Decomposing uncertainties in the future

terrestrial carbon budget associated with

emission scenario, climate projection,

and ecosystem simulation using the

ISI-MIP result

K. Nishina1, A. Ito1, P. Falloon3, A. D. Friend5, D. J. Beerling6, P. Ciais7,

D. B. Clark4, R. Kahana3, E. Kato1, W. Lucht2, M. Lomas6, R. Pavlick8,

S. Schaphoff2, L. Warszawaski2, and T. Yokohata1
