AERONET sun and sky-radiance measurements, J. Geophys. Res., 105, 9791–9806, 2000.
Dubovik, O., Sinyuk, A., Lapyonok, T., Holben, B. N., Mishchenko, M., Yang, P., Eck, T. F., Volten, H., Muñoz, O., Veihelmann, B., van der Zande, W. J., Leon, J.-F., Sorokin, M., and Slutsker, I.: Application of spheroid models to account for aerosol particle nonsphericity in remote sensing of desert dust, J. Geophys. Res., 111, D11208, doi:10.1029/2005JD006619, 2006.
Eck, T. F., Holben, B. N., Reid, J. S., Dubovik, O., Smirnov, A., O’Neill, N. T., Slutsker, I., and Kinne, S.: Wavelength dependence of the optical depth of biomass burning, urban and desert dust aerosols, J. Geophys. Res., 104, 31333–31350, doi:10.1029/1999JD900923, 1999.
Erlick, C.: Effective refractive indices of water and sulfate drops containing absorbing inclusions, J. Atmos. Sci., 63, 754–763, 2006.
Erlick, C., Abbatt, J. P., and Rudich, Y.: How Different Calculations of the Refractive Index Affect Estimates of the Radiative Forcing Efficiency of Ammonium Sulfate Aerosols, J. Atmos. Sci., 68, 1845–1852, 2011.
Feingold, G.: Modeling of the first indirect effect: Analysis of measurement requirements, J. Geophys. Res., 30, 1997, doi:10.1029/2003GL017967, 2003.
Forster, P., Ramaswamy, V., Artaxo, P., Berntsen, T., Betts, R., Fa-hey, D. W., Haywood, J., Lean, J., Lowe, D. C., Myhre, G., Nganga, J., Prinn, R., Raga, G., Schulz, M., and van Dorland, R.: Changes in Atmospheric Constituents and in Radiative Forcing. In: Climate Change 2007: The Physical Science Basis. Contribu-tion of WGI to the Fourth Assessment Report of the
Intergovern-mental Panel on Climate Change, edited by: Solomon, S., Qin, D., Manning, M., Chen, Z., Marquis, M., Averyt, K. B., Tignor, M., and Miller, H. L., Cambridge University Press, Cambridge, UK and New York, NY, USA, Chapter 2.4, 153–180, 2007. Ganguly, D., Ginoux, P., Ramaswamy, V., Dubovik, O., Welton,
J., Reid, E. A., and Holben, B. N.: Inferring the composition and concentration of aerosols by combining AERONET and MPLNET data: Comparison with other measurements and uti-lization to evaluate GCM output, J. Geophys. Res., 114, D16203, doi:10.1029/2009JD011895,, 2009.
Gysel, M., Crosier, J., Topping, D. O., Whitehead, J. D., Bower, K. N., Cubison, M. J., Williams, P. I., Flynn, M. J., McFiggans, G. B., and Coe, H.: Closure study between chemical composition and hygroscopic growth of aerosol particles during TORCH2, Atmos. Chem. Phys., 7, 6131–6144, doi:10.5194/acp-7-6131-2007, 2007.
Hallquist, M., Wenger, J. C., Baltensperger, U., Rudich, Y., Simp-son, D., Claeys, M., Dommen, J., Donahue, N. M., George, C., Goldstein, A. H., Hamilton, J. F., Herrmann, H., Hoffmann, T., Iinuma, Y., Jang, M., Jenkin, M. E., Jimenez, J. L., Kiendler-Scharr, A., Maenhaut, W., McFiggans, G., Mentel, T. F., Monod, A., Prévôt, A. S. H., Seinfeld, J. H., Surratt, J. D., Szmigiel-ski, R., and Wildt, J.: The formation, properties and impact of secondary organic aerosol: current and emerging issues, At-mos. Chem. Phys., 9, 5155–5235, doi:10.5194/acp-9-5155-2009, 2009.
Hamburger, T., McMeeking, G., Minikin, A., Birmili, W., Dall’Osto, M., O’Dowd, C., Flentje, H., Henzing, B., Junninen, H., Kristensson, A., de Leeuw, G., Stohl, A., Burkhart, J. F., Coe, H., Krejci, R., and Petzold, A.: Overview of the synop-tic and pollution situation over Europe during the EUCAARI-LONGREX field campaign, Atmos. Chem. Phys., 11, 1065– 1082, doi:10.5194/acp-11-1065-2011, 2011.
Hasekamp, O. P., Litvinov, P., and Butz, A.: Aerosol prop-erties over the ocean from PARASOL multiangle photopo-larimetric measurements, J. Geophys. Res., 116, D14204, doi:10.1029/2010JD015469, 2011.
Hess, M., Koepke, P., and Schult, I.: Optical Properties of Aerosols and Clouds: The Software Package OPAC, B. Am. Meteorol. Soc., 79, 831–844, doi:10.1175/1520-0477(1998)079<0831:OPOAAC<2.0.CO;2, 1998.
Highwood, E. J., Northway, M. J., McMeeking, G. R., Mor-gan, W. T., Liu, D., Osborne, S., Bower, K., Coe, H., Ryder, C., and Williams, P.: Aerosol scattering and absorption during the EUCAARI-LONGREX flights of the Facility for Airborne Atmospheric Measurements (FAAM) BAe-146: can measure-ments and models agree?, Atmos. Chem. Phys., 12, 7251–7267, doi:10.5194/acp-12-7251-2012, 2012.
Hoffer, A., Gelencsér, A., Guyon, P., Kiss, G., Schmid, O., Frank, G. P., Artaxo, P., and Andreae, M. O.: Optical properties of humic-like substances (HULIS) in biomass-burning aerosols, At-mos. Chem. Phys., 6, 3563–3570, doi:10.5194/acp-6-3563-2006, 2006.
Holben, B. N., Eck, T. F., Slutsker, I., Smirnov, A., Sinyuk, A., Schafer, J. S., Giles, D. M., and Dubovik, O.: Aeronet’s Ver-sion 2.0 quality assurance criteria, Proc. SPIE, 6408, 64080Q, doi:10.1117/12.70652, 2006.
Horvath, H.: Influence of atmospheric aerosols upon the global ra-diation balance, In Atmospheric Particles IUPAC Series on Ana-lytical and Physical Chemistry of Environmental Systems, John Wiley, New York, 5, 543–596, 1998.
Jacobson, M. Z.,: Isolating nitrated and aromatic aerosols and ni-trated aromatic gases as sources of ultraviolet light absorption, J. Geophys. Res., 104, 3527–3542, 1999.
Janzen, J.: The refractive index of colloidal carbon, J. Colloid Inter-face Sci., 69, 436–447, 1979.
Jeong, M. J., Li, Z., Andrews, E., and Tsay, S.-C.: Effect of aerosol humidification on the column aerosol optical thickness over the Atmospheric Radiation Measurement Southern Great Plains site, J. Geophys. Res., 112, D10202, doi:10.1029/2006JD007176, 2007.
Kahn, R. A.: Reducing the Uncertainties in Direct Aerosol Radia-tive Forcing, Surv. Geophys., 33, 701–721, doi:10.1007/s10712-011-9153-z, 2012.
Kanakidou, M., Seinfeld, J. H., Pandis, S. N., Barnes, I., Dentener, F. J., Facchini, M. C., Van Dingenen, R., Ervens, B., Nenes, A., Nielsen, C. J., Swietlicki, E., Putaud, J. P., Balkanski, Y., Fuzzi, S., Horth, J., Moortgat, G. K., Winterhalter, R., Myhre, C. E. L., Tsigaridis, K., Vignati, E., Stephanou, E. G., and Wil-son, J.: Organic aerosol and global climate odeling: a review, At-mos. Chem. Phys., 5, 1053–1123, doi:10.5194/acp-5-1053-2005, 2005.
Kandler, K., Lieke, K., Benker, N., Emmel, C., Küpper, M., Müller-Ebert, D., Müller-Ebert, M., Scheuvens, D., Schladitz, A., Schütz, L., and Weinbruch, S.: Electron microscopy of particles collected at Praia, Cape Verde, during the Saharan Mineral Dust Experiment: particle chemistry, shape, mixing state and complex refractive index, Tellus B, 63, 475–496, 2011.
King, M. D., Kaufman, Y. J., Menzel, W., and Tanre, D.: Remote sensing of cloud, aerosol, and water vapor properties from the Moderate Resolution Imaging Spectrometer (MODIS), Geosci. Remote Sens., 30, 2–27, 1992.
Kinne, S., Lohmann, U., Feichter, J., Timmreck, C., Schulz, M., Ghan, S., Easter, R., Chin, M., Ginoux, P., Takemura, T., Tegen, I., Koch, D., Herzog, M., Penner, J., Pitari, G., Holben, B., Eck, T., Smirnov, A., Dubovik, O., Slutsker, I., Tanré, D., Torres, O., Mishchenko, M., Geogdzhayev, I., Chu, D. A., and Kaufman, Y.: Monthly Averages of Aerosol Properties: A Global compari-son among models, satellite data and AERONET ground data, J. Geophys. Res., 108, 4634, doi:10.1029/2001JD001253, 2003. Kirchstetter, T. W., Novakov, T., and Hobbs, P. V.: Evidence
that the spectral dependence of light absorption by aerosols is affected by organic carbon, J. Geophys. Res., 109, D21208, doi:10.1029/2004JD004999, 2004.
Köhler, H.: The nucleus in the growth of hygroscopic droplets, Trans. Faraday Soc., 32, 1152–1161, 1936.
Köpke, P., Hess, M., Schult, I.,and Shettle, E. P.: Global Aerosol Data Set, Report No. 243, ISSN: 0937-1060, Max-Planck-Institut für Meteorologie, Hamburg, 1997.
Koren, I., Remer, L., Kaufman, Y. J., Rudich, Y., and Martins, J.: On the twilight zone between clouds and aerosols, Geophys. Res. Lett., 34, L08805, doi:10.1029/2007GL029253, 2007.
Kulmala, M., Kerminen, V. M., Anttila, T., Laaksonen, A., and O’Dowd, C. D.: Organic aerosol formation via sul-phate cluster activation, J. Geophys. Res, 109, D04205, doi:10.1029/2003JD003961, 2004.
Kulmala, M., Asmi, A., Lappalainen, H. K., Carslaw, K. S.,Pöschl, U., Baltensperger, U., Hov, Ø., Brenquier, J.-L., Pandis, S. N., Facchini, M. C., Hansson, H.-C., Wiedensohler, A., and O’Dowd, C. D.: Introduction: European Integrated project on Aerosol Cloud Climate and Air Quality interactions (EUCAARI) – integrating aerosol research from nano to global scales, At-mos. Chem. Phys., 9, 2825–2841, doi:10.5194/acp-9-2825-2009, 2009.
Kulmala, M., Asmi, A., Lappalainen, H. K., Baltensperger, U., Brenguier, J.-L., Facchini, M. C., Hansson, H.-C., Hov, Ø., O’Dowd, C. D., Pöschl, U., Wiedensohler, A., Boers, R., Boucher, O., de Leeuw, G., Denier van der Gon, H. A. C., Fe-ichter, J., Krejci, R., Laj, P., Lihavainen, H., Lohmann, U., Mc-Figgans, G., Mentel, T., Pilinis, C., Riipinen, I., Schulz, M., Stohl, A., Swietlicki, E., Vignati, E., Alves, C., Amann, M., Ammann, M., Arabas, S., Artaxo, P., Baars, H., Beddows, D. C. S., Bergström, R., Beukes, J. P., Bilde, M., Burkhart, J. F., Canonaco, F., Clegg, S. L., Coe, H., Crumeyrolle, S., D’Anna, B., Decesari, S., Gilardoni, S., Fischer, M., Fjaeraa, A. M., Foun-toukis, C., George, C., Gomes, L., Halloran, P., Hamburger, T., Harrison, R. M., Herrmann, H., Hoffmann, T., Hoose, C., Hu, M., Hyvärinen, A., Hõrrak, U., Iinuma, Y., Iversen, T., Josipovic, M., Kanakidou, M., Kiendler-Scharr, A., Kirkevåg, A., Kiss, G., Klimont, Z., Kolmonen, P., Komppula, M., Kristjánsson, J.-E., Laakso, L., Laaksonen, A., Labonnote, L., Lanz, V. A., Lehtinen, K. E. J., Rizzo, L. V., Makkonen, R., Manninen, H. E., McMeek-ing, G., Merikanto, J., Minikin, A., Mirme, S., Morgan, W. T., Nemitz, E., O’Donnell, D., Panwar, T. S., Pawlowska, H., Pet-zold, A., Pienaar, J. J., Pio, C., Plass-Duelmer, C., Prévôt, A. S. H., Pryor, S., Reddington, C. L., Roberts, G., Rosenfeld, D., Schwarz, J., Seland, Ø., Sellegri, K., Shen, X. J., Shiraiwa, M., Siebert, H., Sierau, B., Simpson, D., Sun, J. Y., Topping, D., Tunved, P., Vaattovaara, P., Vakkari, V., Veefkind, J. P., Viss-chedijk, A., Vuollekoski, H., Vuolo, R., Wehner, B., Wildt, J., Woodward, S., Worsnop, D. R., van Zadelhoff, G.-J., Zardini, A. A., Zhang, K., van Zyl, P. G., Kerminen, V.-M., S Carslaw, K., and Pandis, S. N.: General overview: European Integrated project on Aerosol Cloud Climate and Air Quality interactions (EUCAARI) – integrating aerosol research from nano to global scales, Atmos. Chem. Phys., 11, 13061–13143, doi:10.5194/acp-11-13061-2011, 2011.
Lesins, G., Chylek, P., and Lohmann, U.: A study of internal and external mixing scenarios and its effect on aerosol optical prop-erties and direct radiative forcing, J. Geophys. Res., 107, 4094, doi:10.1029/2001JD000973, 2002.
Loeb, N. G. and Su, W.: Direct Aerosol Radiative Forcing Uncer-tainty Based on a Radiative Perturbation Analysis, J. Climate, 23, 5288–5293, doi:10.1175/2010JCLI3543.1, 2010.
Lohmann, U. and Feichter, J.: Global indirect aerosol effects: a re-view, Atmos. Chem. Phys., 5, 715–737, doi:10.5194/acp-5-715-2005, 2005.
Atmos. Chem. Phys., 10, 3235–3246, doi:10.5194/acp-10-3235-2010, 2010.
Marcolli, C. and Krieger, U. K..: Phase changes during hygro-scopic cycles of mixed organic/inorganic model systems of tropospheric aerosols, J. Phys. Chem. A., 110, 1881–1893, doi:10.1021/jp0556759, 2006.
McConnell, C. L., Formenti, P., Highwood, E. J., and Harrison, M. A. J.: Using aircraft measurements to determine the refrac-tive index of Saharan dust during the DODO Experiments, At-mos. Chem. Phys., 10, 3081–3098, doi:10.5194/acp-10-3081-2010, 2010.
Mensah, A. A., Holzinger, R., Otjes, R., Trimborn, A., Mentel, T. F., ten Brink, H., Henzing, B., and Kiendler-Scharr, A.: Aerosol chemical composition at Cabauw, The Netherlands as observed in two intensive periods in May 2008 and March 2009, Atmos. Chem. Phys., 12, 4723–4742, doi:10.5194/acp-12-4723-2012, 2012.
Meyer, N. K., Duplissy, J., Gysel, M., Metzger, A., Dommen, J., Weingartner, E., Alfarra, M. R., Prévôt, A. S. H., Fletcher, C., Good, N., McFiggans, G., Jonsson, Å. M., Hallquist, M., Bal-tensperger, U., and Ristovski, Z. D.: Analysis of the hygro-scopic and volatile properties of ammonium sulphate seeded and unseeded SOA particles, Atmos. Chem. Phys., 9, 721–732, doi:10.5194/acp-9-721-2009, 2009.
Mishchenko, M. I., Travis, L. D., Kahn, R. A., and West, R. A.: Modeling phase functions for dustlike tropospheric aerosols us-ing a shape mixture of randomly oriented polydisperse spheroids. J. Geophys. Res., 102, 16831–16847, doi:10.1029/96JD02110, 1997.
Moelwyn-Hughes, E. A.: Physical Chemistry, 2nd rev. ed., p. 397, Pergamon, New York, 1961.
Morgan, W. T., Allan, J. D., Bower, K. N., Esselborn, M., Har-ris, B., Henzing, J. S., Highwood, E. J., Kiendler-Scharr, A., McMeeking, G. R., Mensah, A. A., Northway, M. J., Osborne, S., Williams, P. I., Krejci, R., and Coe, H.: Enhancement of the aerosol direct radiative effect by semi-volatile aerosol com-ponents: airborne measurements in North-Western Europe, At-mos. Chem. Phys., 10, 8151–8171, doi:10.5194/acp-10-8151-2010, 2010.
Myhre, G.: Consistency Between Satellite-Derived and Modeled Estimates of the Direct Aerosol Effect, Science 325, 187–190, doi:10.1126/science.1174461, 2009.
Myhre, G., Samset, B. H., Schulz, M., Balkanski, Y., Bauer, S., Berntsen, T. K., Bian, H., Bellouin, N., Chin, M., Diehl, T., Easter, R. C., Feichter, J., Ghan, S. J., Hauglustaine, D., Iversen, T., Kinne, S., Kirkevåg, A., Lamarque, J.-F., Lin, G., Liu, X., Lund, M. T., Luo, G., Ma, X., van Noije, T., Penner, J. E., Rasch, P. J., Ruiz, A., Seland, Ø., Skeie, R. B., Stier, P., Takemura, T., Tsigaridis, K., Wang, P., Wang, Z., Xu, L., Yu, H., Yu, F., Yoon, J.-H., Zhang, K., Zhang, H., and Zhou, C.: Radiative forcing of the direct aerosol effect from AeroCom Phase II simulations, Atmos. Chem. Phys., 13, 1853–1877, doi:10.5194/acp-13-1853-2013, 2013a.
Myhre, G., Myhre, C. E. L., Samset, B. H., and Storelvmo, T.: Aerosols and their Relation to Global Climate and Climate Sen-sitivity, Nature Educ. Knowl., 4, 7, 2013b.
Nelder, J. A. and Mead, R.: A simplex method for function min-imization, Comp. J., 7, 308–313, doi:10.1093/comjnl/7.4.308, 1965.
Oshima, N., Koike, M., Zhang, Y., and Kondo, Y.: Aging of black carbon in outflow from anthropogenic sources using a mixing state resolved model: 2. Aerosol optical properties and cloud condensation nuclei activities, J. Geophys. Res., 114, D18202, doi:10.1029/2008JD011681, 2009.
Péré, J. C., Mallet, M., Bessagnet, B., and Pont, V.: Evidence of the aerosol core-shell mixing state over Europe during the heat wave of summer 2003 by using CHIMERE simulations and AERONET inversions, Geophys. Res. Lett., 36, L09807, doi:10.1029/2009GL037334, 2009.
Petzold, A. and Schönlinner, M.: Multi-angle absorption photome-try – a new method for the measurement of aerosol light absorp-tion and atmospheric black carbon, J. Aerosol Sci., 35, 421–441, 2004.
Petzold, A., Schloesser, H., Sheridan, P. J., Arnott, W. P., Ogren, J. A., and Virkkula, A.: Evaluation of multiangle absorption photometry for measuring aerosol light absorption, Aerosol Sci. Technol., 39, 40–51, 2005.
Quaas, J., Boucher, O., Bellouin, N., and Kinne, S.: Satellite-based estimate of the direct and indirect aerosol climate forcing, J. Geo-phys. Res., 113, D05204, doi:10.1029/2007JD008962, 2008. Quaas, J., Ming, Y., Menon, S., Takemura, T., Wang, M., Penner,
J. E., Gettelman, A., Lohmann, U., Bellouin, N., Boucher, O., Sayer, A. M., Thomas, G. E., McComiskey, A., Feingold, G., Hoose, C., Kristjánsson, J. E., Liu, X., Balkanski, Y., Donner, L. J., Ginoux, P. A., Stier, P., Feichter, J., Sednev, I., Bauer, S. E., Koch, D., Grainger, R. G., Kirkevåg, A., Iversen, T., Seland, Ø., Easter, R., Ghan, S. J., Rasch, P. J., Morrison, H., Lamarque, J.-F., Iacono, M. J., Kinne, S., and Schulz, M.: Aerosol indirect effects – general circulation model intercomparison and eval-uation with satellite data, Atmos. Chem. Phys., 9, 8697–8717, doi:10.5194/acp-9-8697-2009, 2009.
Richardson, C. B. and Hightower, R. L.: Evaporation of ammonium nitrate particles, Atmos. Environ., 21, 971–975, 1987.
Roelofs, G. J. and Kamphuis, V.: Cloud processing, cloud evapo-ration and Angström exponent, Atmos. Chem. Phys., 9, 71–80, doi:10.5194/acp-9-71-2009, 2009.
Roelofs, G. J., ten Brink, H., Kiendler-Scharr, A., de Leeuw, G., Mensah, A., Minikin, A., and Otjes, R.: Evaluation of simulated aerosol properties with the aerosol-climate model ECHAM5-HAM using observations from the IMPACT field campaign, At-mos. Chem. Phys., 10, 7709–7722, doi:10.5194/acp-10-7709-2010, 2010.
Russchenberg, H. W. J., Bosveld, F., Swart, D. P. J., ten Brink, H., de Leeuw, G., Uijlenhoet, R., Arbesser-Rastburg, B., van der Marel, H., Ligthart, L., Boers, R., and Apituley, A.: Ground-based atmospheric remote sensing in The Netherlands; Eu-ropean outlook, IEICE Trans. Comm., E88-B(6), 2252–2258, doi:10.1093/ietcom/e88-b.6.2252, 2005.
Russell, P. B., Bergstrom, R. W., Shinozuka, Y., Clarke, A. D., De-Carlo, P. F., Jimenez, J. L., Livingston, J. M., Redemann, J., Dubovik, O., and Strawa, A.: Absorption Angstrom Exponent in AERONET and related data as an indicator of aerosol composi-tion, Atmos. Chem. Phys., 10, 1155–1169, doi:10.5194/acp-10-1155-2010, 2010.
